Name: Siemens 6AG4025-0DB30-4BA0 Advanced Industrial Box PC
Brand: Siemens
SKU: 22726
Availability: InStock
Rating: 5.0 (1 reviews)

Product Overview: SIMATIC IPC527G Industrial Computing System

The Siemens SIMATIC IPC527G is an industrial box PC platform designed for automation, visualization, data acquisition, and equipment integration. Model 6AG4025-0DB30-4BA0 combines an Intel Core i7-6700 processor with 16 GB DDR4 memory, a 1 TB hard drive, and Windows 10 Enterprise 2016 LTSB 64-bit.

Its combination of network, display, USB, serial, PCI, and PCI Express interfaces supports integration with a broad range of industrial equipment. The multilingual operating system configuration is suited to compatible Windows-based industrial applications, including systems that benefit from a consistent long-term software environment.

Technical Specifications

Specification	Details
Manufacturer	Siemens
Product family	SIMATIC IPC527G
Model number	6AG4025-0DB30-4BA0
Product type	Industrial box PC
Processor	Intel Core i7-6700
Processor cores / threads	4 cores / 8 threads
Processor frequency	3.4 GHz base, up to 4.0 GHz turbo
Cache	8 MB
Chipset	Intel H110
Memory	16 GB DDR4
Storage	1 TB internal HDD
Operating system	Windows 10 Enterprise 2016 LTSB, multilingual 64-bit
Ethernet	2 × Gigabit Ethernet
Display outputs	1 × DisplayPort, 1 × VGA
USB	4 × USB 3.0
Serial interfaces	2 × selectable RS232/RS485/RS422
Expansion slots	1 × PCIe x16, 1 × PCIe x1, 2 × PCI
Graphics	Integrated Intel HD Graphics 530
Power supply	100/240 V AC, 50/60 Hz
Protection rating	IP20
Operating temperature	0°C to 40°C for the documented IPC527G platform
Storage temperature	-20°C to 60°C for the documented IPC527G platform
Dimensions	Approximately 260 × 135 × 225 mm
Mounting	Wall, book-style, or desktop mounting

Recommended Companion Models

Model	Product description
Siemens 6AG4025-0DB30-2AA0	IPC527G with Core i7-6700, 16 GB DDR4, 1 TB HDD, and Windows 7 Ultimate 64-bit
Siemens 6AG4025-0DB30-6CD0	IPC527G configuration associated with Core i7 processing, 16 GB DDR4, 1 TB HDD, and Windows 10 Enterprise LTSC 2019
Siemens 6AG4025-0DF20-4BB0	IPC527G with Core i7-6700, 8 GB DDR4, 512 GB SSD, and Windows 10 Enterprise 2016 LTSB
Siemens 6AG4025-0CE30-0BA0	IPC527G with Core i5-6500, 16 GB DDR4, 256 GB SSD, and no operating system

Frequently Considered Alternatives

Model	Product description
Siemens 6AG4025-0CB20-2BB0	IPC527G with Core i5-6500, 8 GB DDR4, 1 TB HDD, and Windows 7 Ultimate 64-bit
Siemens 6AG4025-0CE20-3BB0	IPC527G with Core i5-6500, 8 GB DDR4, 256 GB SSD, and Windows 10 Enterprise 2016 LTSB
Siemens 6AG4025-0CE20-5CA0	IPC527G with Core i5-6500, 8 GB DDR4, 256 GB SSD, and Windows 10 Enterprise LTSC 2019
Siemens 6AG4025-0DF20-2BB0	IPC527G with Core i7-6700, 8 GB DDR4, 512 GB SSD, and Windows 7 Ultimate 64-bit

Applications and Use Cases

Industrial automation and machine-level computing in manufacturing environments.
Production monitoring, industrial data acquisition, and process visualization.
Human-machine interface (HMI) systems and operator workstations.
Communication with PLCs, industrial controllers, and network-connected equipment.
Industrial applications requiring Windows-based software and flexible expansion options.

Key Benefits and Features

Intel Core i7 performance: The Core i7-6700 processor supports demanding industrial computing and multitasking.
16 GB DDR4 memory: Provides capacity for industrial applications, visualization, and concurrent workloads.
1 TB hard drive: Offers local storage for software, production records, and operational data.
Windows 10 Enterprise: Includes Windows 10 Enterprise 2016 LTSB multilingual 64-bit for compatible industrial applications.
Flexible connectivity: Provides Gigabit Ethernet, DisplayPort, VGA, USB 3.0, and configurable serial interfaces.
Expansion flexibility: Includes PCI and PCI Express slots for compatible industrial expansion cards.

Technical FAQs

1. What is the Siemens 6AG4025-0DB30-4BA0?

It is a Siemens SIMATIC IPC527G industrial box PC designed for industrial automation, machine-level computing, and data-processing applications.

2. Which processor does this model use?

It uses an Intel Core i7-6700 processor with four cores, eight threads, a 3.4 GHz base frequency, and a maximum turbo frequency of 4.0 GHz.

3. How much memory is installed?

This configuration includes 16 GB of DDR4 memory.

4. What storage capacity does it provide?

It includes a 1 TB internal hard disk drive for applications, operating-system files, and industrial data.

5. Which operating system is included?

The configured operating system is Windows 10 Enterprise 2016 LTSB multilingual 64-bit, supporting German, English, French, Spanish, and Italian.

6. Does it support industrial Ethernet?

Yes. It includes two Gigabit Ethernet interfaces suitable for industrial networking and communication with compatible devices.

7. Which display connections are available?

The unit provides one DisplayPort and one VGA interface for connecting compatible displays.

8. Can it communicate with serial industrial devices?

Yes. It includes two selectable RS232/RS485/RS422 interfaces for connecting compatible serial equipment.

9. Which expansion slots are available?

The listed configuration includes one PCIe x16 slot, one PCIe x1 slot, and two PCI slots.

10. What should be checked before installation?

Verify software compatibility, installed expansion cards, network requirements, serial interface settings, ventilation, and the condition of the supplied unit.
