Name: Siemens 6AG4104-4CA02-3XX0 – SIMATIC IPC547G Industrial Rack PC
Brand: Siemens
SKU: 22872
Availability: InStock
Rating: 5.0 (1 reviews)

Introduction

The Siemens SIMATIC IPC547G 6AG4104-4CA02-3XX0 is an industrial rack computer intended for automation environments that require a versatile computing platform with multiple expansion options. Its reported Core i5-6500 processor, 4 GB DDR4 memory, and 1 TB hard drive provide a foundation for industrial monitoring, control software, and production data processing.

The combination of dual Gigabit Ethernet, multiple USB interfaces, display connectivity, and seven expansion slots allows integration with a variety of industrial peripherals and legacy hardware. Built-in temperature monitoring, fan monitoring, and watchdog functionality provide additional system-management capabilities.

This model belongs to an older IPC547G product generation. When purchasing for an existing installation, confirm its condition, operating-system support, accessory requirements, and compatibility with the intended application.

Technical Specifications

Parameter	Specification
Manufacturer	Siemens
Order number	6AG4104-4CA02-3XX0
Product family	SIMATIC IPC547G
Product type	Industrial rack PC
Mounting format	19-inch rack, 4U
Processor	Intel Core i5-6500
Processor cores / threads	4 / 4
Processor frequency	3.2 GHz base, up to 3.6 GHz Turbo
Chipset	Intel H110
Installed memory	4 GB DDR4-2133 SDRAM, 1 × 4 GB
Storage	1 × 1 TB internal HDD
Ethernet	2 × Intel Gigabit Ethernet
Front USB	2 × USB 3.0
Rear USB	2 × USB 3.0, 4 × USB 2.0
Display interfaces	1 × DisplayPort 1.2, 1 × DVI-D
Other interfaces	2 × PS/2, audio line-in and line-out
Expansion slots	5 × PCI Express, 2 × PCI
Monitoring functions	Temperature monitoring, fan monitoring, watchdog
Graphics	Integrated graphics
Power supply	100–240 V AC family specification
Dimensions (W × H × D)	Approximately 481.4 × 176.6 × 446.6 mm
Height	4U
Weight	Varies by installed configuration; confirm against the unit's nameplate or shipping documentation
Operating system	Confirm the installed operating system; configuration may vary
Product generation	Legacy SIMATIC IPC547G

Specifications reflect the reported configuration and IPC547G family information. Confirm the exact unit's nameplate, installed components, and original Siemens documentation before procurement.

Recommended Related Models

The following models are from the same IPC547G family or represent closely related configurations. Their processor, storage, operating system, and power-supply options differ.

Model	Description
6AG4104-4CA02-0XX1	IPC547G configuration reported with Core i5-6500, 4 GB DDR4, and 1 TB HDD
6AG4104-4CA01-0XX1	IPC547G with Core i5-6500, H110 chipset, 4 GB DDR4, and 1 TB HDD; listed without an operating system
6AG4104-4CA00-0BX2	IPC547G with Core i5-6500, short enclosure, 4 GB DDR4, 1 TB HDD, and Windows 7 Ultimate
6AG4104-4CA04-0BX0	IPC547G with Core i5-6500, 4 GB DDR4, 1 TB HDD, DVD drive, and redundant AC power supplies
6AG4104-4DA12-3BX2	IPC547G configuration with Core i7-6700, 8 GB DDR4, 1 TB HDD, DVD drive, and Windows 7 Ultimate

Popular Related Models

Model	Description
6AG4104-4GA12-2DX1	IPC547G with Core i5-6500, C236 chipset, 8 GB DDR4, 1 TB HDD, DVD drive, and a dual-head graphics card
6AG4104-4GN16-4BX0	IPC547G with Core i5-6500, C236 chipset, 8 GB DDR4, and RAID 1 storage using two 1 TB HDDs
6AG4104-4GK13-1BX2	IPC547G with Core i5-6500, C236 chipset, 8 GB DDR4, a 480 GB SSD in a removable front-access insert, and redundant AC power supplies
6AG4104-4EN16-3XX0	IPC547G configuration with Pentium G4400, C236 chipset, 8 GB DDR4, RAID 1 storage, and no preinstalled operating system
6AG4104-4AA05-3XX0	IPC547G configuration with Pentium G4400, H110 chipset, 4 GB DDR4, 1 TB HDD, and no preinstalled operating system

Applications

The Siemens 6AG4104-4CA02-3XX0 is a SIMATIC IPC547G industrial rack PC designed for industrial computing, automation control, and data-processing applications. Its 19-inch, 4U rack-mount format and expansion capabilities make it suitable for integration into control cabinets, industrial server racks, and machine-control systems.

Typical applications include:

Industrial automation and machine control
Production-line monitoring and data acquisition
Human-machine interface (HMI) and SCADA systems
Industrial networking and communication
Quality inspection and manufacturing data processing
Legacy automation system maintenance and replacement

Advantages

Industrial rack-mount design: A 19-inch, 4U enclosure supports installation in standard equipment racks.
Reliable computing platform: The reported configuration uses an Intel Core i5-6500 processor and Intel H110 chipset.
Flexible expansion: Seven expansion slots support compatible PCI Express and conventional PCI cards.
Multiple connectivity options: Dual Gigabit Ethernet, USB ports, PS/2 connections, audio interfaces, DisplayPort, and DVI-D support a range of industrial peripherals.
Practical storage capacity: The listed configuration includes a 1 TB internal hard disk drive.
Industrial monitoring features: Temperature and fan monitoring, watchdog functionality, and card retainers support system supervision and reliable operation.

Technical FAQs

Q1: What type of product is the Siemens 6AG4104-4CA02-3XX0?

It is a Siemens SIMATIC IPC547G industrial rack PC in a 19-inch, 4U format.

Q2: Which processor is used in this configuration?

Available product information identifies an Intel Core i5-6500 processor with four cores and four threads, a 3.2 GHz base frequency, and up to 3.6 GHz Turbo frequency.

Q3: What motherboard chipset does it use?

The listed configuration uses the Intel H110 chipset.

Q4: How much memory is installed?

The reported configuration includes 4 GB of DDR4-2133 SDRAM in a single memory module. Verify the installed memory on the individual unit before ordering.

Q5: What storage is provided?

The listed configuration includes one internal 1 TB hard disk drive.

Q6: How many Ethernet interfaces are available?

It has two Intel Gigabit Ethernet interfaces, suitable for connecting to industrial networks and other Ethernet devices.

Q7: Which display interfaces are supported?

The H110-based configuration includes one DisplayPort 1.2 interface and one DVI-D interface.

Q8: How many expansion slots does the IPC547G provide?

The system provides seven expansion slots: five PCI Express slots and two PCI slots.

Q9: What power supply does it require?

The IPC547G family supports a 100–240 V AC industrial power supply. Confirm the installed power-supply configuration and local power-cable requirements before installation.

Q10: Is the 6AG4104-4CA02-3XX0 suitable for replacing an existing industrial PC?

It may be suitable when the required processor performance, operating system, expansion cards, interfaces, and mechanical dimensions are compatible. Check the original system configuration and software requirements before replacing existing equipment.
