Brand:Schneider PLC Item No.:MVS08H Product Origin:France Product Dimensions:352 x 422 x 297 mm Product Weight:40 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider MVS08H Breaker is part of the EasyPact MVS range of low-voltage air circuit breakers used in industrial and commercial electrical distribution systems. It is intended for applications where dependable switching and circuit protection are essential for maintaining electrical system performance.
For maintenance engineers, plant operators, and industrial equipment purchasers, the MVS08H may be relevant to switchgear maintenance, equipment replacement, or power distribution projects. Accurate product identification is especially important when sourcing replacement breakers because models with similar current ratings can differ in breaking capacity, terminal arrangement, installation dimensions, and trip-unit functions.
Before purchasing, verify the complete catalog number and product nameplate. Confirm the rated current, rated voltage, short-circuit breaking capacity, pole configuration, and mounting arrangement against the existing installation.
Selecting a compatible circuit breaker helps reduce installation difficulties and supports reliable operation of the electrical distribution system.
Technical Specifications
Parameter
Specification
Brand
Schneider Electric
Model
MVS08H
Product Type
Air Circuit Breaker (ACB)
Product Family
EasyPact MVS
Rated Current Reference
800 A
Dimensions (H × W × D)
352 × 422 × 297 mm
Dimensions (inches)
13.86 × 16.61 × 11.69 in
Weight
40 kg (88.18 lb)
Dimensions and weight are supplied reference values. Actual specifications may vary depending on pole count, mounting arrangement, and the complete catalog number. Verify the exact configuration before ordering or installation.
Recommended Related Models
Schneider MVS10H Breaker
Schneider MVS12H Breaker
Schneider MVS16H Breaker
Schneider MVS20H Breaker
Schneider NW08N1 Breaker
Popular Related Models
Schneider MVS08H
Schneider MVS10H
Schneider MVS12H
Schneider MVS20H
Schneider NW10N1
When sourcing Schneider Electric circuit breakers, verify the complete catalog number and technical configuration to ensure compatibility with the intended electrical installation.
Applications
The Schneider MVS08H Breaker is a low-voltage air circuit breaker designed for industrial and commercial power distribution systems. It is suitable for installations that require reliable circuit protection, switching, and electrical isolation.
Typical applications include:
Industrial power distribution panels and main switchboards
Manufacturing plants and production facilities
Commercial buildings and infrastructure projects
Transformer and generator distribution systems
Electrical equipment rooms and industrial facilities
Replacement and maintenance projects involving compatible EasyPact MVS switchgear
The suitability of the breaker depends on its rated voltage, breaking capacity, trip unit, and installation configuration.
Advantages
Reliable circuit protection: Supports protection against overloads and short circuits when equipped with the appropriate trip unit.
Industrial power distribution: Designed for integration into compatible low-voltage switchgear assemblies.
Flexible configuration: The EasyPact MVS family offers different current ratings, pole counts, and installation arrangements.
Maintenance convenience: Supports routine inspection and testing according to applicable manufacturer procedures.
Replacement compatibility: Can be considered for legacy equipment maintenance after electrical and mechanical specifications are verified.
System integration: Suitable for industrial distribution applications when correctly selected and installed.
Technical FAQs
Q1: What type of circuit breaker is the Schneider MVS08H?
The MVS08H belongs to the Schneider Electric EasyPact MVS family of low-voltage air circuit breakers.
Q2: What is the rated current of the MVS08H?
The MVS08H designation generally corresponds to an 800 A frame rating. Confirm the exact rating on the nameplate and applicable technical documentation.
Q3: What protection functions are available?
Protection functions depend on the installed trip unit and configuration. Supported functions may include overload, short-time overcurrent, and instantaneous short-circuit protection.
Q4: Can the MVS08H be used as a main incomer breaker?
It may be suitable for a main incomer application if its current rating, breaking capacity, and protection settings meet the system design requirements.
Q5: What can cause repeated tripping?
Possible causes include overloads, short circuits, ground faults where applicable, incorrect protection settings, or trip-unit problems. The cause should be investigated before resetting the breaker.
Q6: Can the MVS08H protect a transformer feeder?
It may be used for transformer feeder protection when the breaker's interrupting capacity and protection characteristics are appropriate for the transformer and prospective fault current.
Q7: How should the trip unit be tested?
Qualified electrical personnel should verify the settings and perform functional tests using suitable test equipment and approved procedures.
Q8: Can the MVS08H replace another 800 A breaker?
Not automatically. Rated voltage, breaking capacity, pole count, trip unit, terminal arrangement, mounting dimensions, and switchboard compatibility must be checked.
Q9: What maintenance does the MVS08H require?
Maintenance may include visual inspection, mechanism checks, connection inspections, and trip-unit testing according to manufacturer recommendations.
Q10: What information is needed when ordering a replacement?
Provide the complete catalog number, nameplate details, pole configuration, mounting arrangement, and trip-unit information to help verify compatibility.
