Name: Siemens 6AG4025-0DB30-4BB0 High-Performance Industrial Box PC
Brand: Siemens
SKU: 22728
Availability: InStock
Rating: 5.0 (1 reviews)

Product Overview: SIMATIC IPC527G Industrial Computing System

The Siemens SIMATIC IPC527G is an industrial box PC designed for automation, visualization, data acquisition, and equipment integration. Model 6AG4025-0DB30-4BB0 is listed with an Intel Core i7-6700 processor, 16 GB DDR4 memory, a 1 TB hard drive, and Windows 10 Enterprise 2016 LTSB 64-bit.

Its combination of networking, display, USB, serial, PCI, and PCI Express interfaces supports integration with a variety of industrial equipment. The multilingual operating system configuration can accommodate compatible Windows-based applications across multiple language environments.

Technical Specifications

Specification	Details
Manufacturer	Siemens
Product family	SIMATIC IPC527G
Model number	6AG4025-0DB30-4BB0
Product type	Industrial box PC
Processor	Intel Core i7-6700
Processor cores / threads	4 cores / 8 threads
Processor frequency	3.4 GHz base, up to 4.0 GHz turbo
Cache	8 MB
Chipset	Intel H110
Memory	16 GB DDR4
Storage	1 TB internal HDD
Operating system	Windows 10 Enterprise 2016 LTSB, multilingual 64-bit
Graphics	Integrated Intel HD Graphics 530
Ethernet	2 × Gigabit Ethernet
Display outputs	1 × DisplayPort, 1 × VGA
USB	4 × USB 3.0; USB 2.0 availability depends on configuration
Serial interfaces	2 × configurable RS232/RS485/RS422
Expansion slots	1 × PCIe x16, 1 × PCIe x1, 2 × PCI
Power supply	100/240 V AC, 50/60 Hz
Protection rating	IP20
Operating temperature	0°C to 40°C for the documented IPC527G platform
Storage temperature	-20°C to 60°C for the documented IPC527G platform
Dimensions	Approximately 260 × 135 × 225 mm
Mounting	Wall, book-style, or desktop mounting

Recommended Companion Models

Model	Product description
Siemens 6AG4025-0DB30-2AA0	IPC527G with Core i7-6700, 16 GB DDR4, 1 TB HDD, and Windows 7 Ultimate 64-bit
Siemens 6AG4025-0DB30-6CD0	IPC527G configuration associated with Core i7 processing, 16 GB DDR4, 1 TB HDD, and Windows 10 Enterprise LTSC 2019
Siemens 6AG4025-0DF20-4BB0	IPC527G with Core i7-6700, 8 GB DDR4, 512 GB SSD, and Windows 10 Enterprise 2016 LTSB
Siemens 6AG4025-0CE30-0BA0	IPC527G with Core i5-6500, 16 GB DDR4, 256 GB SSD, and no operating system

Frequently Considered Alternatives

Model	Product description
Siemens 6AG4025-0CB20-2BB0	IPC527G with Core i5-6500, 8 GB DDR4, 1 TB HDD, and Windows 7 Ultimate 64-bit
Siemens 6AG4025-0CE20-3BB0	IPC527G with Core i5-6500, 8 GB DDR4, 256 GB SSD, and Windows 10 Enterprise 2016 LTSB
Siemens 6AG4025-0CE20-5CA0	IPC527G with Core i5-6500, 8 GB DDR4, 256 GB SSD, and Windows 10 Enterprise LTSC 2019
Siemens 6AG4025-0DF20-2BB0	IPC527G with Core i7-6700, 8 GB DDR4, 512 GB SSD, and Windows 7 Ultimate 64-bit

Applications and Use Cases

Industrial automation and machine-level computing in manufacturing environments.
Production monitoring, process visualization, and industrial data acquisition.
Human-machine interface (HMI) applications and operator workstation integration.
Communication with PLCs, industrial controllers, and network-connected equipment.
Industrial applications requiring Windows-based software, serial communication, and expansion-card support.

Key Benefits and Features

Intel Core i7 processing: The Core i7-6700 supports multitasking and demanding industrial computing workloads.
16 GB DDR4 memory: Provides capacity for visualization software, control applications, and concurrent processes.
1 TB internal storage: Offers local space for applications, production records, and operational data.
Windows 10 Enterprise: The listed configuration includes Windows 10 Enterprise 2016 LTSB multilingual 64-bit.
Flexible connectivity: Includes Gigabit Ethernet, DisplayPort, VGA, USB 3.0, and configurable serial interfaces.
Expansion capability: Supports PCI and PCI Express expansion for compatible industrial hardware.

Technical FAQs

1. What is the Siemens 6AG4025-0DB30-4BB0?

It is a Siemens SIMATIC IPC527G industrial box PC designed for automation, industrial visualization, and machine-level data processing.

2. Which processor does this model use?

It uses an Intel Core i7-6700 processor with four cores, eight threads, a 3.4 GHz base frequency, and a maximum turbo frequency of 4.0 GHz.

3. How much memory is installed?

The listed configuration includes 16 GB of DDR4 memory.

4. What storage capacity does it provide?

It includes a 1 TB internal hard disk drive for applications, operating-system files, and industrial data.

5. Which operating system is included?

The listed configuration includes Windows 10 Enterprise 2016 LTSB multilingual 64-bit.

6. Does it support industrial Ethernet?

Yes. The configuration includes two Gigabit Ethernet interfaces for industrial networking and communication with compatible devices.

7. Which display interfaces are available?

It includes one DisplayPort and one VGA interface for connecting compatible displays.

8. Can it connect to serial industrial equipment?

Yes. It includes two configurable RS232/RS485/RS422 interfaces for compatible serial devices.

9. Which expansion slots are available?

The listed configuration includes one PCIe x16 slot, one PCIe x1 slot, and two PCI slots.

10. What should be considered before deployment?

Verify software compatibility, expansion-card requirements, network configuration, serial communication settings, ventilation, and the condition of the supplied hardware.
