The Yokogawa ADV869-P00 I/O Module is a high-performance, high-density input/output (I/O) module designed for use in advanced industrial automation and control systems. This module provides a flexible and reliable solution for handling a large number of inputs and outputs in process automation, manufacturing, energy, and building control applications. Built for scalability, efficiency, and precision, the ADV869-P00 integrates seamlessly into Yokogawa’s broader automation ecosystem, providing high-quality data collection, signal processing, and real-time control.

With its ability to support both analog and digital signals, the ADV869-P00 is ideal for industries where real-time monitoring and accurate control of physical processes are crucial. Whether used in a distributed control system (DCS) or an industrial automation platform, this module ensures reliable performance, even in the most demanding environments.

Technical Specifications

Model: Yokogawa ADV869-P00
Module Type: I/O Module
Input Types:
- Analog: 4-20 mA, 0-10 V
- Digital: Discrete inputs
Output Types:
- Analog: 4-20 mA, 0-10 V
- Digital: Discrete outputs
I/O Capacity:
- Inputs: 32 total (16 analog, 16 digital)
- Outputs: 32 total (16 analog, 16 digital)
Power Supply: 24 V DC
Communication Protocols:
- Ethernet/IP, Modbus TCP
Dimensions: 8.3 x 6.5 x 4.2 inches (210 x 165 x 107 mm)
Weight: 2.7 kg (5.95 lbs)
Operating Temperature: -10°C to 60°C
Storage Temperature: -20°C to 70°C
Humidity: 5% to 95% RH (non-condensing)
Certifications: UL Listed, CE, RoHS Compliant

Recommended Related Models

Yokogawa ADV860 – Digital I/O Module
Yokogawa ADV850 – Analog Input Module
Yokogawa ADV550 – Digital Input Module
Yokogawa ADV871 – Signal Conditioning Module
Yokogawa ADV840 – Communication Interface Module

These related models provide additional capabilities for I/O, signal conditioning, and communication, complementing the ADV869-P00 to enhance your automation system’s functionality.

Popular Yokogawa Models

The Yokogawa ADV869-P00 is part of Yokogawa's well-established range of modules and integrates seamlessly with a variety of Yokogawa systems, including:

Yokogawa Centum VP – Distributed Control System (DCS)
Yokogawa STARDOM – Remote Automation System for decentralized control
Yokogawa ProSafe-RS – Safety Instrumented System (SIS)
Yokogawa FAM – Field Asset Management for monitoring and diagnostics

These models work seamlessly with the ADV869-P00, creating a powerful, flexible, and integrated solution for industrial automation.

Applications

The Yokogawa ADV869-P00 I/O Module is designed for use in a wide range of industrial applications, including:

Process Automation: Ideal for industries such as oil & gas, chemicals, and pharmaceuticals, where the module ensures precise control of variables such as pressure, flow, and temperature.
Energy & Utilities: Suitable for power plants, renewable energy systems, and grid management, the ADV869-P00 ensures stable and efficient communication for energy control and monitoring.
Manufacturing Automation: Used in industries like automotive, electronics, and food processing to connect machinery, control production lines, and automate various stages of manufacturing.
Building Automation: For applications in smart buildings, the ADV869-P00 helps integrate systems such as HVAC, lighting, and security for optimized energy use and operational control.

Advantages

High I/O Density: The ADV869-P00 offers 64 I/O points (32 inputs and 32 outputs), allowing for high-density data acquisition and control in compact applications, reducing the need for multiple modules.
Versatile I/O Capabilities: Supports both analog (4-20 mA, 0-10 V) and digital signals, making it suitable for a wide variety of sensors, actuators, and devices.
Reliable Communication: With support for both Ethernet/IP and Modbus TCP, the ADV869-P00 ensures high-speed and reliable communication across industrial networks.
Compact Design: Despite its high I/O capacity, the module’s compact dimensions (210 x 165 x 107 mm) allow for easy installation in control panels or equipment racks, saving valuable space.
Wide Operating Temperature Range: The ADV869-P00 can operate in environments ranging from -10°C to 60°C, ensuring reliability across various industrial conditions.
Scalability and Flexibility: Easily integrates with other Yokogawa modules and systems, providing flexibility for building scalable control solutions in large industrial operations.

Technical FAQs

How many I/O points can the ADV869-P00 handle?
The ADV869-P00 can handle up to 64 I/O points: 32 inputs (16 analog, 16 digital) and 32 outputs (16 analog, 16 digital).
What are the supported communication protocols for the ADV869-P00?
The module supports Ethernet/IP and Modbus TCP, ensuring compatibility with a wide range of industrial networks.
What is the power supply requirement for the ADV869-P00?
The ADV869-P00 operates with a 24 V DC power supply, standard for most industrial automation systems.
What is the temperature range of the ADV869-P00?
The module operates within a temperature range of -10°C to 60°C, making it suitable for various industrial environments.
What is the weight of the ADV869-P00?
The module weighs 2.7 kg (5.95 lbs), making it easy to handle during installation while providing powerful I/O performance.
Can the ADV869-P00 be used in hazardous environments?
The ADV869-P00 is designed for general industrial use. If you require usage in hazardous areas, you should verify with additional certifications (e.g., ATEX, IECEx).
Is the ADV869-P00 compatible with other Yokogawa systems?
Yes, the ADV869-P00 integrates seamlessly with other Yokogawa systems like Centum VP, STARDOM, and ProSafe-RS, ensuring easy system expansion and integration.
How compact is the ADV869-P00?
The module’s dimensions are 8.3 x 6.5 x 4.2 inches (210 x 165 x 107 mm), offering a compact solution for high-density I/O in industrial applications.
What certifications does the ADV869-P00 have?
The ADV869-P00 is UL Listed, CE certified, and RoHS Compliant, ensuring it meets global safety and environmental standards.
Can the ADV869-P00 be used for both analog and digital signals?
Yes, the ADV869-P00 supports both analog (4-20 mA, 0-10 V) and digital signals, making it highly versatile for a variety of applications.
