Siemens 6AG4104-4CA16-1DX3 SIMATIC IPC547G Industrial Rack PC

Where It Excels in Industrial Use

• Industrial automation and control: The SIMATIC IPC547G platform is designed for industrial computing tasks, including machine supervision, production monitoring, and automation software execution.

• Production data processing: Its industrial PC architecture supports applications that collect, process, and communicate operational data from manufacturing equipment.

• Expansion-intensive installations: Five PCI Express slots and two PCI slots provide flexibility for compatible fieldbus adapters, communication cards, and specialized industrial interfaces.

• Factory network integration: Dual Intel Gigabit Ethernet interfaces support connections to industrial networks, supervisory systems, and other Ethernet-enabled devices.

• Centralized equipment racks: The 19-inch, 4U chassis is suitable for control rooms, industrial cabinets, and rack-based automation installations.

• Legacy system maintenance: The platform can be useful when maintaining existing installations that rely on established hardware interfaces, drivers, and validated software environments.

Key Strengths at a Glance

• Industrial monitoring functions: Temperature and fan monitoring, watchdog functionality, and card-retention features support system supervision and hardware management.

• Broad expansion capability: The combination of PCI Express and conventional PCI slots accommodates a range of compatible industrial expansion cards.

• Practical connectivity: Front USB 3.0 ports, dual Gigabit Ethernet, PS/2 connections, and rear audio interfaces support common peripheral and networking requirements.

• Flexible system configurations: The IPC547G family was available with different Intel processors, memory capacities, storage devices, and graphics options. The precise hardware configuration for order number 6AG4104-4CA16-1DX3 should be verified against the original Siemens order documentation.

• Industrial AC power: The platform supports 100–240 V AC input, with redundant power-supply configurations available for selected models.

• Rack integration options: Standard and short enclosure variants within the family provide different installation depths, making enclosure verification important when replacing existing equipment.

Technical FAQs

Q1. What is the Siemens 6AG4104-4CA16-1DX3?

It is an order number presented for the Siemens SIMATIC IPC547G industrial rack PC family, designed for industrial computing and automation applications. Its exact configuration should be confirmed before procurement.

Q2. Which processor is installed in this specific model?

The processor for order number 6AG4104-4CA16-1DX3 could not be independently verified. The broader IPC547G family includes configurations based on Intel Pentium, Core i5, Core i7, and Xeon processors.

Q3. What memory capacity does this configuration provide?

The exact installed memory capacity is unconfirmed. IPC547G systems were offered with multiple DDR4 memory configurations, so the device label or original order record should be checked.

Q4. What storage options are supported by the IPC547G family?

Depending on configuration, the family supports internal hard drives, solid-state drives, and selected RAID arrangements. The precise storage type and capacity of this order number require verification.

Q5. How many expansion slots are available?

The IPC547G family provides five PCI Express slots and two conventional PCI slots. Individual card compatibility depends on interface type, card dimensions, power requirements, and available clearance.

Q6. Which Ethernet interfaces does the system provide?

The family includes two Intel Gigabit Ethernet interfaces for industrial networking and communication with compatible automation systems.

Q7. Which display interfaces are available?

Display outputs depend on the motherboard and graphics configuration. Certain IPC547G variants include DisplayPort and DVI-D, while optional graphics cards can provide additional outputs.

Q8. Does the computer include a preinstalled operating system?

Operating-system installation and licensing vary by order number. Confirm the exact software configuration before integrating the system into a production environment.

Q9. Is redundant power available for this model?

Redundant AC power supplies were offered on selected IPC547G configurations. Their inclusion in the 6AG4104-4CA16-1DX3 variant has not been confirmed.

Q10. What should be checked before replacing this industrial PC?

Confirm the exact order number, processor, memory, storage layout, operating system, graphics connections, expansion cards, power-supply arrangement, and enclosure format. Also assess software compatibility and lifecycle support before selecting a replacement.
