Introduction
The Siemens 6AG4010-6EC30-0FX5 SIMATIC IPC3000 SMART V3 is an industrial rack PC intended for computing tasks in automation and manufacturing environments. Its reported configuration combines an Intel Core i7-6700 processor, 8 GB DDR4 memory, and dual 1 TB hard drives, making it a candidate for industrial visualization, production data processing, and equipment-monitoring applications.
The unit is associated with a 19-inch, 4U rack-mounted chassis and a range of industrial communication interfaces. Because operating-system support and configuration details can affect long-term serviceability, buyers should verify the supplied hardware and software before deployment, especially when integrating the computer into a modern industrial network.
Technical Specifications
Specification | Details |
|---|
Manufacturer | Siemens |
Order number | 6AG4010-6EC30-0FX5 |
Product family | SIMATIC IPC3000 SMART V3 |
Device type | Industrial rack PC |
Form factor | 19-inch, 4U |
Processor | Intel Core i7-6700, 4 cores / 8 threads |
Processor frequency | 3.4 GHz base, up to 4.0 GHz Turbo |
Memory | 8 GB DDR4 SDRAM |
Storage | 2 × 1 TB HDD, as reported for this configuration |
Optical drive | No DVD drive, as reported |
Operating system | Windows 7 Ultimate multilingual, configuration requires confirmation |
Ethernet | 2 × LAN |
Serial interfaces | Serial ports; exact standards and layout require confirmation |
USB | Front and rear USB ports; verify exact count |
Display interfaces | VGA and DisplayPort, as reported |
Other interfaces | PS/2 and audio, as reported |
Power supply | 350 W, as reported |
Dimensions (W × H × D) | Requires confirmation |
Weight | Approximately 14.1 kg, reported; verify before installation |
Regional release | Listed as China-market release; confirm regional suitability |
Recommended Companion Models
These related Siemens industrial PC order numbers can be used for configuration comparisons. Verify the precise hardware and compatibility before treating any model as a direct replacement.
Model Number | Product Name |
|---|
6AG4010-6EC30-0BX5 | Siemens SIMATIC IPC3000 SMART V3 industrial PC, related configuration |
6AG4010-6EC30-0DX5 | Siemens SIMATIC IPC3000 SMART V3 industrial PC, related configuration |
6AG4010-6EC30-0XX5 | Siemens industrial PC, related 6EC30 configuration; exact specification requires confirmation |
6AG4010-6EC21-0FX5 | Siemens industrial PC, related 6EC series configuration; exact specification requires confirmation |
Frequently Selected Alternatives
The following models are documented configurations from the earlier SIMATIC IPC3000 SMART family. They are comparison candidates, not guaranteed drop-in replacements for the V3 configuration.
Model Number | Product Name |
|---|
6AG4010-4AA11-0XX5 | Siemens SIMATIC IPC3000 SMART industrial PC |
6AG4010-4AA20-0XX5 | Siemens SIMATIC IPC3000 SMART industrial PC |
6AG4010-4AB22-0XX5 | Siemens SIMATIC IPC3000 SMART industrial PC |
6AG4010-4BA10-0XX5 | Siemens SIMATIC IPC3000 SMART industrial PC |
Technical FAQs
Q1: What is Siemens 6AG4010-6EC30-0FX5?
It is a Siemens SIMATIC IPC3000 SMART V3 industrial PC configuration. Available product information identifies it as a 19-inch, 4U rack-mounted computer with an Intel Core i7-6700 processor, 8 GB DDR4 memory, and two 1 TB hard drives.
Q2: Which processor does this model use?
The listed configuration uses an Intel Core i7-6700 processor with four physical cores and eight threads, a base frequency of 3.4 GHz, and a maximum Turbo frequency of up to 4.0 GHz.
Q3: How much memory and storage does it provide?
The reported configuration includes 8 GB DDR4 SDRAM and two 1 TB hard disk drives. Confirm the actual installed components against the device label or supplier configuration sheet before ordering a replacement.
Q4: Which operating system is supplied?
Available product information lists Windows 7 Ultimate, multilingual, with English and other language options. Confirm the precise license and installation status for the unit being supplied, particularly if it will be connected to a modern network.
Q5: What communication interfaces are available?
The listed interfaces include two Ethernet LAN ports, serial communication, USB ports, VGA, DisplayPort, PS/2, and audio. Verify the exact port count and supported serial standards against the unit's configuration.
Q6: Does this model include an optical drive?
The reported 0FX5 configuration is described as an IPC3000 standard version without a DVD drive. Check the supplied unit directly if optical media is required for installation or maintenance.
Q7: What is the power supply rating?
The listed configuration specifies a 350 W power supply. Confirm the input-voltage range, regional power cable, and electrical requirements before installation.
Q8: Can it be used for PLC communication and SCADA applications?
Yes, it can potentially serve as a host for compatible visualization, supervisory control, and data-acquisition software. Actual compatibility depends on the operating system, application version, communication drivers, network configuration, and licensing.
Q9: What are its dimensions and weight?
The chassis is associated with a 19-inch, 4U rack format. A weight of approximately 14.1 kg is reported for this specific order number by a product listing, but the exact mechanical dimensions were not independently confirmed. Verify both measurements before planning cabinet installation.
Q10: What should be checked before purchasing?
Confirm the full order number, processor, memory, hard-drive configuration, operating system, interface layout, power supply, regional release restrictions, physical dimensions, and included accessories. Also assess operating-system security and software compatibility before integrating the computer into a current production network.
