Introduction The Siemens 6AG4104-4DA12-2XX3 is a requested ordering designation within the SIMATIC IPC547G industrial rack PC family. This industrial computing platform is designed to support manufacturing operations, automation infrastructure, and centralized process management.
The IPC547G combines a 19-inch, 4U rack-mounted enclosure with flexible hardware expansion capabilities. Its architecture supports different processor and storage configurations, allowing industrial system integrators to adapt the computer to specific production and monitoring requirements.
A major advantage of this platform is its extensive expansion architecture. Five PCI Express slots and two conventional PCI slots provide integration options for specialized communication interfaces, data acquisition devices, and other industrial peripherals. Dual Intel Gigabit Ethernet interfaces further support communication with factory networks and automation controllers.
The computer also incorporates temperature and fan monitoring, watchdog functionality, and configurable industrial power supply options. These features help maintenance teams monitor hardware conditions and support stable operation in industrial environments.
For manufacturing facilities, automation engineers, and industrial equipment maintenance providers, the SIMATIC IPC547G offers a practical computing solution for established PC-based automation systems. Its flexible architecture makes it suitable for production monitoring, SCADA applications, industrial data processing, and machine integration.
The exact internal configuration of order number 6AG4104-4DA12-2XX3 should be confirmed before procurement, particularly the processor, memory, storage, operating system, and power supply specifications.
Technical Specifications Parameter
Specification
Manufacturer
Siemens
Order Number
6AG4104-4DA12-2XX3
Product Family
SIMATIC IPC
Platform Model
IPC547G
Product Type
Industrial Rack PC
Chassis Format
19-inch rack-mounted
Rack Height
4U
Processor Family
Intel Pentium / Core i5 / Core i7 / Xeon E3
Processor Model
Configuration dependent
Chipset
Intel H110 / C236, depending on configuration
Memory Type
DDR4 SDRAM
Memory Capacity
Configuration dependent
Ethernet Interfaces
2 × Intel Gigabit Ethernet
Front USB
2 × USB 3.0
Rear USB
2 × USB 3.0 and 4 × USB 2.0
Display Interfaces
DVI-D / DisplayPort, depending on configuration
Expansion Slots
5 × PCI Express, 2 × PCI
Storage
HDD / SSD
RAID Support
Available on selected configurations
Optical Drive
DVD±RW, configuration dependent
Monitoring Functions
Temperature and fan monitoring
System Protection
Watchdog
Power Supply
100–240 V AC
Redundant Power Supply
Optional, configuration dependent
Installation
Horizontal or vertical
Dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm
Net Weight
17 kg, standard documented configuration
Product Lifecycle
Discontinued
Dimensions and weight are based on Siemens SIMATIC IPC547G standard-enclosure specifications. Actual weight can range from 15 to 23 kg depending on the installed equipment. Exact configuration for the requested ordering number requires confirmation.
Recommended Companion Models Model Number
Product Name
6AG4104-4DA12-3BX2
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB RAM, 1 TB HDD
6AG4104-4DA12-3EX2
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB RAM, 1 TB HDD, Windows 10 Enterprise
6AG4104-4DA22-0BX2
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 16 GB RAM, 1 TB HDD
6AG4104-4DA15-3BX2
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB RAM, 1 TB HDD
Frequently Selected Alternatives Model Number
Product Name
6AG4104-4DB12-0BX1
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, Dual 1 TB HDD, 8 GB RAM
6AG4104-4DB21-0XX0
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, Dual 1 TB HDD, 16 GB RAM
6AG4104-4DD12-2BX0
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 480 GB SSD, 8 GB RAM
6AG4104-4DD20-0BX2
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 480 GB SSD, 16 GB RAM
Where It Excels in Industrial Use - Industrial Production Management: Provides a centralized computing platform for collecting production information, monitoring equipment conditions, and coordinating manufacturing operations.
- Factory Automation Systems: Supports PC-based automation applications that require flexible hardware integration and communication with industrial controllers.
- SCADA and HMI Visualization: Handles industrial visualization software, operator interfaces, process monitoring, and alarm management in manufacturing environments.
- Industrial Data Processing: Supports production data collection, equipment performance analysis, and communication between automation devices and supervisory systems.
- Machine Control Integration: Accommodates compatible PCI Express and PCI expansion cards for specialized communication, measurement, and control applications.
- Centralized Control Rooms: Its 19-inch rack-mounted design makes it suitable for industrial control cabinets, equipment rooms, and centralized monitoring stations.
Key Strengths at a Glance - Industrial Computing Architecture: Based on the Siemens SIMATIC IPC547G platform, designed for demanding industrial computing applications.
- Flexible Expansion Capacity: Seven expansion slots, including five PCI Express and two PCI slots, provide extensive hardware integration options.
- Dual Gigabit Ethernet: Two Intel Gigabit Ethernet interfaces support communication with PLCs, industrial networks, and supervisory computers.
- Hardware Condition Monitoring: Integrated temperature and fan monitoring help maintenance personnel identify abnormal operating conditions.
- Watchdog Supervision: Supports system monitoring and configured responses to unexpected operating conditions.
- Configurable Hardware: Supports different processor, memory, and storage configurations according to application requirements.
- Industrial Rack Compatibility: The 4U enclosure allows convenient installation in standard 19-inch industrial equipment cabinets.
Technical FAQs Q1: What is the primary function of the Siemens 6AG4104-4DA12-2XX3?
The requested ordering number belongs to the SIMATIC IPC547G product family, an industrial rack PC platform designed for automation computing, process visualization, and manufacturing data management. The exact configuration associated with this suffix requires confirmation.
Q2: Which processor architecture does the IPC547G support?
The IPC547G family supports selected Intel Pentium G4400, Core i5-6500, Core i7-6700, and Xeon E3-1275 v5 processor configurations. The installed processor depends on the specific hardware variant.
Q3: How many expansion slots are available?
The IPC547G provides seven expansion slots, consisting of five PCI Express slots and two conventional PCI slots for compatible industrial expansion devices.
Q4: Does the system support dual Ethernet communication?
Yes. The platform provides two Intel Gigabit Ethernet interfaces for connecting industrial controllers, network switches, and supervisory systems.
Q5: Can this industrial computer be integrated with Siemens PLCs?
Yes. It can communicate with compatible Siemens SIMATIC PLCs through supported industrial Ethernet protocols and suitable automation software.
Q6: Does the IPC547G support multiple storage configurations?
Yes. The product family supports internal HDD and SSD configurations. Selected variants also provide RAID functionality for applications requiring additional storage protection.
Q7: What hardware monitoring functions are included?
The platform provides temperature and fan monitoring to help maintenance personnel identify abnormal hardware conditions and perform preventive maintenance.
Q8: What is the function of the integrated watchdog?
The watchdog monitors system activity and can initiate a predefined response when abnormal operating conditions are detected, helping improve application reliability.
Q9: Can additional industrial communication cards be installed?
Yes. Compatible PCI Express and PCI expansion cards can extend the system's communication capabilities for specialized industrial networks, measurement equipment, and data acquisition applications.
Q10: What should be checked before replacing an existing IPC547G?
Users should verify the processor, motherboard chipset, memory, storage configuration, expansion cards, operating system, BIOS settings, and power supply requirements to maintain compatibility with the existing automation system.
