Siemens 6AG4104-4AA02-0XX3 SIMATIC IPC547G Industrial Rack PC
Siemens 6AG4104-4AA02-0XX3 SIMATIC IPC547G Industrial Rack PC
0.0
Points
Brand:Siemens Item No.:6AG4104-4AA02-0XX3 Product Origin: Germany Product Dimensions:481.4 × 176.6 × 446.6 mm Product Weight:23 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens SIMATIC IPC547G industrial rack PC is designed for automation and production environments that require a configurable computing platform with industrial connectivity and expansion flexibility. Its rack-mounted construction supports integration into equipment cabinets, while its expansion slots accommodate compatible cards for specialized industrial applications.
Model 6AG4104-4AA02-0XX3 should be verified against the original equipment documentation before its detailed configuration is specified. The IPC547G family provides a useful reference for chassis dimensions, expansion capacity, and common connectivity features, but the processor, memory, storage, and operating system must be confirmed for this exact order number.
For maintenance and replacement projects, matching the existing interfaces and software environment is particularly important. Confirming these details helps reduce installation problems and supports a smoother return to operation.
Technical Specifications
Parameter
Specification
Brand
Siemens
Product family
SIMATIC IPC547G
Model number
6AG4104-4AA02-0XX3
Product type
Industrial Rack PC
Form factor
19-inch, 4U
Processor
Exact configuration requires verification
Memory
Exact capacity requires verification
Storage
Type and capacity require verification
Front USB
2 × USB 3.0
Ethernet
2 × Intel Gigabit Ethernet
Other interfaces
Family-level configuration includes 2 × PS/2 and audio
Expansion slots
5 × PCI Express, 2 × PCI
System monitoring
Temperature and fan monitoring
Watchdog
Supported by the IPC547G family
Power supply
100–240 V AC; verify installed supply and options
Dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm, standard enclosure
Weight
15–23 kg, depending on equipment
Operating system
Exact configuration requires verification
Installation
Horizontal or vertical; rack brackets can be removed externally
Dimensions and weight refer to the IPC547G standard-enclosure family. A short-enclosure variant has a different depth, so verify the physical configuration before planning cabinet space or shipment.
Recommended Related Models
The following SIMATIC IPC547G models offer different hardware configurations. They should be considered only after checking the original system's requirements.
Model Number
Product Name
6AG4104-4AA05-3XX0
SIMATIC IPC547G, Pentium G4400, 4 GB DDR4, 1 TB HDD, without operating system
6AG4104-4CA01-0XX1
SIMATIC IPC547G, Core i5-6500, 4 GB DDR4, 1 TB HDD, without operating system
Legacy system support: Can serve as a replacement platform when hardware, software, and interface requirements match.
Control-room installations: The rack-mounted enclosure fits standard 19-inch industrial cabinets and equipment racks.
Advantages
Key Strengths at a Glance
Industrial rack format: 19-inch, 4U construction designed for industrial environments.
Extensive expansion capacity: The IPC547G family provides five PCI Express slots and two PCI slots.
Dual Gigabit Ethernet: Supports connections to industrial networks and supervisory systems.
Front-access USB: Two USB 3.0 ports simplify service access and peripheral connection.
Hardware monitoring: Temperature and fan monitoring help operators assess system conditions.
Watchdog functionality: Supports monitoring of system or application operation.
Flexible installation: Designed for horizontal or vertical installation, with preparation for telescopic rails.
Configuration options: Processor, memory, storage, operating system, and selected interfaces vary by order number.
Technical FAQs
Q1: What is the Siemens 6AG4104-4AA02-0XX3?
It is an order number associated with the Siemens SIMATIC IPC547G industrial rack PC family. The exact hardware configuration should be checked before procurement or replacement.
Q2: What applications can the IPC547G run?
With compatible hardware and software, it can support industrial visualization, HMI, SCADA, production monitoring, and data-processing applications.
Q3: What is the IPC547G's mounting format?
The IPC547G uses a 19-inch, 4U rack-mount enclosure suitable for industrial cabinets and control-room equipment racks.
Q4: How many expansion slots does the IPC547G provide?
The family configuration includes seven expansion slots: five PCI Express slots and two PCI slots. Check the installed configuration before selecting expansion cards.
Q5: Does the IPC547G have Ethernet connectivity?
Yes. The family includes two Intel Gigabit Ethernet interfaces for industrial networking and communication with compatible equipment.
Q6: Which USB interfaces are available?
Two USB 3.0 ports are provided on the front. Rear USB interfaces depend on the motherboard and chipset configuration.
Q7: Does the IPC547G include system monitoring functions?
The family supports temperature and fan monitoring, a watchdog function, and a card-retention mechanism.
Q8: Can additional communication or I/O cards be installed?
Yes, provided the cards are compatible with the available PCI Express or PCI slots, the operating system, and the system's power and space requirements.
Q9: What power supply does the IPC547G use?
The family supports a 100–240 V AC power supply, with redundant power supply options available on selected configurations. Verify the actual power supply before installation.
Q10: What information should be checked before ordering a replacement?
Confirm the complete order number, processor, memory, storage, operating system, expansion cards, rear interfaces, power supply, and chassis dimensions to ensure compatibility with the existing installation.
