Introduction The Siemens 6AG4104-4DA12-5XX3 is a requested ordering designation associated with the SIMATIC IPC547G industrial rack PC family. This platform is designed to provide flexible computing resources for industrial automation, manufacturing operations, and centralized process management.
Featuring a 19-inch, 4U rack-mounted enclosure, the IPC547G combines industrial hardware construction with extensive expansion capabilities. Its architecture supports different processor and storage configurations, allowing system integrators to adapt the computer to specific production and control requirements.
One of its main advantages is the seven-slot expansion architecture. Five PCI Express slots and two conventional PCI slots provide integration options for specialized communication adapters, data acquisition devices, and industrial peripherals. Dual Intel Gigabit Ethernet interfaces further support connections to automation controllers and factory networks.
The IPC547G also incorporates temperature and fan monitoring, watchdog functionality, and configurable industrial power supply options. These features provide useful diagnostic capabilities for maintenance teams responsible for maintaining stable computing operations.
For manufacturing facilities, automation engineers, and industrial system integrators, the SIMATIC IPC547G offers a practical computing foundation for SCADA applications, production monitoring, machine integration, and industrial data processing.
The exact configuration associated with 6AG4104-4DA12-5XX3 should be confirmed before procurement, particularly its processor, memory, storage devices, operating system, and power supply arrangement.
Technical Specifications Parameter
Specification
Manufacturer
Siemens
Order Number
6AG4104-4DA12-5XX3
Product Family
SIMATIC IPC
Platform Model
IPC547G
Product Type
Industrial Rack PC
Chassis Format
19-inch rack-mounted
Rack Height
4U
Processor Family
Intel Pentium / Core i5 / Core i7 / Xeon E3
Processor Model
Configuration dependent
Chipset
Intel H110 / C236
Memory Type
DDR4 SDRAM
Memory Capacity
Configuration dependent
Ethernet Interfaces
2 × Intel Gigabit Ethernet
Front USB
2 × USB 3.0
Rear USB
2 × USB 3.0 and 4 × USB 2.0
Display Interfaces
DVI-D / DisplayPort, depending on motherboard
Expansion Slots
5 × PCI Express, 2 × PCI
Storage
HDD / SSD
RAID Support
Available on selected configurations
Optical Drive
DVD±RW, configuration dependent
Monitoring Functions
Temperature and fan monitoring
System Protection
Watchdog
Power Supply
100–240 V AC
Redundant Power Supply
Optional, configuration dependent
Installation
Horizontal or vertical
Dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm
Weight
15–23 kg, depending on equipment
Product Lifecycle
Discontinued
Dimensions and weight refer to the standard SIMATIC IPC547G enclosure. Actual weight depends on the installed processor, storage drives, expansion cards, and power supply. The exact configuration of 6AG4104-4DA12-5XX3 has not been independently confirmed.
Recommended Companion Models Model Number
Product Name
6AG4104-4DA12-3BX2
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB RAM, 1 TB HDD
6AG4104-4CA12-1DX1
Siemens SIMATIC IPC547G Core i5-6500 Industrial Rack PC, 8 GB RAM, 1 TB HDD
6AG4104-4GK13-1BX2
Siemens SIMATIC IPC547G Core i5-6500 Industrial Rack PC, 8 GB RAM, 480 GB SSD, Redundant Power Supply
6AG4104-4HF11-0HX0
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB RAM, RAID1, Windows Server 2016
Frequently Selected Alternatives Model Number
Product Name
6AG4104-4DA12-2EX1
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB RAM, 1 TB HDD, Windows 10 Enterprise
6AG4104-4CA00-0BX2
Siemens SIMATIC IPC547G Core i5-6500 Industrial Rack PC, 4 GB RAM, 1 TB HDD
6AG4104-4DA12-3BX2
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB RAM, 1 TB HDD
6AG4104-4CA12-1DX1
Siemens SIMATIC IPC547G Core i5-6500 Industrial Rack PC, 8 GB RAM, 1 TB HDD
Where It Excels in Industrial Use - Industrial Automation: Provides a centralized computing platform for factory automation, machine supervision, and PC-based control applications requiring flexible hardware integration.
