Siemens 6AG4010-6EE30-0DX5 – High-Performance SIMATIC IPC3000 SMART V3 Industrial Rack PC

Where It Excels in Industrial Use

• Factory automation supervision: Supports industrial computing applications for production monitoring, process visualization, and operational data management.

• Manufacturing data processing: Provides computing resources for production records, reporting tools, and compatible industrial software.

• Machine visualization: Can host suitable operator-interface and visualization applications for monitoring machinery and production lines.

• Industrial network integration: Dual Ethernet connections and serial interfaces support communication with compatible factory networks and legacy equipment.

• Centralized rack installations: The 19-inch, 4U chassis suits industrial equipment racks and control-room computing environments.

• Equipment connectivity: USB, VGA, DisplayPort, and serial connections provide options for compatible peripherals and industrial devices.

Key Strengths at a Glance

• Intel Core i7 processing: The listed Intel Core i7-6700 processor features four cores, four threads, a 3.4 GHz base frequency, up to 4.0 GHz turbo frequency, and 8 MB cache.

• Solid-state storage: A listed 512 GB SSD provides storage for compatible operating systems, industrial applications, and production data.

• DDR4 memory: The listed 8 GB DDR4 SDRAM configuration supports general industrial computing workloads.

• Broad connectivity: Two Ethernet LAN ports, serial connections, six USB ports, VGA, DisplayPort, PS/2, and audio interfaces support diverse integration needs.

• Serial communication flexibility: RS232, RS422, and RS485 support allows connection to compatible serial-based equipment.

• Rack-mounted construction: The 19-inch, 4U format supports integration into suitable industrial cabinets and rack systems.

Technical FAQs

Q1: What is the Siemens 6AG4010-6EE30-0DX5?

It is listed as a Siemens SIMATIC IPC3000 SMART V3 industrial rack PC. The specified configuration includes an Intel Core i7-6700 processor, 8 GB DDR4 memory, a 512 GB SSD, and a 350 W power supply.

Q2: What processor does this model use?

The listed configuration uses an Intel Core i7-6700 with four cores and four threads, a 3.4 GHz base frequency, up to 4.0 GHz turbo frequency, and 8 MB cache.

Q3: How much RAM and storage are included?

The listed configuration includes 8 GB DDR4 SDRAM and a 512 GB SSD. Confirm the installed components on the specific unit before ordering or planning upgrades.

Q4: Which network connections are available?

The unit is listed with two Ethernet LAN ports for compatible network connections and industrial system integration.

Q5: Does it support serial communication?

Yes. The listed configuration includes two serial interfaces and two COM ports supporting RS232, RS422, and RS485 modes. Verify the precise port arrangement and configuration before connecting field equipment.

Q6: Which display interfaces are provided?

The listed interface configuration includes one VGA port and one DisplayPort connection. Check monitor compatibility and required display resolution before deployment.

Q7: How many USB ports does it have?

The listed configuration provides six USB ports: four on the rear panel and two on the front panel.

Q8: Does the unit include an operating system?

The supplier listing specifies that it is supplied without an operating system, with drivers and documentation provided on a USB drive. Confirm the delivery contents and driver availability before commissioning.

Q9: What are the dimensions and weight?

The device is listed as a 19-inch, 4U rack PC with a net weight of approximately 14.1 kg. Exact external dimensions require confirmation from a model-specific mechanical drawing; the supplier's package-dimension field is not a reliable substitute for chassis measurements.

Q10: Is this model suitable for use outside China?

The supplier listing identifies this particular configuration as released for the Chinese market and supplied with a China-market power cable. Verify regional approval, power-cable requirements, and applicable compliance requirements before installing it elsewhere.
