Siemens 6AG4022-0BC31-0AA1 SIMATIC IPC327G Industrial Box PC
Siemens 6AG4022-0BC31-0AA1 SIMATIC IPC327G Industrial Box PC
0.0
Points
Brand:Siemens Item No.: 6AG4022-0BC31-0AA1 Product Origin: Germany Product Dimensions:254 × 132 × 73 mm Product Weight:2.7 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens SIMATIC IPC327G 6AG4022-0BC31-0AA1 is a compact industrial Box PC designed for automation, machine monitoring, and industrial data-processing applications. Its Intel Atom x6413E quad-core processor and 8 GB DDR4 memory provide a practical platform for applications that benefit from additional memory capacity.
The IPC offers two independent Gigabit Ethernet interfaces, two DisplayPort graphics outputs, four USB 3.1 ports, three USB 2.0 ports, and four serial COM ports. These connections support integration with networked automation equipment, industrial peripherals, compatible serial devices, and dual-display systems.
This configuration is supplied without an operating system or mass storage, giving integrators flexibility to choose a suitable software environment and storage device. Its fanless design, 24 V DC power input, and DIN rail or wall mounting options make it suitable for installation in compatible industrial control cabinets and equipment enclosures.
Technical Specifications
Parameter
Specification
Manufacturer
Siemens
Order number
6AG4022-0BC31-0AA1
Product family
SIMATIC IPC327G
Product type
Basic Box PC
Processor
Intel Atom x6413E
CPU architecture
Quad-core
Maximum processor frequency
Up to 3.0 GHz
Installed memory
8 GB DDR4 RAM
Maximum supported memory
16 GB, depending on configuration
Mass storage
Not included
Operating system
Not included
Ethernet interfaces
2 × independent RJ45 Gigabit Ethernet
Ethernet speed
10/100/1000 Mbps
Display interfaces
2 × DisplayPort
USB 3.1
4 ports
USB 2.0
3 ports
Serial interfaces
4 × COM
Audio
Not included in this configuration
Cooling
Fanless
Supply voltage
24 V DC
Power-failure buffering
20 ms
Protection rating
IP40
Operating temperature
0°C to 55°C
Mounting
DIN rail or wall mounting
Approximate dimensions (W × H × D)
254 × 132 × 73 mm
Approximate net weight
2.7 kg
Recommended Companion Models
Model
Product Name
Typical Application
6AG4022-0BC21-0AA1
SIMATIC IPC327G, Intel Atom x6413E, 4 GB RAM, no OS or mass storage
Basic configuration with lower installed memory
6AG4022-0BC31-2BA1
SIMATIC IPC327G, Intel Atom x6413E, 8 GB RAM, 256 GB SSD, Windows 10 Enterprise LTSC 2019
Deployment requiring preinstalled software and storage
6AG4022-0BC31-0BA2
SIMATIC IPC327G, Intel Atom x6413E, 8 GB RAM, SSD configuration
Industrial applications requiring onboard storage
6AG4022-0BC41-0AA1
SIMATIC IPC327G higher-memory configuration
Alternative configuration for applications with greater memory requirements; verify order-code details before selection
Frequently Selected Alternatives
Model
Product Name
Main Difference
6AG4022-0BC21-0AA1
SIMATIC IPC327G Basic Box PC, 4 GB RAM
Lower-memory configuration without OS or mass storage
Includes storage and a preinstalled operating system
6AG4022-0BC31-0BA2
SIMATIC IPC327G, 8 GB RAM with SSD
Provides onboard solid-state storage
6AG4022-0BC42-0CA1
SIMATIC IPC327G higher-memory and storage configuration
Alternative configuration for more demanding computing and storage requirements
Industrial Applications and Use Cases
Industrial automation and machine-level computing requiring an 8 GB RAM configuration.
Production monitoring, industrial data acquisition, and equipment diagnostics.
Ethernet communication with PLCs, industrial controllers, and supervisory systems.
Dual-display visualization for machine status, process data, and operator monitoring.
Serial device integration using compatible industrial COM interfaces.
Edge computing and local data processing in manufacturing environments.
Customized industrial software installations requiring a separately selected operating system and storage device.
Key Product Advantages
Intel Atom x6413E processor: Quad-core industrial computing with a maximum frequency of up to 3.0 GHz.
8 GB DDR4 RAM: Provides additional memory capacity for multitasking and industrial software workloads.
Flexible storage configuration: Supplied without mass storage, allowing a compatible storage solution to be selected separately.
Dual Gigabit Ethernet: Two independent RJ45 interfaces support industrial network communication.
Dual DisplayPort outputs: Connects two compatible monitors for visualization and monitoring.
Multiple USB interfaces: Four USB 3.1 ports and three USB 2.0 ports support peripherals and external devices.
Serial communication: Four COM ports support compatible industrial equipment and legacy devices.
Fanless construction: Reduces moving parts and helps simplify maintenance.
24 V DC power input: Designed for integration into compatible industrial power systems.
Flexible mounting: Supports DIN rail or wall mounting, depending on installation requirements.
Technical FAQs
1. What is the Siemens 6AG4022-0BC31-0AA1?
It is a Siemens SIMATIC IPC327G Basic Box PC featuring an Intel Atom x6413E processor and 8 GB of DDR4 RAM, designed for industrial computing and automation applications.
2. Which processor is installed in this model?
The IPC uses an Intel Atom x6413E quad-core processor with a maximum operating frequency of up to 3.0 GHz.
3. How much RAM does the IPC provide?
This configuration includes 8 GB of DDR4 RAM, providing additional memory capacity for compatible industrial software and multitasking workloads.
4. Does the device include an SSD?
No. The 6AG4022-0BC31-0AA1 is supplied without mass storage. A compatible SSD or other supported storage device must be selected separately.
5. Is an operating system preinstalled?
No. This model is supplied without an operating system, allowing system integrators to install a compatible software environment.
6. How many Ethernet interfaces are available?
The IPC provides two independent RJ45 Gigabit Ethernet interfaces supporting 10/100/1000 Mbps communication.
7. Which display connections are supported?
Two DisplayPort graphics outputs are available for connecting compatible displays.
8. How many USB and serial interfaces does it have?
The IPC327G interface configuration includes four USB 3.1 ports, three USB 2.0 ports, and four serial COM ports.
9. What power supply does the IPC require?
The unit uses a nominal 24 V DC supply and provides 20 ms of power-failure buffering under the specified conditions.
10. What are the mounting and environmental specifications?
The IPC supports rail or wall mounting, has an IP40 protection rating, and is designed for an operating temperature range of 0°C to 55°C.
