Siemens 6AG4022-0BC21-0AA1 SIMATIC IPC327G Industrial Box PC

Industrial Applications and Use Cases

• Industrial automation systems requiring a compact, fanless industrial computer.

• Machine monitoring and production data acquisition using Ethernet and serial communication.

• Industrial equipment integration requiring multiple COM ports for legacy devices and peripherals.

• Multi-display applications using dual DisplayPort graphics outputs.

• Local data processing and edge computing in manufacturing environments.

• Control cabinet installations using DIN rail or wall mounting.

• Customized industrial software deployments requiring an operating system and storage to be configured separately.

Key Product Advantages

• Intel Atom x6413E processor: Quad-core industrial computing platform with a maximum frequency of up to 3.0 GHz.

• 4 GB DDR4 RAM: Integrated memory configuration for embedded computing and industrial control applications.

• Flexible storage configuration: Supplied without mass storage, allowing system integrators to select a compatible storage solution.

• Dual Gigabit Ethernet: Two independent RJ45 Ethernet interfaces for industrial network connectivity.

• Dual DisplayPort outputs: Supports two compatible displays for visualization and monitoring.

• Multiple USB connections: Four USB 3.1 ports and three USB 2.0 ports for peripherals and external devices.

• Serial communication: Four COM ports for connecting compatible industrial equipment.

• Fanless construction: Reduces moving parts and helps minimize routine maintenance.

• 24 V DC power input: Designed for integration into compatible industrial power systems.

• Industrial installation options: Supports DIN rail or wall mounting.

Technical FAQs

1. What is the Siemens 6AG4022-0BC21-0AA1?

It is a Siemens SIMATIC IPC327G Basic Box PC designed for industrial computing, automation integration, machine monitoring, and data communication.

2. Which processor does this model use?

The IPC327G uses an Intel Atom x6413E processor with four cores and a maximum operating frequency of up to 3.0 GHz.

3. How much memory is installed?

This configuration includes 4 GB of DDR4 RAM. The IPC327G platform supports higher memory configurations depending on the selected variant.

4. Does this model include an SSD?

No. The 6AG4022-0BC21-0AA1 is supplied without mass storage. A compatible storage device must be selected and installed according to the intended application.

5. Is an operating system preinstalled?

No. This order number specifies a configuration supplied without an operating system, allowing the integrator to select and install compatible software.

6. How many Ethernet ports are available?

The IPC327G provides two independent RJ45 Gigabit Ethernet interfaces supporting 10/100/1000 Mbps communication.

7. Which display interfaces does the unit provide?

It includes two DisplayPort graphics outputs for connecting compatible monitors and industrial displays.

8. How many USB ports are included?

The specified configuration provides four USB 3.1 ports and three USB 2.0 ports.

9. Can the computer connect to serial industrial devices?

Yes. It includes four COM ports for compatible serial devices. The supported electrical interfaces and port configurations should be checked against the equipment being connected.

10. What are the power and environmental specifications?

The IPC uses a nominal 24 V DC supply, supports an operating temperature range of 0°C to 55°C, and has an IP40 protection rating. It is intended for installation in a suitable industrial environment.
