Siemens 6AG4021-0AD11-2CA0 SIMATIC IPC127E Industrial Box PC

Industrial Applications and Deployment Scenarios

• Industrial automation systems requiring compact, fanless computing with a preinstalled operating system.

• Machine-level monitoring, data acquisition, and local processing in manufacturing environments.

• Industrial Ethernet and PROFINET communication with compatible automation equipment.

• Edge computing applications involving local data collection and industrial software execution.

• Equipment control cabinets where space-efficient computing hardware is essential.

• Industrial applications that benefit from onboard security features and solid-state storage.

Key Benefits and Product Features

• Quad-core processing: Intel Atom E3940 processor operating at 1.6 GHz with four cores and four threads.

• Integrated memory: 4 GB onboard DDR4 RAM for embedded industrial computing tasks.

• 128 GB SSD: Provides local storage for the operating system, application software, and operational data.

• Preinstalled operating system: Windows 10 Enterprise 2019 LTSC, 64-bit, with multilingual user interface support.

• Trusted Platform Module: TPM hardware support for compatible security and system-management applications.

• Industrial connectivity: Two RJ45 Ethernet ports, two USB 3.0 ports, and one DisplayPort.

• Fanless design: Reduces moving parts and supports low-maintenance industrial installations.

• 24 V DC power input: Suitable for integration into industrial control power systems.

• Compact enclosure: Designed for installation in space-constrained industrial environments.

Technical FAQs

1. What is the Siemens 6AG4021-0AD11-2CA0?

It is a Siemens SIMATIC IPC127E industrial Box PC with an Intel Atom E3940 processor, 4 GB RAM, 128 GB SSD, TPM support, and Windows 10 Enterprise 2019 LTSC.

2. Which processor is installed in this model?

The device uses an Intel Atom E3940 processor with four cores, four threads, and a nominal operating frequency of 1.6 GHz.

3. How much memory and storage does it provide?

The IPC includes 4 GB of onboard DDR4 RAM and a 128 GB solid-state drive.

4. Which operating system is preinstalled?

The system is supplied with Windows 10 Enterprise 2019 LTSC, 64-bit, with a multilingual user interface supporting English, German, French, Italian, and Spanish.

5. Does this model include TPM?

Yes. This configuration includes a Trusted Platform Module (TPM) for compatible security functions.

6. How many Ethernet ports are available?

The basic version provides two RJ45 Ethernet interfaces supporting 10/100/1000 Mbps communication.

7. Which USB and display interfaces are included?

It features two USB 3.0 ports and one DisplayPort for compatible peripherals and display devices.

8. What is the required power supply?

The IPC uses a nominal 24 V DC supply, with a specified operating range of 19.2–28.8 V DC.

9. Is the IPC suitable for industrial environments?

Its fanless design, industrial enclosure, integrated temperature monitoring, and watchdog functionality support suitable industrial computing applications. Actual suitability depends on ambient conditions and installation requirements.

10. Are mounting accessories included?

No. Mounting accessories are not included and must be selected separately based on the required DIN rail, wall, or portrait mounting arrangement.
