Introduction The Siemens 6AG4104-4DA12-3XX3 is a requested ordering designation associated with the SIMATIC IPC547G industrial rack PC family. This platform is designed to provide flexible computing resources for manufacturing operations, industrial automation, and centralized process management.
Featuring a 19-inch, 4U rack-mounted enclosure, the IPC547G combines industrial hardware construction with extensive expansion capabilities. Its architecture supports different processor and storage configurations, allowing system integrators to adapt the computer to specific production and control requirements.
A key advantage of the platform is its seven-slot expansion architecture. Five PCI Express slots and two conventional PCI slots provide integration options for specialized communication adapters, data acquisition hardware, and other industrial peripherals. Dual Intel Gigabit Ethernet interfaces further support connections to automation controllers and factory networks.
The IPC547G also incorporates temperature and fan monitoring, watchdog functionality, and industrial power supply options. These features provide useful diagnostic capabilities for maintenance teams responsible for keeping production computing systems operational.
For industrial operators, automation engineers, and system integrators, the SIMATIC IPC547G offers a practical computing foundation for SCADA applications, production monitoring, machine integration, and industrial data processing.
The exact configuration of the 6AG4104-4DA12-3XX3 suffix should be verified before procurement, particularly its processor, memory, storage devices, operating system, and power supply arrangement.
Technical Specifications Parameter
Specification
Manufacturer
Siemens
Order Number
6AG4104-4DA12-3XX3
Product Family
SIMATIC IPC
Model
IPC547G
Product Type
Industrial Rack PC
Chassis Format
19-inch rack-mounted
Rack Height
4U
Processor Family
Intel Pentium / Core i5 / Core i7 / Xeon E3
Processor Model
Configuration dependent
Chipset
Intel H110 / C236
Memory Type
DDR4 SDRAM
Memory Capacity
Configuration dependent
Ethernet Interfaces
2 × Intel Gigabit Ethernet
Front USB
2 × USB 3.0
Rear USB
2 × USB 3.0 and 4 × USB 2.0
Display Interfaces
DVI-D / DisplayPort, depending on motherboard
Expansion Slots
5 × PCI Express, 2 × PCI
Storage
HDD / SSD
RAID Support
Available on selected configurations
Optical Drive
DVD±RW, configuration dependent
System Monitoring
Temperature and fan monitoring
Protection Function
Watchdog
Power Supply
100–240 V AC
Redundant Power Supply
Optional, configuration dependent
Installation
Horizontal or vertical
Dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm
Weight
15–23 kg, depending on equipment
Product Lifecycle
Discontinued
Dimensions and weight refer to the standard SIMATIC IPC547G enclosure. The exact net weight and internal hardware configuration of 6AG4104-4DA12-3XX3 require confirmation.
Recommended Companion Models Model Number
Product Name
6AG4104-4DA12-3BX2
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB RAM, 1 TB HDD
6AG4104-4CA12-1DX1
Siemens SIMATIC IPC547G Core i5-6500 Industrial Rack PC, 8 GB RAM, 1 TB HDD
6AG4104-4GK13-1BX2
Siemens SIMATIC IPC547G Core i5-6500 Industrial Rack PC, 8 GB RAM, 480 GB SSD, Redundant Power Supply
6AG4104-4JP22-0BB1
Siemens SIMATIC IPC547G Xeon E3-1275 v5 Industrial Rack PC, 16 GB RAM, RAID1
Frequently Selected Alternatives Model Number
Product Name
6AG4104-4DA11-0BX3
Siemens SIMATIC IPC547G Industrial Rack PC, Core i7 Configuration
6AG4104-4HA12-0XX1
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB RAM, 1 TB HDD
6AG4104-4CA00-0BX2
Siemens SIMATIC IPC547G Core i5-6500 Industrial Rack PC, 4 GB RAM, 1 TB HDD
6AG4104-5JD12-3BX0
Siemens SIMATIC IPC547J Industrial Rack PC, Core i7 Configuration
Where It Excels in Industrial Use - Factory Automation: Provides an industrial computing platform for production supervision, machine monitoring, and automated manufacturing operations.
- Process Visualization: Supports HMI and SCADA applications for displaying production parameters, monitoring equipment status, and managing industrial alarms.
- Manufacturing Data Management: Handles production information, equipment records, and communication between factory automation systems and supervisory platforms.
- Industrial Network Integration: Supports communication with PLCs, industrial switches, and other network-connected equipment through Gigabit Ethernet interfaces.
- Machine Control Applications: Accommodates compatible PCI Express and PCI expansion cards for specialized communication, measurement, and control requirements.
- Centralized Control Stations: Its 19-inch, 4U rack-mounted design makes it suitable for industrial control rooms, equipment cabinets, and centralized monitoring environments.
Key Strengths at a Glance - Industrial Computing Platform: Built on the Siemens SIMATIC IPC547G architecture for demanding industrial applications.
- Flexible Expansion Capacity: Seven expansion slots, comprising five PCI Express and two PCI slots, support a wide range of industrial peripherals.
- Dual Gigabit Ethernet: Two Intel Gigabit Ethernet interfaces provide connectivity for industrial networks and automation equipment.
- System Health Monitoring: Integrated temperature and fan monitoring help maintenance personnel identify abnormal hardware conditions.
- Watchdog Supervision: Provides system monitoring capabilities to support dependable industrial computer operation.
- Flexible Installation: Supports horizontal and vertical installation, with provisions for telescopic rails and optional tower conversion.
- Industrial Power Compatibility: Supports 100–240 V AC input, with redundant power supply options available for selected configurations.
Technical FAQs Q1: What is the main function of the Siemens 6AG4104-4DA12-3XX3?
The requested ordering number is associated with the SIMATIC IPC547G industrial rack PC family, designed for industrial computing, production monitoring, process visualization, and PC-based automation applications. The exact hardware configuration of this suffix requires confirmation.
Q2: Which processor configurations are available for the IPC547G platform?
The IPC547G family supports Intel Pentium G4400, Core i5-6500, Core i7-6700, and Xeon E3-1275 v5 processor configurations. The actual processor depends on the selected hardware variant.
Q3: How many expansion slots does the IPC547G provide?
The platform provides seven expansion slots, including five PCI Express slots and two conventional PCI slots for compatible industrial expansion cards.
Q4: Does the IPC547G support dual Ethernet connectivity?
Yes. The platform provides two Intel Gigabit Ethernet interfaces for connecting industrial controllers, network switches, and supervisory computers.
Q5: Can the IPC547G be integrated with Siemens SIMATIC PLC systems?
Yes. It can communicate with compatible SIMATIC controllers through supported industrial Ethernet protocols and appropriate Siemens automation software.
Q6: What storage configurations are supported?
The IPC547G family supports internal HDD and SSD configurations. Selected variants also provide RAID functionality for applications requiring additional storage protection and availability.
Q7: Does the industrial PC provide hardware monitoring?
Yes. Integrated temperature and fan monitoring functions help maintenance personnel identify abnormal operating conditions and perform preventive maintenance.
Q8: What is the purpose of the watchdog function?
The watchdog monitors system activity and can initiate a predefined response when abnormal computer operation is detected, helping support reliable industrial applications.
Q9: Can additional industrial communication interfaces be installed?
Yes. Compatible PCI Express and PCI expansion cards can extend communication capabilities for specialized industrial networks, measurement equipment, and data acquisition applications.
Q10: What should be checked before replacing this IPC547G model?
Users should verify the processor, motherboard chipset, memory, storage arrangement, expansion cards, operating system, BIOS settings, and power supply requirements to maintain compatibility with the existing automation installation.
