The Yokogawa AEP7D I/O Module is a highly reliable and versatile I/O module designed to meet the needs of modern industrial automation systems. Ideal for applications in process control, manufacturing automation, energy systems, and building management, the AEP7D offers excellent performance in real-time data acquisition and control. With its high-density I/O capabilities, the AEP7D ensures that your system operates efficiently, even in the most demanding industrial environments.

The AEP7D module is built to integrate seamlessly with Yokogawa’s range of control systems, allowing for precise monitoring and control of analog and digital signals across a wide variety of field devices. Whether you need to monitor sensors, actuators, or other industrial equipment, the AEP7D provides the flexibility and reliability to keep your systems running smoothly.

Technical Specifications

Model: Yokogawa AEP7D
Module Type: I/O Module
Input Types:
- Analog: 4-20 mA, 0-10 V
- Digital: Discrete inputs
Output Types:
- Analog: 4-20 mA, 0-10 V
- Digital: Discrete outputs
I/O Capacity:
- Inputs: 16 analog (4-20 mA, 0-10 V), 8 digital
- Outputs: 16 analog (4-20 mA, 0-10 V), 8 digital
Power Supply: 24 V DC
Communication Protocol:
- Ethernet/IP, Modbus TCP
Dimensions: 8.0 x 6.0 x 4.2 inches (203 x 152 x 107 mm)
Weight: 2.3 kg (5.07 lbs)
Operating Temperature: -10°C to 60°C
Storage Temperature: -20°C to 70°C
Humidity: 5% to 95% RH (non-condensing)
Certifications: UL Listed, CE, RoHS Compliant

Recommended Related Models

Yokogawa AEP7E – Advanced Analog Input Module
Yokogawa AEP7F – Digital I/O Module
Yokogawa AEP7C – Signal Conditioning Module
Yokogawa AEP7G – Communication Interface Module
Yokogawa AEP7A – Analog Output Module

These related models complement the AEP7D by providing additional I/O capabilities, signal conditioning, and communication features, enhancing the overall flexibility of your system.

Popular Yokogawa Models

The Yokogawa AEP7D I/O Module integrates seamlessly with a variety of popular Yokogawa systems, ensuring effective, scalable automation solutions:

Yokogawa Centum VP – Distributed Control System (DCS)
Yokogawa STARDOM – Remote Automation System for decentralized control
Yokogawa ProSafe-RS – Safety Instrumented System (SIS)
Yokogawa FAM – Field Asset Management for condition monitoring and diagnostics

These control systems, when used alongside the AEP7D, ensure reliable, real-time control, monitoring, and management of industrial processes and systems.

Applications

The Yokogawa AEP7D I/O Module is designed for use across a variety of industrial applications, including:

Process Automation: Suitable for industries such as chemical, pharmaceutical, and petrochemical, where precise control of process variables such as temperature, pressure, and flow is crucial to ensuring product quality and operational efficiency.
Energy & Utilities: Ideal for use in power plants, renewable energy systems, and utility networks, providing real-time monitoring and optimization of energy distribution and generation.
Manufacturing Automation: Used in industries like automotive, electronics, and food processing, the AEP7D enhances automation on production lines, helping to improve machine performance, reduce downtime, and optimize quality control.
Building Automation: The AEP7D facilitates automation in large buildings, integrating systems such as HVAC, lighting, and security for energy efficiency and improved operational control.

Advantages

High I/O Density: The AEP7D provides a high-density configuration with up to 32 I/O points (16 analog, 8 digital inputs and 16 analog, 8 digital outputs), enabling efficient handling of complex industrial data in a single module.
Flexible I/O Configuration: With both analog and digital signal capabilities (4-20 mA, 0-10 V), the AEP7D can easily interface with a wide range of sensors, actuators, and field devices.
Reliable Communication: The AEP7D supports Ethernet/IP and Modbus TCP, ensuring robust, high-speed communication across industrial networks and enabling smooth integration with existing control systems.
Compact and Efficient Design: Despite its high I/O capacity, the AEP7D is designed to be compact (203 x 152 x 107 mm), making it a space-efficient solution that can be easily integrated into control panels or equipment racks.
Wide Operating Temperature Range: The module operates in a temperature range from -10°C to 60°C, allowing it to be deployed in a variety of environments, including harsh industrial conditions.
Seamless Integration: The AEP7D integrates effortlessly with other Yokogawa control systems, such as Centum VP and STARDOM, enabling streamlined, scalable automation solutions.

Technical FAQs

How many I/O points does the AEP7D support?
The AEP7D supports up to 32 I/O points: 16 analog inputs (4-20 mA, 0-10 V), 8 digital inputs, 16 analog outputs (4-20 mA, 0-10 V), and 8 digital outputs.
What communication protocols does the AEP7D support?
The module supports Ethernet/IP and Modbus TCP, providing reliable communication for real-time data transfer across industrial systems.
What is the power supply requirement for the AEP7D?
The module operates on a 24 V DC power supply, a standard for industrial automation systems.
What is the temperature range of the AEP7D?
The AEP7D operates in a temperature range of -10°C to 60°C, making it suitable for most industrial environments.
What are the dimensions of the AEP7D?
The module measures 8.0 x 6.0 x 4.2 inches (203 x 152 x 107 mm) and weighs 2.3 kg (5.07 lbs), making it compact yet capable of handling high-density I/O configurations.
Is the AEP7D suitable for hazardous environments?
The AEP7D is designed for general industrial use. If used in hazardous environments, additional certifications (e.g., ATEX, IECEx) may be necessary.
Can I use the AEP7D in combination with other Yokogawa systems?
Yes, the AEP7D is designed to integrate seamlessly with Yokogawa’s Centum VP, STARDOM, and ProSafe-RS systems, making it highly compatible for large-scale automation projects.
Is the AEP7D easy to install?
Yes, the AEP7D is designed for easy installation and quick configuration, and it integrates easily into existing Yokogawa automation environments.
What certifications does the AEP7D have?
The AEP7D is UL Listed, CE Certified, and RoHS Compliant, meeting global standards for safety, quality, and environmental performance.
Does the AEP7D support both analog and digital signals?
Yes, the AEP7D supports both analog (4-20 mA, 0-10 V) and digital signals, providing versatility in handling various field devices.
