Siemens 6AG4022-0BC21-0AA2 SIMATIC IPC327G Industrial Box PC
Siemens 6AG4022-0BC21-0AA2 SIMATIC IPC327G Industrial Box PC
0.0
Points
Brand:Siemens Item No.: 6AG4022-0BC21-0AA2 Product Origin: Germany Product Dimensions:481 × 177 × 509 mm Product Weight:14 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
Product Overview: Flexible Industrial Computing for DIN Rail Installation
The Siemens SIMATIC IPC327G 6AG4022-0BC21-0AA2 is an industrial Box PC designed for automation environments that require reliable network communication, multiple peripheral interfaces, and compact installation. Its Intel Atom x6413E processor and 4 GB DDR4 memory provide a platform for machine-level monitoring, industrial data collection, visualization, and communication tasks.
The unit offers two independent Gigabit Ethernet interfaces, two DisplayPort outputs, four USB 3.1 ports, three USB 2.0 ports, and four serial COM ports. This range of interfaces makes it suitable for systems that combine modern Ethernet-connected equipment with compatible serial devices.
Supplied without an operating system or mass storage, the IPC allows integrators to select a suitable software environment and storage configuration. Its fanless design and DIN rail mounting arrangement support installation in appropriate industrial control cabinets and equipment enclosures.
Technical Specifications
Parameter
Specification
Manufacturer
Siemens
Order number
6AG4022-0BC21-0AA2
Product family
SIMATIC IPC327G
Product type
Basic Box PC
Processor
Intel Atom x6413E
CPU architecture
Quad-core
Maximum processor frequency
Up to 3.0 GHz
Installed memory
4 GB DDR4 RAM
Mass storage
Not included
Operating system
Not included
Ethernet interfaces
2 × independent RJ45 Gigabit Ethernet
Ethernet speed
10/100/1000 Mbps
Display interfaces
2 × DisplayPort
USB 3.1
4 ports
USB 2.0
3 ports
Serial interfaces
4 × COM
Audio
Not supported in this configuration
Cooling
Fanless
Supply voltage
24 V DC nominal
Power-failure buffering
20 ms
Protection rating
IP40
Operating temperature
0°C to 55°C
Relative humidity
5–85% at 30°C, non-condensing
Approximate dimensions (W × H × D)
254 × 132 × 73 mm
Net weight
Approximately 2.7 kg
Mounting
DIN rail
Storage and OS installation
Required separately
Recommended Companion Models
Model
Product Name
Typical Application
6AG4022-0BC21-0AA1
SIMATIC IPC327G Basic Box PC, 4 GB RAM, no OS or mass storage
Alternative base configuration
6AG4022-0BC21-2BA1
SIMATIC IPC327G with Intel Atom x6413E, 4 GB RAM, Windows 10 Enterprise LTSC 2019
Deployment requiring a preinstalled operating system
6AG4022-0BC31-0AA1
SIMATIC IPC327G with Intel Atom x6413E, 8 GB RAM, no OS
Applications requiring additional memory
6AG4022-0BC31-2BA1
SIMATIC IPC327G with Intel Atom x6413E, 8 GB RAM, Windows 10 Enterprise LTSC 2019
Windows-based applications requiring more memory
Frequently Selected Alternatives
Model
Product Name
Main Difference
6AG4022-0BC21-0BA2
SIMATIC IPC327G, 4 GB RAM, 256 GB SSD, no OS
Includes a 256 GB SSD
6AG4022-0BC21-2CA1
SIMATIC IPC327G with Windows 10 Enterprise LTSC 2019 and SSD storage
Preinstalled operating system and storage
6AG4022-0BC31-0BA2
SIMATIC IPC327G, 8 GB RAM, 256 GB SSD, no OS
Higher memory capacity and SSD storage
6AG4022-0AA21-0BA1
SIMATIC IPC327E Basic Box PC
Previous-generation IPC327E platform; check availability and compatibility before substitution
Industrial Applications and Integration Scenarios
Industrial automation systems requiring compact computing hardware with DIN rail mounting.
Machine monitoring and production data acquisition in manufacturing environments.
Industrial communication with PLCs, sensors, serial devices, and other compatible equipment.
Multi-display applications for machine visualization and equipment monitoring.
Edge computing and local data processing in industrial control cabinets.
Legacy equipment integration using multiple serial COM ports.
Customized industrial software deployments requiring a separately installed operating system and storage device.
Key Product Benefits
Intel Atom x6413E processor: Quad-core computing with a maximum frequency of up to 3.0 GHz.
4 GB DDR4 memory: Suitable for embedded industrial applications and lightweight computing workloads.
Flexible storage configuration: Supplied without mass storage, allowing the storage solution to be selected separately.
Dual Gigabit Ethernet: Two independent RJ45 interfaces for industrial network communication.
Dual DisplayPort outputs: Connects up to two compatible displays.
Multiple USB connections: Four USB 3.1 ports and three USB 2.0 ports for peripherals and external devices.
Four serial COM ports: Supports integration with compatible serial industrial equipment.
Fanless design: Reduces moving parts and helps simplify maintenance.
24 V DC power input: Supports integration into compatible industrial power systems.
DIN rail mounting: Designed for space-efficient installation in suitable industrial enclosures.
Technical FAQs
1. What is the Siemens 6AG4022-0BC21-0AA2?
It is a Siemens SIMATIC IPC327G Basic Box PC designed for industrial automation, machine monitoring, communication, and local data processing.
2. Which processor does this model use?
The IPC uses an Intel Atom x6413E quad-core processor with a maximum operating frequency of up to 3.0 GHz.
3. How much RAM is installed?
This configuration includes 4 GB of DDR4 RAM.
4. Does the IPC include an SSD or hard drive?
No. The 6AG4022-0BC21-0AA2 is supplied without mass storage. A compatible storage device must be selected separately.
5. Is an operating system included?
No. This model is supplied without an operating system, allowing system integrators to install a compatible operating environment for their application.
6. How many Ethernet ports are available?
It provides two independent RJ45 Gigabit Ethernet interfaces supporting 10/100/1000 Mbps communication.
7. Which display interfaces are supported?
The IPC includes two DisplayPort graphics outputs for compatible monitors and industrial displays.
8. How many USB and serial ports does it provide?
The configuration includes four USB 3.1 ports, three USB 2.0 ports, and four serial COM ports.
9. What power supply does the device require?
The IPC uses a nominal 24 V DC power supply. The complete electrical installation should follow the applicable Siemens technical documentation.
10. What mounting arrangement does this model use?
This version is specified for DIN rail mounting. Confirm the required rail type, enclosure clearance, and installation conditions before commissioning.