- Production Line Monitoring: Supports manufacturing process visualization, equipment status monitoring, and production data management across industrial facilities.
- SCADA and HMI Applications: Provides a suitable computing foundation for supervisory control, operator interfaces, alarm management, and industrial visualization software.
- Industrial Data Acquisition: Supports compatible expansion cards for collecting measurement signals, processing equipment data, and integrating external industrial devices.
- Machine Vision and Inspection: Accommodates compatible PCI Express graphics and acquisition hardware for automated inspection and industrial image processing.
- Centralized Control Systems: Its 19-inch rack-mounted construction makes it suitable for industrial control cabinets, equipment rooms, and centralized monitoring stations.
Key Strengths at a Glance - Industrial Computing Performance: The IPC547G platform supports Intel Core and Xeon processor configurations for demanding industrial computing workloads.
- Extensive Expansion Architecture: Five PCI Express slots and two PCI slots provide flexibility for integrating specialized industrial peripherals.
- Dual Gigabit Ethernet: Two Intel Gigabit Ethernet interfaces support communication with PLCs, industrial switches, and supervisory systems.
- Comprehensive Hardware Monitoring: Temperature and fan monitoring functions help maintenance teams identify abnormal operating conditions.
- Watchdog Protection: Supports system supervision and configured responses to unexpected operating conditions.
- Flexible Storage Architecture: Supports different internal HDD and SSD arrangements, including selected RAID configurations.
- Industrial Rack Installation: The 4U chassis allows convenient integration into standard 19-inch industrial equipment cabinets.
Technical FAQs Q1: What is the primary function of the Siemens 6AG4104-4DA12-5XX3?
The requested ordering number is associated with the SIMATIC IPC547G industrial rack PC family, designed for industrial computing, production monitoring, process visualization, and PC-based automation applications. The exact hardware configuration of this suffix requires confirmation.
Q2: Which processor architectures are supported by the IPC547G?
The IPC547G platform supports selected Intel Pentium G4400, Core i5-6500, Core i7-6700, and Xeon E3-1275 v5 processor configurations. The installed processor depends on the specific hardware variant.
Q3: How many expansion slots are available?
The IPC547G provides seven expansion slots, consisting of five PCI Express slots and two conventional PCI slots for compatible industrial expansion cards.
Q4: Does the IPC547G support dual Gigabit Ethernet communication?
Yes. The platform provides two Intel Gigabit Ethernet interfaces for connecting industrial controllers, network switches, supervisory computers, and other networked equipment.
Q5: Can this computer be integrated with Siemens SIMATIC PLC systems?
Yes. It can communicate with compatible SIMATIC controllers through supported industrial Ethernet protocols and suitable Siemens automation software.
Q6: What storage technologies are supported?
The IPC547G family supports internal HDD and SSD storage configurations. Selected hardware variants also support RAID arrangements for improved storage availability and data protection.
Q7: Does the IPC547G include hardware diagnostic functions?
Yes. Integrated temperature and fan monitoring functions help maintenance personnel identify abnormal operating conditions and support preventive maintenance.
Q8: How does the watchdog function improve system operation?
The watchdog monitors system activity and can initiate a predefined response when abnormal computer operation is detected, helping support dependable industrial applications.
Q9: Can additional industrial communication cards be installed?
Yes. Compatible PCI Express and PCI cards can extend communication capabilities for specialized industrial networks, measurement equipment, and data acquisition systems.
Q10: What should be considered when replacing an existing IPC547G?
Users should verify the processor, motherboard chipset, memory capacity, storage arrangement, expansion cards, operating system, BIOS settings, and power supply requirements to maintain compatibility with the existing automation installation.
