Brand:Siemens Item No.:6AG1313-6CG04-7AB0 Product Origin:Germany Product Dimensions:130 × 125 × 80 mm Product Weight:0.576 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG1313-6CG04-7AB0 SIPLUS S7-300 CPU 313C-2 DP is designed for industrial control systems that require integrated digital I/O and PROFIBUS DP communication. With 16 digital inputs, 16 digital outputs, 128 KB of work memory, and three high-speed counters, it provides a compact solution for machine automation and distributed control applications.
Based on the standard SIMATIC S7-300 CPU 313C-2 DP, this SIPLUS version features conformal coating and an extended operating temperature range of -25°C to +70°C. Its MPI and PROFIBUS DP interfaces support engineering access and integration with compatible distributed I/O systems.
For equipment maintenance, spare-parts procurement, and control-system upgrades, the CPU is suitable for installations designed around the S7-300 platform. Before ordering, verify the exact part number, network configuration, memory card, and environmental requirements.
Technical Specifications
Parameter
Specification
Brand
Siemens
Model
6AG1313-6CG04-7AB0
Product Type
SIPLUS S7-300 CPU 313C-2 DP
Product Series
SIMATIC S7-300
Base Model
6ES7313-6CG04-0AB0
CPU Type
Compact PLC CPU
Work Memory
128 KB
Digital Inputs
16
Digital Outputs
16
Analog Inputs
None integrated
Analog Outputs
None integrated
High-Speed Counters
3
Maximum Counting Frequency
30 kHz
Communication Interfaces
MPI, PROFIBUS DP
PROFIBUS DP Function
Master/slave capability
Rated Supply Voltage
24 V DC
Permissible Supply Voltage
19.2–28.8 V DC
Operating Temperature
-25°C to +70°C
Environmental Protection
Conformal coating
Front Connector
1 × 40-pin
Memory Card
SIMATIC Micro Memory Card required
Programming Software
Compatible STEP 7
Dimensions
130 × 125 × 80 mm (5.12 × 4.92 × 3.15 in)
Weight
0.576 kg (1.27 lb)
Recommended Related Models
The following models belong to the Siemens SIMATIC S7-300 or SIPLUS S7-300 product families. Their I/O configurations, communication capabilities, and environmental specifications may differ. Verify the required functionality before selecting an alternative.
Model
Product Type
Description
6AG1313-6CG04-2AY0
SIPLUS CPU 313C-2 DP
Related CPU 313C-2 DP version with railway-related environmental specifications
6ES7313-6CG04-0AB0
CPU 313C-2 DP
Standard SIMATIC S7-300 base model
6AG1313-5BG04-7AB0
SIPLUS CPU 313C
Compact CPU with integrated digital and analog I/O
6AG1314-6CH04-7AB0
SIPLUS CPU 314C-2 DP
Compact CPU with integrated I/O and PROFIBUS DP
6AG1315-2AH14-7AB0
SIPLUS CPU 315-2 DP
CPU with PROFIBUS DP communication
Popular Related Models
Model
Product Type
Description
6AG1312-5BF04-7AB0
SIPLUS CPU 312C
Compact CPU for smaller automation applications
6AG1313-5BG04-7AB0
SIPLUS CPU 313C
Compact CPU with integrated digital and analog I/O
6AG1314-1AG14-7AB0
SIPLUS CPU 314
S7-300 CPU for broader control requirements
6AG1315-2AH14-7AB0
SIPLUS CPU 315-2 DP
CPU with PROFIBUS DP communication
6AG1315-2EH14-7AB0
SIPLUS CPU 315-2 PN/DP
CPU with PROFINET and PROFIBUS DP connectivity
Applications
The Siemens 6AG1313-6CG04-7AB0 is a SIPLUS SIMATIC S7-300 CPU 313C-2 DP compact programmable logic controller (PLC). Based on the standard 6ES7313-6CG04-0AB0, it combines integrated digital I/O, MPI communication, and a PROFIBUS DP interface for industrial automation applications.
Featuring conformal coating and an extended operating temperature range of -25°C to +70°C, this CPU is designed for industrial environments that require additional environmental protection. Its integrated fieldbus interface supports communication with compatible distributed I/O stations and automation devices.
Typical applications include:
Industrial machine automation and sequence control
Distributed I/O systems using PROFIBUS DP
Digital signal acquisition and actuator control
High-speed counting and frequency measurement
Production equipment and process automation
Compact control systems with fieldbus communication
Maintenance and upgrades of existing SIMATIC S7-300 installations
Advantages
Integrated digital I/O: Provides 16 digital inputs and 16 digital outputs.
PROFIBUS DP connectivity: Supports communication with compatible distributed I/O devices and fieldbus equipment.
MPI communication: Enables programming and communication with compatible SIMATIC devices.
128 KB work memory: Supports control programs and associated runtime data.
High-speed counters: Includes three high-speed counting channels with frequencies up to 30 kHz.
Conformal coating: Provides additional protection for electronic components in challenging environments.
Extended temperature range: Designed for operation from -25°C to +70°C.
24 V DC power supply: Uses an industrial DC supply architecture with a permissible input range of 19.2–28.8 V DC.
Compact controller design: Combines processing, digital I/O, and PROFIBUS DP communication in one module.
Established automation platform: Suitable for compatible SIMATIC S7-300 control architectures.
Technical FAQs
Q1: What is the Siemens 6AG1313-6CG04-7AB0 CPU?
It is a SIPLUS SIMATIC S7-300 CPU 313C-2 DP compact PLC with integrated digital I/O, MPI communication, a PROFIBUS DP interface, and conformal coating.
Q2: How many digital inputs and outputs are integrated?
The CPU provides 16 digital inputs and 16 digital outputs for connecting compatible sensors, switches, and actuators.
Q3: Does this CPU support analog I/O?
No. The 6AG1313-6CG04-7AB0 does not include integrated analog inputs or analog outputs. Compatible external analog I/O modules are required for analog signal processing.
Q4: What communication interfaces does it provide?
It includes an MPI interface and an integrated PROFIBUS DP interface. The PROFIBUS DP interface supports master or slave operation according to the configured system architecture.
Q5: How much work memory is available?
The CPU has 128 KB of integrated work memory. A compatible SIMATIC Micro Memory Card is required for operation and provides load memory for the user program.
Q6: Does the CPU support high-speed counting?
Yes. It features three high-speed counters with frequencies up to 30 kHz. Actual performance depends on the signal configuration and operating conditions.
Q7: What is the required power supply?
The rated supply voltage is 24 V DC, with a permissible range of 19.2–28.8 V DC. The power supply and protective devices should be selected according to the installation requirements.
Q8: What is the operating temperature range?
The specified operating temperature range is -25°C to +70°C. Installation conditions and other environmental limits should be checked against the application requirements.
Q9: Which software is used to program this CPU?
The CPU is configured using compatible Siemens STEP 7 software. Supported engineering options include STEP 7 V5.5 SP1 or later, or STEP 7 V5.3 SP2 or later with the appropriate hardware support package.
Q10: What should be checked before replacing this CPU?
Confirm the complete order number, firmware, STEP 7 project, Micro Memory Card, MPI settings, PROFIBUS DP configuration, I/O wiring, and environmental requirements. Verify compatibility with the existing control system before installation.
