Siemens 6AG4104-4CA02-3XX3 – Versatile SIMATIC IPC547G Industrial Rack PC
Siemens 6AG4104-4CA02-3XX3 – Versatile SIMATIC IPC547G Industrial Rack PC
0.0
Points
Brand:Siemens Item No.:6AG4104-4CA02-3XX3 Product Origin: Germany Product Dimensions:481.4 × 176.6 × 356.6 mm Product Weight:23 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Siemens SIMATIC IPC547G is a rack-mounted industrial computer developed for automation environments where connectivity, expansion capability, and integration with existing equipment are important. Its 19-inch, 4U format supports installation in industrial cabinets and equipment racks.
The platform offers dual Gigabit Ethernet, multiple USB connections, display interfaces, and a combination of PCI Express and PCI expansion slots. Monitoring features such as temperature and fan supervision and watchdog functionality support system management in industrial applications.
Because the complete configuration of order number 6AG4104-4CA02-3XX3 could not be verified from the available documentation, CPU, memory, storage, operating system, and included accessories should be confirmed before purchase. This is particularly important when replacing a computer in an established production system.
Technical Specifications
Parameter
Specification
Manufacturer
Siemens
Order number
6AG4104-4CA02-3XX3
Product family
SIMATIC IPC547G
Product category
Industrial rack PC
Rack format
19-inch, 4U
Processor
Exact configuration unverified
Motherboard chipset
Exact configuration unverified; H110 is a known IPC547G variant
Memory
Exact installed capacity unverified
Storage
Exact drive type and capacity unverified
Ethernet
2 × Intel Gigabit Ethernet, family specification
Front USB
2 × USB 3.0, family specification
Rear USB
Depends on motherboard variant
Display interfaces
Depends on motherboard variant
PS/2 interfaces
2, family specification
Audio
Rear audio interfaces, family specification
Expansion slots
5 × PCI Express and 2 × PCI, family specification
Monitoring
Temperature and fan monitoring, watchdog
Power input
100–240 V AC, family specification
Standard enclosure dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm
Short enclosure dimensions (W × H × D)
481.4 × 176.6 × 356.6 mm
Weight
Approximately 15–23 kg for standard-enclosure configurations, depending on equipment
Operating system
Exact configuration unverified
Product generation
Legacy IPC547G family
Dimensions and weight are family-level specifications. The exact enclosure type and installed hardware for 6AG4104-4CA02-3XX3 should be confirmed before installation or shipment.
Recommended Related Models
The following IPC547G variants provide useful comparison points for processor, memory, storage, and operating-system requirements.
Model
Key configuration
6AG4104-4CA01-0XX1
Core i5-6500, H110 chipset, 4 GB DDR4, 1 TB HDD, no operating system
Core i7-6700, C236 chipset, 8 GB DDR4, RAID 1 storage, redundant AC power supplies
6AG4104-4CA00-0BX2
Core i5-6500, short enclosure, 4 GB DDR4, 1 TB HDD, Windows 7 Ultimate
Applications
The Siemens 6AG4104-4CA02-3XX3 is associated with the SIMATIC IPC547G industrial rack PC family. Designed for rack-mounted industrial computing, the IPC547G platform supports automation applications that require multiple interfaces, expansion slots, and integration with established industrial equipment.
Typical application areas include:
Industrial automation and machine-control systems
SCADA and HMI applications
Production monitoring and manufacturing data collection
Industrial Ethernet communication
Quality-control and process-monitoring systems
Maintenance and replacement of legacy industrial computing equipment
Configuration note: The exact Siemens documentation for the 6AG4104-4CA02-3XX3 suffix was not independently confirmed. The article below distinguishes IPC547G family characteristics from order-specific details that should be checked before purchase.
Advantages
Rack-ready construction: The IPC547G family uses a 19-inch, 4U industrial enclosure.
Expansion flexibility: The platform provides seven expansion slots, comprising five PCI Express slots and two PCI slots.
Industrial connectivity: Dual Gigabit Ethernet, front USB 3.0 ports, rear USB interfaces, PS/2, and audio connections support a range of peripherals.
System monitoring: Family-level features include temperature and fan monitoring, watchdog functionality, and card retainers.
Configurable computing platform: Processor, memory, storage, operating system, and other options vary among order numbers in the IPC547G range.
Suitable for legacy installations: Its established interface and expansion options can help support existing automation systems when compatibility is verified.
Technical FAQs
Q1: What is the main function of the Siemens 6AG4104-4CA02-3XX3?
It is identified with the SIMATIC IPC547G industrial rack PC family, intended for industrial computing, automation support, and production-system integration.
Q2: What processor is installed in this exact order number?
The processor for the 6AG4104-4CA02-3XX3 configuration has not been independently verified. Confirm the original product label or order-specific Siemens documentation before specifying a CPU.
Q3: How much RAM does this model support?
Memory capacity depends on the motherboard and installed configuration. Check the relevant IPC547G technical documentation and the individual unit before planning a memory upgrade.
Q4: What storage options are available in the IPC547G family?
Depending on the order variant, the family includes hard-disk and solid-state storage configurations. The exact drive type and capacity for this order number should be confirmed separately.
Q5: Which network interfaces are available?
The IPC547G family provides two Intel Gigabit Ethernet interfaces for industrial network communication.
Q6: Does the computer support expansion cards?
Yes. The family provides seven expansion slots: five PCI Express and two PCI. Confirm the slot type, card dimensions, and power requirements before installation.
Q7: Which USB ports are provided?
The family specification includes two front USB 3.0 ports. Rear USB configurations vary by motherboard version; the H110 variant commonly has two rear USB 3.0 ports and four USB 2.0 ports.
Q8: What display connections does the H110 configuration offer?
The H110 motherboard variant commonly provides one DisplayPort 1.2 and one DVI-D interface. Verify the installed motherboard before relying on these connections.
Q9: What power input does the IPC547G use?
The standard IPC547G family supports 100–240 V AC input. The exact power-supply arrangement, cable, and regional configuration depend on the individual unit.
Q10: Is the IPC547G appropriate for new automation projects?
It may be appropriate where legacy software or existing hardware requires this platform. For new installations, evaluate operating-system support, spare-part availability, cybersecurity requirements, and the suitability of a current-generation industrial PC.
