Siemens 6AG4025-0CE30-3AA0 Efficient Industrial Box PC
Siemens 6AG4025-0CE30-3AA0 Efficient Industrial Box PC
0.0
Points
Brand:Siemens Item No.:6AG4025-0CE30-3AA0 Product Origin: Germany Product Dimensions:260 × 135 × 225 mm Product Weight:5 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens 6AG4025-0CE30-3AA0 combines an Intel Core i5-6500 processor, 16 GB DDR4 memory, a 256 GB SSD, and Windows 10 Enterprise 2016 LTSB in an industrial Box PC platform.
Its combination of computing performance, industrial Ethernet, display connectivity, and serial communication makes it suitable for machine visualization, production monitoring, industrial measurement, and compatible automation software. The 16 GB memory configuration offers more capacity than standard 8 GB variants for applications that use multiple services or process larger datasets.
The system provides a PCIe x16 expansion slot for compatible add-on hardware. When integrating it into an existing installation, verify software compatibility, operating-system support, and any peripheral driver requirements.
Technical Specifications
Parameter
Specification
Manufacturer
Siemens
Article number
6AG4025-0CE30-3AA0
Product family
SIMATIC IPC527G
Product type
Industrial Box PC
Processor
Intel Core i5-6500
Processor cores / threads
4 / 4
Processor frequency
3.2 GHz base, up to 3.6 GHz
Cache
6 MB
Installed memory
16 GB DDR4
Maximum memory
Up to 32 GB for the family
Storage
256 GB internal SSD
Operating system
Windows 10 Enterprise 2016 LTSB MUI, 64-bit
Ethernet
2 × Gigabit Ethernet
Display interfaces
1 × DisplayPort, 1 × VGA
USB interfaces
4 × USB 3.0
Serial interfaces
2 × selectable RS232/RS485/RS422
Expansion slots
1 × PCIe x16
Power supply
100/240 V AC, 50/60 Hz
Enclosure dimensions
Approximately 260 × 135 × 225 mm
Protection rating
IP20
Operating temperature
Up to 45°C, according to family specifications
Mounting options
Desktop, wall, portrait
Net weight
Approximately 5 kg
Recommended Companion Models
Model
Product Name
Typical Application
6AG4025-0CE30-0BA0
SIMATIC IPC527G, Core i5-6500, 16 GB RAM, 256 GB SSD, without OS
Projects requiring a separately installed operating system
16 GB DDR4 memory: Provides additional capacity for demanding software and multiple concurrent tasks.
256 GB SSD storage: Supports responsive application loading and local data access.
Windows 10 Enterprise: Preinstalled Windows 10 Enterprise 2016 LTSB MUI, 64-bit.
Industrial connectivity: Two Gigabit Ethernet ports, DisplayPort, VGA, USB 3.0, and configurable serial interfaces.
PCI Express expansion: One PCIe x16 slot in this configuration supports compatible expansion hardware.
Flexible installation: Designed for desktop, wall, and portrait mounting.
Industrial construction: The SIMATIC IPC527G platform is designed for integration into industrial environments with suitable enclosure protection.
Technical FAQs
Q1: What is Siemens 6AG4025-0CE30-3AA0?
It is a Siemens SIMATIC IPC527G industrial Box PC configured for industrial computing, manufacturing visualization, and automation-related applications.
Q2: Which processor does this model use?
It uses an Intel Core i5-6500 processor with four cores, four threads, a 3.2 GHz base frequency, up to 3.6 GHz frequency, and 6 MB cache.
Q3: How much memory is installed?
This configuration includes 16 GB of DDR4 memory, supporting multitasking and applications with higher memory requirements.
Q4: What storage capacity does it provide?
It includes a 256 GB internal SSD for the operating system, industrial applications, and local data storage.
Q5: Which operating system is installed?
The model is configured with Windows 10 Enterprise 2016 LTSB MUI, 64-bit, with a multilingual interface.
Q6: Which Ethernet connections are available?
It provides two Gigabit Ethernet interfaces for industrial networking and compatible PROFINET-related communication.
Q7: Which display interfaces are supported?
The system provides one DisplayPort and one VGA interface for connecting compatible monitors.
Q8: Which USB and serial interfaces are available?
The configuration includes four USB 3.0 ports and two selectable RS232/RS485/RS422 interfaces. Additional interfaces may depend on the installed expansion options.
Q9: What expansion slots does this model provide?
This configuration includes one PCIe x16 slot without additional specified expansion hardware. Confirm card dimensions and compatibility before installation.
Q10: What power supply and mounting options does it support?
It supports a 100/240 V AC power supply at 50/60 Hz and offers desktop, wall, and portrait mounting options. Confirm the supplied power cable and installation requirements before commissioning.
