Name: Siemens 6AG4025-0AB10-0AA0 SIMATIC IPC527G Industrial Box PC
Brand: Siemens
SKU: 22630
Availability: InStock
Rating: 5.0 (1 reviews)

Product Overview: Expandable Industrial Computing for Automation

The Siemens SIMATIC IPC527G 6AG4025-0AB10-0AA0 is associated with the IPC527G industrial Box PC family, designed for industrial computing applications requiring network connectivity, local data storage, and hardware expansion. The corresponding Pentium G4400 configuration combines a 3.3 GHz dual-core processor with 4 GB DDR4 RAM and a 1 TB internal HDD.

Its two Gigabit Ethernet interfaces support industrial network communication, while DisplayPort and VGA outputs provide display connectivity. Multiple USB ports and serial interfaces allow integration with compatible industrial peripherals, controllers, and legacy equipment.

The IPC527G platform also supports PCI and PCI Express expansion cards, making it suitable for applications requiring additional interface or specialized hardware. The base Pentium configuration is supplied without an operating system and uses a 100–240 V AC power supply. Confirm the complete order number and hardware configuration before purchasing, as closely related IPC527G variants have different processor, memory, storage, and expansion specifications.

Technical Specifications

Parameter	Specification
Manufacturer	Siemens
Requested order number	6AG4025-0AB10-0AA0
Product family	SIMATIC IPC527G
Product type	Industrial Box PC
Processor family	Intel Pentium G4400 configuration
CPU cores / threads	2 / 2
Processor frequency	3.3 GHz
Installed memory	4 GB DDR4 RAM
Memory type	DDR4 SO-DIMM
Storage	1 TB internal HDD in the corresponding base configuration
Operating system	Not included in the corresponding base configuration
Ethernet interfaces	2 × Gigabit Ethernet RJ45
Display interfaces	1 × DisplayPort, 1 × VGA
USB interfaces	4 × USB 3.0; USB 2.0 connectivity depends on configuration
Serial interfaces	2 × configurable RS232/RS485/RS422; 2 × RS232 in the corresponding configuration
Digital I/O	1 × 8-bit DIO in the corresponding configuration
Expansion slots	2 × PCI, 1 × PCIe x16, 1 × PCIe x1 in the corresponding configuration
Power supply	100–240 V AC, 50/60 Hz
Power cable	Not included in the corresponding base configuration
Protection rating	IP20
Operating temperature	0°C to 40°C
Storage/transport temperature	-20°C to 60°C
Approximate dimensions (W × H × D)	260 × 135 × 225 mm
Mounting	Wall, portrait/book, or desktop mounting, depending on installation accessories

Recommended Companion Models

Model	Product Name	Typical Application
6AG4025-0AB10-0BB0	SIMATIC IPC527G, Pentium G4400, 4 GB RAM, 1 TB HDD, no OS	Closely related base configuration
6AG4025-0CB20-0BB0	SIMATIC IPC527G, Core i5-6500, 8 GB RAM, 1 TB HDD, no OS	Higher processing performance
6AG4025-0CE30-0BA0	SIMATIC IPC527G, Core i5-6500, 16 GB RAM, 256 GB SSD, no OS	SSD-based configuration with additional memory
6AG4025-0AE30-5AA0	SIMATIC IPC527G, Pentium G4400, 16 GB RAM, 256 GB SSD, Windows 10 Enterprise LTSC 2019	Windows-based configuration with SSD storage

Frequently Selected Alternatives

Model	Product Name	Main Difference
6AG4025-0AB10-0BB0	SIMATIC IPC527G, Pentium G4400, 4 GB RAM, 1 TB HDD	Closely related catalog configuration; verify the final order code
6AG4025-0CB20-2BB0	SIMATIC IPC527G, Core i5-6500, 8 GB RAM, 1 TB HDD, Windows 7 Ultimate	Higher-performance processor with a preinstalled operating system
6AG4025-0CE20-3BB0	SIMATIC IPC527G, Core i5-6500, 8 GB RAM, 256 GB SSD, Windows 10 Enterprise LTSB 2016	SSD storage and an earlier Windows enterprise configuration
6AG4025-0DE20-6CA0	SIMATIC IPC527G, Core i5-6500, 8 GB RAM, 256 GB SSD, Windows 10 Enterprise LTSC 2019	Alternative Windows LTSC configuration

Industrial Applications and Use Cases

Industrial automation systems requiring a desktop-class Box PC with expansion slots.
Production monitoring and data acquisition in manufacturing environments.
Industrial Ethernet and PROFINET communication with PLCs and automation equipment.
Machine vision and industrial visualization applications using compatible graphics and expansion cards.
Legacy equipment integration through serial RS232, RS485, and RS422 interfaces.
Local data logging and process monitoring using onboard hard disk storage.
Customized industrial software deployments requiring a separately installed operating system.
Control system installations that benefit from PCI and PCI Express expansion capabilities.

Key Product Advantages

Intel Pentium G4400 processor: Dual-core, four? No—two-core, two-thread processing at 3.3 GHz for compatible industrial computing workloads.
4 GB DDR4 memory: Provides onboard system memory for basic industrial applications.
1 TB internal HDD: Offers substantial local storage capacity for software, logs, and production data.
Flexible operating system selection: Supplied without an operating system for customized software deployment.
Dual Gigabit Ethernet: Two RJ45 interfaces support industrial network communication.
Multiple display outputs: DisplayPort and VGA enable connection to compatible monitors.
USB connectivity: Four USB 3.0 ports and USB 2.0 connectivity support peripheral integration.
Serial communication: Supports RS232 and selectable RS232/RS485/RS422 interfaces, depending on configuration.
Expansion capability: Includes PCI and PCI Express slots for compatible additional hardware.
AC power input: Supports 100–240 V AC operation without a supplied power cable.

Technical FAQs

1. What is the Siemens 6AG4025-0AB10-0AA0?

It belongs to the Siemens SIMATIC IPC527G industrial Box PC family, designed for industrial automation, data acquisition, machine monitoring, and applications requiring hardware expansion.

2. Which processor is used in this configuration?

The corresponding IPC527G Pentium configuration uses an Intel Pentium G4400 processor with two cores, two threads, and a clock frequency of 3.3 GHz.

3. How much memory does the system provide?

The matching Pentium G4400 configuration includes 4 GB of DDR4 RAM. The IPC527G platform supports memory expansion, subject to the specific hardware configuration.

4. What storage capacity is available?

The corresponding base configuration includes a 1 TB internal hard disk drive for the operating system, applications, and local industrial data.

5. Does this model include Windows?

The matching base configuration is supplied without an operating system. A compatible operating system and required drivers must be installed separately.

6. Which Ethernet interfaces are available?

The IPC527G provides two Gigabit Ethernet RJ45 interfaces for network communication and compatible industrial Ethernet applications.

7. Which display connections does it support?

The standard configuration provides one DisplayPort and one VGA output for compatible displays.

8. Can the IPC connect to serial industrial equipment?

Yes. The platform supports two configurable RS232/RS485/RS422 interfaces and two additional RS232 interfaces in the corresponding base configuration.

9. What expansion slots are available?

The corresponding configuration provides two PCI slots, one PCI Express x16 slot, and one PCI Express x1 slot for compatible expansion cards.

10. What are the power and environmental requirements?

The IPC527G uses a 100–240 V AC power supply at 50/60 Hz. The corresponding base configuration has an IP20 protection rating and an operating temperature range of 0°C to 40°C.
