Name: Siemens 6AG4025-0AB10-0BB0 SIMATIC IPC527G Industrial Box PC
Brand: Siemens
SKU: 22633
Availability: InStock
Rating: 5.0 (1 reviews)

Product Overview

The Siemens SIMATIC IPC527G, order number 6AG4025-0AB10-0BB0, is an industrial Box PC designed for PC-based automation, equipment integration, and production data processing. Its combination of Intel Pentium processing, internal hard-disk storage, industrial network interfaces, serial ports, and expansion slots supports a range of machine and plant applications.

The unit includes an Intel Pentium G4400 processor, 4 GB DDR4 memory, and a 1 TB HDD. Its Ethernet and serial interfaces enable communication with compatible industrial devices, while DisplayPort and VGA support local visualization. PCI and PCI Express expansion options provide additional flexibility for supported hardware.

The system is supplied without an operating system, allowing system integrators to select and install suitable software for the intended application. Confirm software compatibility and hardware requirements before deployment.

Technical Specifications

Parameter	Specification
Manufacturer	Siemens
Product family	SIMATIC IPC527G
Order number	6AG4025-0AB10-0BB0
Product type	Industrial Box PC
Processor	Intel Pentium G4400
Processor configuration	2 cores / 2 threads
Processor frequency	3.3 GHz
Processor cache	3 MB
Chipset	Intel H110
Installed memory	4 GB DDR4
Memory type	DDR4 SO-DIMM
Maximum supported memory	Up to 32 GB, subject to configuration
Storage	1 TB internal HDD
Operating system	Not included
Industrial Ethernet	2 × Gigabit Ethernet (IE/PN)
Display interfaces	1 × DisplayPort, 1 × VGA
USB interfaces	4 × USB 3.0, 2 × USB 2.0
Serial interfaces	2 × RS232/RS485/RS422 configurable, 2 × RS232
Digital I/O	1 × 8-bit DIO
Expansion slots	2 × PCI, 1 × PCIe x16, 1 × PCIe x1
Supply voltage	100/240 V AC, autoranging
Line frequency	50/60 Hz
Mounting	Wall, portrait, or desktop
Dimensions (W × H × D)	Approximately 260 × 135 × 225 mm
Net weight	Approximately 5.5 kg
Power cable	Not included in the specified configuration

Recommended Companion Models

Model	Product description
6AG4025-0CB20-0BB0	SIMATIC IPC527G, Intel Core i5-6500, 8 GB DDR4, 1 TB HDD, no operating system
6AG4025-0CB20-2BB0	SIMATIC IPC527G, Intel Core i5-6500, 8 GB DDR4, 1 TB HDD, Windows 7 Ultimate 64-bit
6AG4025-0CE20-3BB0	SIMATIC IPC527G, Intel Core i5-6500, 8 GB DDR4, 256 GB SSD, Windows 10 Enterprise LTSB 2016
6AG4025-0DF20-4BB0	SIMATIC IPC527G, Intel Core i7-6700, 8 GB DDR4, 512 GB SSD, Windows 10 Enterprise LTSB 2016

Frequently Selected Alternatives

Model	Product description
6AG4025-0CE20-5CA0	SIMATIC IPC527G, Intel Core i5-6500, 8 GB DDR4, 256 GB SSD, Windows 10 Enterprise LTSC 2019
6AG4025-0CE30-0BA0	SIMATIC IPC527G, Intel Core i5-6500, 16 GB DDR4, 256 GB SSD, no operating system
6AG4025-0AB20-0CA0	SIMATIC IPC527G, Intel Pentium G4400, 8 GB DDR4, 1 TB HDD, no operating system
6AG4025-0DE20-6CA0	SIMATIC IPC527G, Intel Core i5-6500, 8 GB DDR4, 256 GB SSD, Windows 10 Enterprise LTSC 2019

Typical Industrial Applications

Industrial automation systems requiring reliable PC-based computing.
Production line monitoring and machine-level data processing.
Industrial visualization and operator-interface applications.
Data acquisition and communication between automation equipment.
System integration requiring Ethernet, serial communication, and expansion-card support.
Legacy industrial applications that need a compatible Windows or Linux environment installed separately.

Key Product Advantages

Dual-core processing: Intel Pentium G4400 processor operating at 3.3 GHz.
Integrated storage: 1 TB internal hard disk drive for applications and industrial data.
DDR4 memory: 4 GB installed memory, with platform expansion options.
Industrial connectivity: Two Gigabit Ethernet ports, serial interfaces, USB ports, DisplayPort, and VGA.
Expansion flexibility: Two PCI slots, one PCIe x16 slot, and one PCIe x1 slot.
Flexible installation: Supports wall mounting, portrait mounting, and desktop placement.
Industrial power input: 100/240 V AC autoranging power supply; power cable is not included in the specified configuration.

Technical FAQs

1. What is Siemens 6AG4025-0AB10-0BB0?

It is a Siemens SIMATIC IPC527G industrial Box PC equipped with an Intel Pentium G4400 processor, 4 GB DDR4 memory, a 1 TB internal HDD, and no preinstalled operating system.

2. Which processor does this industrial PC use?

The unit uses an Intel Pentium G4400 dual-core, two-thread processor running at 3.3 GHz, with 3 MB cache.

3. How much memory and storage are included?

The standard configuration includes 4 GB DDR4 memory and a 1 TB internal hard disk drive.

4. Does the product include an operating system?

No. This order configuration is supplied without an operating system. A compatible operating system and required drivers must be installed separately.

5. Which Ethernet connections are available?

The unit provides two Gigabit Ethernet ports suitable for industrial network communication and integration with compatible automation systems.

6. Which display connections does it support?

The IPC527G configuration includes one DisplayPort and one VGA interface for compatible display devices.

7. What USB ports are available?

The specified configuration includes four USB 3.0 ports and two USB 2.0 ports.

8. Does it support serial communication?

Yes. The configuration includes two RS232 interfaces and two additional serial interfaces configurable for RS232, RS485, or RS422 operation.

9. Can expansion cards be installed?

Yes. The specified configuration provides two PCI slots, one PCI Express x16 slot, and one PCI Express x1 slot for compatible expansion hardware.

10. What should be checked before replacing an existing unit?

Verify the full order number, operating system, installed applications, interface requirements, expansion cards, storage condition, and power arrangement to ensure a suitable replacement.
