The Siemens SIMATIC IPC527G, order number 6AG4025-0AB20-0CA0, is an industrial Box PC intended for PC-based automation, machine integration, production monitoring, and industrial data processing.
This configuration combines an Intel Pentium G4400 processor with 8 GB DDR4 memory and a 1 TB internal hard disk drive. Two Gigabit Ethernet interfaces support industrial network communication, while DisplayPort and VGA provide local display connectivity. Serial interfaces support compatible industrial equipment, and the configured PCI Express slots provide options for additional hardware.
The system is supplied without a preinstalled operating system. Software installation, driver compatibility, and application requirements should therefore be assessed before commissioning.
The product is listed as discontinued, so buyers planning a new installation or replacement should confirm remaining stock and service options. When selecting an alternative, compare the processor, storage, interface layout, expansion slots, and operating-system requirements rather than relying on the product family name alone.
Technical Specifications
Parameter
Specification
Manufacturer
Siemens
Product family
SIMATIC IPC527G
Order number
6AG4025-0AB20-0CA0
Product type
Industrial Box PC
Processor
Intel Pentium G4400
Processor cores / threads
2 / 2
Processor frequency
3.3 GHz
Processor cache
3 MB
Chipset
Intel H110
Installed memory
8 GB DDR4
Maximum supported memory
Up to 32 GB for the platform
Storage
1 TB HDD
Operating system
Not included
Ethernet
2 × Gigabit Ethernet (IE/PN)
Display interfaces
1 × DisplayPort, 1 × VGA
USB interfaces
4 × USB 3.0; additional USB 2.0 availability depends on configuration
Serial interfaces
2 × RS232/RS485/RS422 configurable
Expansion slots
1 × PCIe x16, 1 × PCIe x4, 2 × PCIe x1
Power supply
100/240 V AC, autoranging
Supply frequency
50/60 Hz
Mounting options
Wall, portrait, desktop
Protection rating
IP20
Net weight
Approximately 5 kg
Product lifecycle
Discontinued
Recommended Companion Models
Model
Product description
6AG4025-0AB10-0BB0
SIMATIC IPC527G, Intel Pentium G4400, 4 GB DDR4, 1 TB HDD, no operating system
6AG4025-0CB20-0BB0
SIMATIC IPC527G, Intel Core i5-6500, 8 GB DDR4, 1 TB HDD, no operating system
Factory automation: Supports PC-based computing for manufacturing and machine automation environments.
Production monitoring: Processes operational information for machine status tracking and production reporting.
Industrial data processing: Provides local storage and computing resources for production data and application records.
Machine integration: Connects compatible industrial devices through Ethernet and supported serial interfaces.
Operator visualization: Supports local display applications through DisplayPort and VGA.
Equipment modernization: Provides an industrial computing platform for applications requiring verified hardware and software compatibility.
Key Strengths for Industrial Integration
Intel Pentium processing: Features an Intel Pentium G4400 dual-core processor running at 3.3 GHz.
Expanded memory configuration: Includes 8 GB DDR4 memory for industrial computing and multitasking workloads.
Large internal storage: Provides a 1 TB HDD for applications and operational data.
Industrial network connectivity: Includes two Gigabit Ethernet interfaces for compatible network integration.
Flexible expansion architecture: Provides PCI Express and PCI expansion options, subject to the configured hardware.
Display and peripheral support: Includes DisplayPort, VGA, and USB connectivity.
Operating-system flexibility: Supplied without a preinstalled operating system, allowing software deployment to be planned separately.
Technical FAQs
1. What is Siemens 6AG4025-0AB20-0CA0?
It is a Siemens SIMATIC IPC527G industrial Box PC configured with an Intel Pentium G4400 processor, 8 GB DDR4 memory, a 1 TB HDD, and no preinstalled operating system.
2. Which processor does this model use?
The system uses an Intel Pentium G4400 processor with two cores, two threads, a 3.3 GHz operating frequency, and 3 MB cache.
3. How much RAM is installed?
The standard configuration includes 8 GB of DDR4 memory, suitable for compatible industrial applications and data-processing workloads.
4. What storage capacity does it provide?
The system includes a 1 TB internal hard disk drive for operating data, applications, and industrial records.
5. Does it come with an operating system?
No. This configuration is supplied without an operating system, so the integrator must select and install a compatible system and required drivers.
6. Which Ethernet interfaces are available?
The unit provides two Gigabit Ethernet interfaces for industrial network communication and integration with compatible devices.
7. What display connections does it support?
The system includes one DisplayPort and one VGA output for compatible displays and local visualization applications.
8. Which serial communication interfaces are available?
The documented configuration includes two serial interfaces configurable for RS232, RS485, or RS422 operation. Confirm the physical interface arrangement before connecting equipment.
9. What expansion slots are provided?
The specified configuration includes one PCIe x16 slot, one PCIe x4 slot, and two PCIe x1 slots. Check card dimensions and compatibility before installation.
10. Is this model still available as a standard product?
The product listing identifies this order number as discontinued. Availability of remaining stock, repair, and replacement services should be confirmed before procurement.
