Siemens 6AG4022-0BC31-2BA1 SIMATIC IPC327G Industrial Box PC
Siemens 6AG4022-0BC31-2BA1 SIMATIC IPC327G Industrial Box PC
0.0
Points
Brand:Siemens Item No.:6AG4022-0BC31-2BA1 Product Origin: Germany Product Dimensions:254 × 132 × 73 mm Product Weight:14 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens SIMATIC IPC327G 6AG4022-0BC31-2BA1 is an industrial Box PC designed for automation, equipment monitoring, and local data-processing applications. Its Intel Atom x6413E quad-core processor and 8 GB DDR4 RAM provide a compact computing platform for industrial software, machine-level data acquisition, and visualization.
The integrated 256 GB Eco SSD and preinstalled Windows 10 Enterprise 2019 LTSC operating system help simplify deployment for applications requiring a Windows-based environment. Dual Gigabit Ethernet interfaces support industrial network connectivity, while dual DisplayPort outputs enable connection to compatible displays.
With four USB 3.1 ports, three USB 2.0 ports, and four COM ports, the IPC supports a wide range of compatible peripherals and industrial communication devices. Temperature monitoring, watchdog functionality, and fanless construction further support its use in suitable industrial environments.
Technical Specifications
Parameter
Specification
Manufacturer
Siemens
Order number
6AG4022-0BC31-2BA1
Product family
SIMATIC IPC327G
Product type
Basic Box PC
Processor
Intel Atom x6413E
CPU cores
4
Maximum processor frequency
Up to 3.0 GHz
Installed memory
8 GB DDR4 RAM
Maximum supported memory
16 GB
Storage
256 GB Eco SSD
Operating system
Windows 10 Enterprise 2019 LTSC
Operating system architecture
64-bit
User interface languages
English, German, French, Italian, Spanish
Ethernet interfaces
2 × independent RJ45 Gigabit Ethernet
Ethernet speed
10/100/1000 Mbps
Display interfaces
2 × DisplayPort
USB 3.1
4 ports
USB 2.0
3 ports
Serial interfaces
4 × COM
Audio
Not included
Cooling
Fanless
Supply voltage
24 V DC
Power-failure buffering
20 ms
Protection rating
IP40
Operating temperature
0°C to 55°C
Relative humidity
5–85% at 30°C, non-condensing
Approximate dimensions (W × H × D)
254 × 132 × 73 mm
Mounting
DIN rail or wall mounting
Monitoring functions
Temperature monitoring, watchdog, status LEDs
Recommended Companion Models
Model
Product Name
Typical Application
6AG4022-0BC21-2BA1
SIMATIC IPC327G, 4 GB RAM, Windows 10 Enterprise 2019 LTSC
Windows-based applications with a lower memory configuration
Industrial automation systems requiring a compact computer with 8 GB RAM and preinstalled Windows software.
Machine monitoring and production data acquisition in manufacturing facilities.
Industrial Ethernet communication with PLCs, controllers, and supervisory systems.
Dual-display applications for production visualization and equipment diagnostics.
Edge computing and local data processing using industrial software.
Serial communication with compatible instruments, controllers, and legacy equipment.
Control cabinet installations requiring fanless industrial computing and DIN rail or wall mounting.
Key Product Advantages
Intel Atom x6413E processor: Quad-core computing with a maximum frequency of up to 3.0 GHz.
8 GB DDR4 RAM: Supports industrial applications and multitasking workloads.
256 GB Eco SSD: Provides onboard solid-state storage for the operating system, applications, and local data.
Preinstalled Windows operating system: Windows 10 Enterprise 2019 LTSC, 64-bit, with multilingual user interface support.
Dual Gigabit Ethernet: Two independent RJ45 interfaces for industrial network connectivity.
Dual DisplayPort graphics: Supports two compatible displays for monitoring and visualization.
Multiple USB ports: Four USB 3.1 ports and three USB 2.0 ports for peripherals and external devices.
Serial connectivity: Four COM ports for compatible industrial equipment.
Fanless design: Reduces moving parts and helps simplify maintenance.
Industrial power input: Operates from a nominal 24 V DC supply.
Integrated monitoring: Includes temperature monitoring, watchdog functionality, and status LEDs.
Technical FAQs
1. What is the Siemens 6AG4022-0BC31-2BA1?
It is a Siemens SIMATIC IPC327G Basic Box PC featuring an Intel Atom x6413E processor, 8 GB RAM, a 256 GB SSD, and Windows 10 Enterprise 2019 LTSC.
2. Which processor does this model use?
The IPC uses an Intel Atom x6413E quad-core processor with a maximum operating frequency of up to 3.0 GHz.
3. How much memory is installed?
The system includes 8 GB of DDR4 RAM, providing memory capacity for compatible industrial applications and multitasking.
4. What storage capacity does it provide?
This configuration includes a 256 GB Eco SSD for the operating system, application software, and local data storage.
5. Which operating system is preinstalled?
It comes with Windows 10 Enterprise 2019 LTSC, 64-bit, with multilingual user interface support for English, German, French, Italian, and Spanish.
6. How many Ethernet ports are available?
The IPC provides two independent RJ45 Gigabit Ethernet interfaces supporting 10/100/1000 Mbps communication.
7. Which display and USB interfaces are included?
The device features two DisplayPort outputs, four USB 3.1 ports, and three USB 2.0 ports.
8. Does the IPC support serial communication?
Yes. It includes four COM ports for connecting compatible serial industrial devices and peripherals.
9. What are the power and environmental requirements?
The IPC uses a nominal 24 V DC supply, has an IP40 protection rating, and supports an operating temperature range of 0°C to 55°C.
10. Which monitoring and cooling features are provided?
The system includes temperature monitoring, watchdog functionality, and POWER and HDD status LEDs. Its fanless design reduces the number of moving parts.
