Name: Siemens 6AG4025-0CE20-5CA0 Reliable Industrial Box PC
Brand: Siemens
SKU: 22704
Availability: InStock
Rating: 5.0 (1 reviews)

Product Overview: SIMATIC IPC527G Industrial Computing Solution

The Siemens 6AG4025-0CE20-5CA0 is a SIMATIC IPC527G industrial Box PC configured with an Intel Core i5-6500 processor, 8 GB DDR4 memory, a 256 GB SSD, and Windows 10 IoT Enterprise LTSC 2019.

Its combination of industrial networking, serial communication, display connectivity, and PCI Express expansion makes it suitable for automation systems that require a configurable industrial computer. The solid-state storage supports responsive software access, while the available interfaces help integrate the system with existing production equipment.

The enclosure supports multiple mounting orientations, allowing integration into suitable industrial workspaces and equipment installations.

Technical Specifications

Parameter	Specification
Manufacturer	Siemens
Article number	6AG4025-0CE20-5CA0
Product family	SIMATIC IPC527G
Product type	Industrial Box PC
Processor	Intel Core i5-6500
Processor cores / threads	4 / 4
Processor frequency	3.2 GHz base, up to 3.6 GHz
Cache	6 MB
Chipset	Intel H110
Installed memory	8 GB DDR4
Maximum memory	Up to 32 GB
Storage	256 GB internal SSD
Operating system	Windows 10 IoT Enterprise LTSC 2019, 64-bit, MUI
Ethernet	2 × Gigabit Ethernet
Display interfaces	1 × DisplayPort, 1 × VGA
USB interfaces	4 × USB 3.0, 2 × USB 2.0
Configurable serial interfaces	2 × RS232/RS485/RS422
Additional serial interfaces	2 × RS232
Digital I/O	1 × 8-bit DIO
Expansion slots	1 × PCIe x16, 1 × PCIe x4, 2 × PCIe x1
Power supply	100/240 V AC, 50/60 Hz
Enclosure dimensions	260 × 135 × 225 mm
Protection rating	IP20
Operating temperature	0°C to 45°C
Storage temperature	-20°C to 60°C
Mounting options	Desktop, wall, portrait
Net weight	Approximately 7 kg

Recommended Companion Models

Model	Product Name	Typical Application
6AG4025-0CE20-3BB0	SIMATIC IPC527G, Core i5, 256 GB SSD, Windows 10 Enterprise LTSB 2016	Existing systems using the 2016 LTSB environment
6AG4025-0DE20-6CA0	SIMATIC IPC527G, Core i7, 256 GB SSD, Windows 10 Enterprise LTSC 2019	Applications requiring a higher-tier processor
6AG4025-0CE20-2BB0	SIMATIC IPC527G, Core i5, 256 GB SSD, Windows 7 Ultimate	Compatible legacy software environments
6AG4025-0CB20-0BB0	SIMATIC IPC527G, Core i5, 1 TB HDD, no OS	Applications prioritizing larger HDD capacity

Frequently Considered Alternatives

Model	Product Name	Key Difference
6AG4025-0DF20-4BB0	SIMATIC IPC527G, Core i7, 512 GB SSD, Windows 10 Enterprise LTSB 2016	Higher processor tier and larger SSD
6AG4025-0CB20-2BB0	SIMATIC IPC527G, Core i5, 1 TB HDD, Windows 7 Ultimate	HDD-based storage and legacy operating system
6AG4025-0CE20-0BA0	SIMATIC IPC527G, Core i5, 256 GB SSD, no OS	Operating system can be selected separately
6AG4025-0AB10-0BB0	SIMATIC IPC527G, Pentium G4400, 1 TB HDD, no OS	Lower-tier processor configuration

Industrial Applications and Use Cases

Industrial automation and machine-control support systems.
Manufacturing data collection, production monitoring, and equipment diagnostics.
HMI visualization and industrial operator-station applications.
Industrial Ethernet and PROFINET network connectivity.
Legacy equipment integration using configurable serial communication ports.
Industrial applications requiring Windows-based software and solid-state storage.

Key Benefits and Features

Intel Core i5 processing: The quad-core Intel Core i5-6500 supports industrial computing and multitasking.
Fast solid-state storage: The 256 GB internal SSD provides responsive system and application access.
Windows IoT Enterprise: Windows 10 IoT Enterprise LTSC 2019 64-bit supports compatible industrial software.
Industrial network connectivity: Two Gigabit Ethernet interfaces support industrial network integration.
Flexible serial communication: Selectable RS232/RS485/RS422 interfaces support a range of industrial devices.
Multiple expansion options: PCI Express slots allow compatible hardware expansion.
Flexible mounting: Supports desktop, wall, and portrait installation.
Industrial enclosure: IP20 protection is suitable for appropriate protected installation environments.

Technical FAQs

Q1: What is Siemens 6AG4025-0CE20-5CA0?

It is a Siemens SIMATIC IPC527G industrial Box PC designed for automation, manufacturing, visualization, and industrial data-processing applications.

Q2: Which processor does this model use?

It uses an Intel Core i5-6500 processor with four cores, four threads, a 3.2 GHz base frequency, up to 3.6 GHz frequency, and 6 MB cache.

Q3: How much memory is installed?

The unit is configured with 8 GB of DDR4 memory.

Q4: What storage capacity does it provide?

It includes a 256 GB internal solid-state drive for the operating system, applications, and local industrial data.

Q5: Which operating system is preinstalled?

This configuration includes Windows 10 IoT Enterprise LTSC 2019, 64-bit, with a multilingual user interface.

Q6: Does it support industrial Ethernet communication?

Yes. It provides two Gigabit Ethernet interfaces for industrial networking and compatible PROFINET-related applications.

Q7: Which display connections are available?

The IPC527G configuration includes one DisplayPort and one VGA interface for compatible monitors.

Q8: Which USB and serial interfaces are included?

It provides four USB 3.0 ports, two USB 2.0 ports, two selectable RS232/RS485/RS422 interfaces, and two additional RS232 interfaces.

Q9: What expansion slots are available?

This configuration provides one PCIe x16 slot, one PCIe x4 slot, and two PCIe x1 slots, allowing compatible expansion cards to be installed.

Q10: What power supply and mounting options does it support?

It supports 100/240 V AC, 50/60 Hz, and can be installed on a desktop, wall, or in portrait orientation. The supplied configuration does not include a power line cable.
