Siemens 6AG4104-4AA02-1XX1 SIMATIC IPC547G Industrial Rack PC
Siemens 6AG4104-4AA02-1XX1 SIMATIC IPC547G Industrial Rack PC
0.0
Points
Brand:Siemens Item No.:6AG4104-4AA02-1XX1 Product Origin: Germany Product Dimensions:481.4 × 176.6 × 446.6 mm Product Weight:17 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens SIMATIC IPC547G is an industrial computing platform developed for environments that require rack integration, expandable hardware, and reliable connectivity. Its combination of conventional expansion slots and industrial interfaces makes the series suitable for automation support, process visualization, production monitoring, and industrial information systems.
For 6AG4104-4AA02-1XX1, the exact configuration should be confirmed before specifying processor performance, memory capacity, storage, or software. IPC547G family characteristics can help identify the platform, but they do not establish every detail of an individual order variant.
When selecting a replacement or planning a system upgrade, compare the original unit's interfaces, expansion cards, operating system, and storage requirements. This is particularly important for installations that depend on legacy drivers or specialized industrial software.
Technical Specifications
Parameter
Specification
Brand
Siemens
Product family
SIMATIC IPC547G
Model number
6AG4104-4AA02-1XX1
Product type
Industrial Rack PC
Form factor
19-inch, 4U
Processor
Exact configuration requires verification
Memory
Exact capacity requires verification
Storage
Type and capacity require verification
Front USB
2 × USB 3.0
Ethernet
2 × Intel Gigabit Ethernet
Other interfaces
Family-level configuration includes 2 × PS/2 and audio
Expansion slots
5 × PCI Express, 2 × PCI
System monitoring
Temperature and fan monitoring
Watchdog
Supported by the IPC547G family
Power supply
100–240 V AC; confirm installed configuration
Dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm for the standard enclosure
Weight
Approximately 17 kg for a documented IPC547G configuration; exact weight of this variant requires confirmation
Operating system
Exact configuration requires verification
Installation
Rack-mounted; horizontal or vertical installation supported by the family
The listed dimensions describe the standard IPC547G enclosure. Enclosure variants and installed options may affect the final dimensions and weight. Verify these details before planning installation or shipment.
Recommended Related Models
Model Number
Product Name
6AG4104-4AA05-3XX0
SIMATIC IPC547G, Pentium G4400, 4 GB DDR4, 1 TB HDD, without operating system
6AG4104-4CA01-0XX1
SIMATIC IPC547G, Core i5-6500, 4 GB DDR4, 1 TB HDD, without operating system
Factory automation: Supports compatible production monitoring, machine supervision, and manufacturing applications.
HMI and SCADA: Provides a platform for operator interfaces and supervisory control software.
Industrial data processing: Handles operational data collection, visualization, and reporting.
System integration: Expansion slots accommodate compatible interface cards for specialized industrial equipment.
Legacy installations: Can support existing applications when hardware and software requirements are met.
Control-room computing: The rack-mounted enclosure integrates into standard industrial cabinets and equipment racks.
Advantages
Key Strengths at a Glance
Industrial rack design: 19-inch, 4U construction suited to industrial installations.
Flexible expansion: The IPC547G family provides five PCI Express slots and two PCI slots.
Dual Gigabit Ethernet: Supports connections to industrial networks and supervisory systems.
Convenient front access: Two front-facing USB 3.0 ports simplify service and peripheral connections.
Hardware monitoring: Temperature and fan monitoring help operators assess system conditions.
Watchdog support: Provides a mechanism for monitoring system or application operation.
Multiple configuration options: Processor, memory, storage, and operating system depend on the specific order variant.
Flexible installation: Supports horizontal or vertical installation, with provisions for telescopic rails.
Technical FAQs
Q1: What is the Siemens 6AG4104-4AA02-1XX1?
It is an order number associated with the Siemens SIMATIC IPC547G industrial rack PC family. Its exact configuration should be verified before procurement or installation.
Q2: What industrial applications can the IPC547G support?
With compatible software and hardware, it can support HMI, SCADA, production monitoring, industrial data processing, and machine-related applications.
Q3: What is the IPC547G's form factor?
The IPC547G uses a 19-inch, 4U rack-mount enclosure designed for industrial cabinets and equipment racks.
Q4: How many expansion slots are available?
The IPC547G family provides seven expansion slots: five PCI Express and two PCI. Confirm card compatibility and available space before installation.
Q5: Does the IPC547G support Gigabit Ethernet?
Yes. The family includes two Intel Gigabit Ethernet interfaces for industrial network connections.
Q6: Which USB interfaces are available?
Two USB 3.0 ports are available on the front. Rear USB interfaces vary according to the installed motherboard and chipset.
Q7: Does the IPC547G support system monitoring?
The family supports temperature and fan monitoring, watchdog functionality, and a card-retention mechanism.
Q8: Can the computer accommodate specialized industrial interface cards?
Yes, provided the cards match the available PCI Express or PCI slots and are compatible with the operating system, power budget, and physical dimensions.
Q9: What power supply does the IPC547G use?
The family supports a 100–240 V AC power supply, with redundant power options available on selected configurations. The installed supply should be checked before connecting the unit.
Q10: What should be checked when replacing this model?
Verify the complete order number, processor, memory, storage, operating system, expansion cards, network interfaces, power supply, and enclosure dimensions to maintain compatibility with the existing system.
