Product Overview
The Siemens SIMATIC IPC527G, model 6AG4025-0CB20-2BB0, is an industrial Box PC designed for machine-level computing, manufacturing data processing, and automation-system integration. It combines an Intel Core i5-6500 processor with 8 GB DDR4 memory and a 1 TB internal hard drive to support established industrial software and data-processing workloads.
A key characteristic of this configuration is its preinstalled Windows 7 Ultimate 64-bit operating system, making it relevant to existing installations that depend on legacy applications. Because Windows 7 is no longer supported through standard Microsoft security updates, deployment should include appropriate network isolation, security controls, and application compatibility planning.
For industrial connectivity, the IPC527G provides two Gigabit Ethernet interfaces, DisplayPort and VGA outputs, USB ports, configurable serial interfaces, and an 8-bit digital I/O interface. Its PCI and PCI Express slots allow integration with compatible expansion cards.
The system supports wall, portrait, and desktop mounting. Its AC power supply accommodates 100/240 V input, while the power cable must be sourced separately.
Technical Specifications
Parameter | Specification |
|---|---|
Manufacturer | Siemens |
Product family | SIMATIC IPC527G |
Order number | 6AG4025-0CB20-2BB0 |
Product type | Industrial Box PC |
Processor | Intel Core i5-6500 |
CPU cores / threads | 4 cores / 4 threads |
Processor frequency | 3.2 GHz base, up to 3.6 GHz |
Processor cache | 6 MB |
Chipset | Intel H110 |
Graphics | Integrated Intel HD Graphics 530 |
Memory | 8 GB DDR4 |
Maximum memory capacity | 32 GB |
Storage | 1 TB internal HDD |
Operating system | Windows 7 Ultimate 64-bit, multilingual UI |
Industrial Ethernet | 2 × Gigabit Ethernet, RJ45 |
Display interfaces | 1 × DisplayPort, 1 × VGA |
USB interfaces | 4 × USB 3.0, 2 × external USB 2.0; additional internal USB 2.0 connection |
Configurable serial interfaces | 2 × RS232/RS485/RS422 |
Additional serial interfaces | 2 × RS232 |
Digital I/O | 1 × 8-bit DIO |
PCI expansion | 2 × PCI |
PCI Express expansion | 1 × PCIe x16, 1 × PCIe x1 |
Power supply | 100/240 V AC, autoranging, 50/60 Hz |
Power cable | Not included |
Mounting | Wall, portrait, or desktop mounting |
Net weight | Approximately 5.49 kg |
Product lifecycle | Active in the Siemens catalog listing; verify current availability before ordering |
Recommended Companion Models
Model | Product description |
|---|---|
6AG4025-0CB20-0BB0 | SIMATIC IPC527G with Intel Core i5-6500, 8 GB DDR4, 1 TB HDD, without operating system |
6AG4025-0CE20-2BB0 | SIMATIC IPC527G with Intel Core i5-6500, 8 GB DDR4, 256 GB SSD, Windows 7 Ultimate 64-bit |
6AG4025-0CE20-3BB0 | SIMATIC IPC527G with Intel Core i5-6500, 8 GB DDR4, 256 GB SSD, Windows 10 Enterprise LTSB 2016 |
6AG4025-0DF20-2BB0 | SIMATIC IPC527G with Intel Core i7-6700, 8 GB DDR4, 512 GB SSD, Windows 7 Ultimate 64-bit |
Frequently Considered Alternatives
Model | Product description |
|---|---|
6AG4025-0CE20-5CA0 | SIMATIC IPC527G with Intel Core i5-6500, 8 GB DDR4, 256 GB SSD, Windows 10 Enterprise LTSC 2019 |
6AG4025-0DE20-6CA0 | SIMATIC IPC527G with Intel Core i5-6500, 8 GB DDR4, 256 GB SSD, Windows 10 Enterprise LTSC 2019 |
6AG4025-0DF20-4BB0 | SIMATIC IPC527G with Intel Core i7-6700, 8 GB DDR4, 512 GB SSD, Windows 10 Enterprise LTSB 2016 |
6AG4025-0AB20-0CA0 | SIMATIC IPC527G with Intel Pentium G4400, 8 GB DDR4, 1 TB HDD, without operating system |
