Name: Siemens 6AG4025-0DE20-6CA0 High-Performance Industrial Box PC
Brand: Siemens
SKU: 22734
Availability: InStock
Rating: 5.0 (1 reviews)

Product Overview: SIMATIC IPC527G Industrial Computing Platform

The Siemens SIMATIC IPC527G is an industrial box PC designed for automation, visualization, machine-level computing, and industrial data processing. Model 6AG4025-0DE20-6CA0 combines an Intel Core i7-6700 processor with 8 GB DDR4 memory, a 256 GB SSD, and Windows 10 IoT Enterprise LTSC 2019 64-bit.

Its combination of Ethernet, display, USB, serial, digital I/O, and PCI Express interfaces supports integration with compatible industrial equipment. The SSD provides solid-state storage, while the Windows LTSC operating system supports compatible industrial applications that benefit from a consistent software environment.

Technical Specifications

Specification	Details
Manufacturer	Siemens
Product family	SIMATIC IPC527G
Model number	6AG4025-0DE20-6CA0
Product type	Industrial box PC
Processor	Intel Core i7-6700
Processor cores / threads	4 cores / 8 threads
Processor frequency	3.4 GHz base, up to 4.0 GHz turbo
Cache	8 MB
Chipset	Intel H110
Memory	8 GB DDR4
Storage	256 GB internal SSD
Operating system	Windows 10 IoT Enterprise LTSC 2019, 64-bit, MUI
Graphics	Integrated Intel HD Graphics 530
Ethernet	2 × Gigabit Ethernet
Display outputs	1 × DisplayPort, 1 × VGA
USB	4 × USB 3.0, 2 × USB 2.0
Serial interfaces	2 × selectable RS232/RS485/RS422; 2 × RS232
Digital I/O	1 × 8-bit digital I/O
Expansion slots	1 × PCIe x16, 1 × PCIe x4, 2 × PCIe x1
Power supply	100/240 V AC, 50/60 Hz; power cable not included in the listed configuration
Protection rating	IP20
Operating temperature	0°C to 45°C
Storage temperature	-20°C to 60°C
Dimensions	260 × 135 × 225 mm
Net weight	Approximately 7 kg
Mounting	Wall, book-style, or desktop mounting

Recommended Companion Models

Model	Product description
Siemens 6AG4025-0DF20-4BB0	IPC527G with Core i7-6700, 8 GB DDR4, 512 GB SSD, and Windows 10 Enterprise 2016 LTSB
Siemens 6AG4025-0DF20-2BB0	IPC527G with Core i7-6700, 8 GB DDR4, 512 GB SSD, and Windows 7 Ultimate 64-bit
Siemens 6AG4025-0CE20-5CA0	IPC527G with Core i5-6500, 8 GB DDR4, 256 GB SSD, and Windows 10 IoT Enterprise LTSC 2019
Siemens 6AG4025-0CE20-3BB0	IPC527G with Core i5-6500, 8 GB DDR4, 256 GB SSD, and Windows 10 Enterprise 2016 LTSB

Frequently Considered Alternatives

Model	Product description
Siemens 6AG4025-0DB30-4BB0	IPC527G with Core i7-6700, 16 GB DDR4, 1 TB HDD, and Windows 10 Enterprise 2016 LTSB
Siemens 6AG4025-0DB30-2AA0	IPC527G configuration listed with Core i7-6700, 16 GB DDR4, 1 TB HDD, and Windows 7 Ultimate 64-bit
Siemens 6AG4025-0CB20-0BB0	IPC527G with Core i5-6500, 8 GB DDR4, 1 TB HDD, and no operating system
Siemens 6AG4025-0CE30-0BA0	IPC527G with Core i5-6500, 16 GB DDR4, 256 GB SSD, and no operating system

Applications and Use Cases

Industrial automation and machine-level computing in manufacturing environments.
Production monitoring, process visualization, and industrial data acquisition.
Human-machine interface (HMI) systems and operator workstation applications.
Industrial Ethernet and PROFINET communication with compatible automation equipment.
Integration with existing industrial software and systems requiring Windows 10 IoT Enterprise LTSC 2019.

Key Benefits and Features

Intel Core i7 processing: The Core i7-6700 processor supports multitasking and industrial computing workloads.
8 GB DDR4 memory: Provides capacity for industrial applications, visualization software, and equipment monitoring.
256 GB SSD storage: Offers solid-state storage for the operating system, applications, and local industrial data.
Windows 10 IoT Enterprise LTSC 2019: Supports compatible industrial software in a long-term servicing environment.
Comprehensive connectivity: Includes Gigabit Ethernet, DisplayPort, VGA, USB, serial interfaces, and digital I/O.
Expansion flexibility: Supports PCI and PCI Express cards for compatible industrial interfaces and additional functions.

Technical FAQs

1. What is the Siemens 6AG4025-0DE20-6CA0?

It is a Siemens SIMATIC IPC527G industrial box PC designed for automation, industrial visualization, data acquisition, and machine-level computing.

2. Which processor does this model use?

It uses an Intel Core i7-6700 processor with four cores, eight threads, a 3.4 GHz base frequency, and a maximum turbo frequency of 4.0 GHz.

3. How much memory is installed?

This configuration includes 8 GB of DDR4 memory.

4. What storage capacity does it provide?

It includes a 256 GB internal solid-state drive for the operating system, industrial applications, and local data.

5. Which operating system is installed?

The configured operating system is Windows 10 IoT Enterprise LTSC 2019 64-bit with a multilingual user interface.

6. Does it support industrial Ethernet and PROFINET?

Yes. It includes two Gigabit Ethernet interfaces suitable for supported Industrial Ethernet and PROFINET applications.

7. Which display interfaces are available?

The unit includes one DisplayPort and one VGA output for connecting compatible displays.

8. Which serial communication interfaces does it provide?

It includes two selectable RS232/RS485/RS422 interfaces and two additional RS232 interfaces.

9. Can expansion cards be installed?

Yes. The documented configuration includes one PCIe x16 slot, one PCIe x4 slot, and two PCIe x1 slots.

10. What should be considered before deployment?

Check software compatibility, available expansion slots, network requirements, serial interface settings, power connections, and the operating condition of the hardware.
