Name: Siemens 6AG4025-0DE30-0AA0 High-Performance Industrial Box PC
Brand: Siemens
SKU: 22735
Availability: InStock
Rating: 5.0 (1 reviews)

Product Overview and Design

The Siemens SIMATIC IPC527G is a versatile industrial Box PC designed for machine builders, automation engineers, and system integrators. Model 6AG4025-0DE30-0AA0 combines an Intel Core i7-6700 processor with 16 GB of memory and a 256 GB SSD, providing a foundation for industrial visualization, machine monitoring, data collection, and control-related applications.

Its combination of Ethernet, serial communication, USB, and display interfaces supports integration with a variety of industrial equipment. The unit is supplied without an operating system, giving integrators flexibility to select and validate a suitable software environment.

Technical Specifications

Specification	Details
Manufacturer	Siemens
Product family	SIMATIC IPC527G
Product type	Industrial Box PC
Order number	6AG4025-0DE30-0AA0
Processor	Intel Core i7-6700
Processor cores / threads	4 cores / 8 threads
Base / turbo frequency	3.4 GHz / up to 4.0 GHz
Cache	8 MB
Installed memory	16 GB DDR4
Maximum supported memory	Up to 32 GB for the IPC527G family
Storage	256 GB SSD
Operating system	None preinstalled
Ethernet	2 × Gigabit Ethernet
Display interfaces	1 × DisplayPort, 1 × VGA
USB	4 × USB 3.0; additional USB 2.0 availability depends on configuration
Serial interfaces	2 × RS232/485/422, selectable
Expansion	1 × PCIe x16
Power supply	100/240 V AC, autoranging, 50/60 Hz
Protection rating	IP20
Operating temperature	0°C to 45°C
Storage temperature	-20°C to 60°C
Dimensions (W × H × D)	260 × 135 × 225 mm
Installation options	Desktop, wall, portrait
Power cable	Verify inclusion with the supplied configuration

Recommended Companion Models

Model	Product name	Typical role
6AG4025-0CE30-0BA0	SIMATIC IPC527G, Core i5-6500, 16 GB RAM, 256 GB SSD, no OS	Alternative processing configuration
6AG4025-0CE20-5CA0	SIMATIC IPC527G, Core i5-6500, 8 GB RAM, 256 GB SSD, Windows 10 IoT Enterprise LTSC 2019	Preinstalled operating-system configuration
6AG4025-0DF30-0AA0	SIMATIC IPC527G, Core i7-6700, 16 GB RAM, 512 GB SSD, no OS	Higher-capacity SSD option
6AG4025-0DE20-6CA0	SIMATIC IPC527G, Core i7-6700, 8 GB RAM, 256 GB SSD, Windows 10 IoT Enterprise LTSC 2019	Related i7 configuration with Windows

Frequently Considered Alternatives

Model	Product name	Main difference
6AG4025-0CB20-0BB0	SIMATIC IPC527G, Core i5-6500, 8 GB RAM, 1 TB HDD, no OS	HDD storage configuration
6AG4025-0CE20-3BB0	SIMATIC IPC527G, Core i5-6500, 8 GB RAM, 256 GB SSD, Windows 10 Enterprise 2016 LTSB	Windows-based configuration
6AG4025-0AB20-0CA0	SIMATIC IPC527G, Pentium G4400, 8 GB RAM, 1 TB HDD, no OS	Lower-performance processor option
6AG4025-0DF20-4BB0	SIMATIC IPC527G, Core i7-6700, 8 GB RAM, 512 GB SSD, Windows 10 Enterprise 2016 LTSB	i7 configuration with larger SSD and Windows

Industrial Applications and Use Cases

Industrial automation systems requiring dependable local computing.
Machine control and production equipment with legacy serial communication needs.
Factory monitoring, data acquisition, and operator-interface applications.
Industrial systems requiring PCI Express expansion for specialized interface cards.
Edge computing installations that benefit from local data processing and network connectivity.
System integration projects requiring a Windows-free configuration for a custom software installation.

Key Benefits and Features

Intel Core i7 processing: The Intel Core i7-6700 processor supports demanding industrial computing workloads.
16 GB DDR4 memory: Provides capacity for multitasking and industrial application software.
256 GB SSD storage: Offers solid-state storage for the operating system installed by the integrator, applications, and local data.
Flexible connectivity: Includes Gigabit Ethernet, DisplayPort, VGA, USB 3.0, and configurable serial interfaces.
PCI Express expansion: A PCIe x16 slot supports compatible expansion hardware.
Flexible installation: The SIMATIC IPC527G family supports desktop, wall, and portrait mounting.
Operating-system flexibility: Supplied without a preinstalled operating system, allowing the integrator to plan the software environment.

Technical FAQs

1. What is the Siemens 6AG4025-0DE30-0AA0?

It is a Siemens SIMATIC IPC527G industrial Box PC configured with an Intel Core i7-6700 processor, 16 GB DDR4 memory, and a 256 GB SSD.

2. Which processor does this model use?

It uses the Intel Core i7-6700, a quad-core desktop processor with a base frequency of 3.4 GHz, a maximum turbo frequency of 4.0 GHz, and 8 MB cache.

3. How much memory is installed?

This configuration includes 16 GB of DDR4 memory.

4. What storage does it provide?

It is configured with a 256 GB solid-state drive.

5. Does it include a preinstalled operating system?

No. This part-number configuration is listed without an operating system, so software compatibility and installation must be handled by the system integrator.

6. Which display connections are available?

The IPC527G platform provides one DisplayPort and one VGA connection.

7. Can it connect to an industrial Ethernet network?

Yes. It includes two Gigabit Ethernet interfaces suitable for industrial network communication.

8. Which serial interfaces are supported?

The standard configuration includes two serial interfaces selectable between RS232, RS485, and RS422 modes. Confirm the exact interface configuration before connecting field equipment.

9. Can expansion cards be installed?

Yes. This configuration is listed with one PCIe x16 expansion slot. Check the card's physical dimensions, power requirements, and driver compatibility before installation.

10. What should be checked before ordering?

Confirm the full part number, processor, memory, SSD capacity, operating-system status, expansion configuration, power-cable requirements, and compatibility with the intended control system.
