Introduction The Siemens 6AG4104-4DA13-0XX3 is an ordering designation associated with the SIMATIC IPC547G industrial rack PC series. This platform is designed for industrial computing environments that require flexible hardware integration, dependable network communication, and convenient rack-mounted installation.
The IPC547G combines an industrial 19-inch chassis with an extensive expansion architecture. Its seven expansion positions provide opportunities to integrate specialized communication cards, data acquisition devices, and other industrial peripherals. This flexibility makes the platform suitable for different automation and manufacturing applications.
Network connectivity is another important characteristic. Dual Intel Gigabit Ethernet interfaces support communication with industrial controllers, production networks, and supervisory systems. Depending on the motherboard configuration, additional interfaces include USB, DisplayPort, DVI-D, PS/2, and serial connections.
For maintenance teams and system integrators, the platform also provides temperature monitoring, fan supervision, and watchdog functionality. These features help support equipment diagnostics and ongoing system maintenance.
The SIMATIC IPC547G offers a practical computing foundation for production monitoring, industrial visualization, machine integration, and manufacturing data processing. Its established architecture makes it particularly relevant to facilities maintaining existing PC-based automation infrastructure.
The exact processor, memory, storage, and operating system configuration of 6AG4104-4DA13-0XX3 should be confirmed from the original product identification label before procurement.
Technical Specifications Parameter
Specification
Manufacturer
Siemens
Order Number
6AG4104-4DA13-0XX3
Product Family
SIMATIC IPC
Platform Model
IPC547G
Product Type
Industrial Rack PC
Chassis Format
19-inch rack-mounted
Rack Height
4U
Processor Family
Intel Pentium / Core i5 / Core i7 / Xeon E3
Processor Model
Configuration dependent
Chipset
Intel H110 / C236, depending on configuration
Memory Type
DDR4 SDRAM
Maximum Memory
Up to 64 GB
Ethernet Interfaces
2 × Intel Gigabit Ethernet
USB Interfaces
USB 3.0 / USB 2.0
Display Interfaces
DisplayPort / DVI-D, configuration dependent
Expansion Slots
5 × PCI Express, 2 × PCI
Storage
HDD / SSD
RAID Support
Available on selected configurations
Serial Interface
COM1 / optional COM2
Monitoring Functions
Temperature and fan monitoring
System Protection
Watchdog
Power Supply
100–240 V AC
Redundant Power Supply
Available on selected configurations
Installation
Horizontal or vertical
Dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm
Weight
15–23 kg, depending on equipment
Product Lifecycle
Discontinued
Dimensions and weight refer to the standard IPC547G enclosure. The short-enclosure version measures 481.4 × 176.6 × 356.6 mm. The exact weight and internal configuration of the requested order number have not been independently confirmed.
西门子工业网 +1
Recommended Companion Models Model Number
Product Name
6AG4104-4DA12-3BX2
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB RAM, 1 TB HDD
6AG4104-4CA12-1DX1
Siemens SIMATIC IPC547G Core i5-6500 Industrial Rack PC, 8 GB RAM, 1 TB HDD
6AG4104-4GK13-1BX2
Siemens SIMATIC IPC547G Core i5-6500 Industrial Rack PC, 8 GB RAM, 480 GB SSD, Redundant Power Supply
6AG4104-4CA00-0BX2
Siemens SIMATIC IPC547G Core i5-6500 Industrial Rack PC, 4 GB RAM, 1 TB HDD
Frequently Selected Alternatives Model Number
Product Name
6AG4104-4DC22-0EX3
Siemens SIMATIC IPC547G Industrial Rack PC, SSD Configuration
6AG4104-4DD12-0BX1
Siemens SIMATIC IPC547G Industrial Rack PC, SSD Configuration
6AG4104-4DD20-2BX0
Siemens SIMATIC IPC547G Industrial Rack PC, SSD Configuration
6AG4104-4DA23-2HX1
Siemens SIMATIC IPC547G Industrial Rack PC, Configurable Hardware Version
Where It Excels in Industrial Use - Factory Automation: Provides a centralized industrial computing platform for production supervision, machine monitoring, and PC-based automation applications.
- Process Visualization: Supports HMI and SCADA environments for displaying operating parameters, monitoring equipment status, and managing production alarms.
- Manufacturing Data Processing: Handles production information, equipment records, and communication between automation devices and supervisory systems.
- Industrial Network Integration: Supports connections to PLCs, industrial switches, and factory information systems through Gigabit Ethernet connectivity.
- Machine Control Integration: Accommodates compatible PCI Express and PCI expansion cards for specialized communication, measurement, and industrial control applications.
- Centralized Monitoring Stations: Its 19-inch rack-mounted architecture makes it suitable for control rooms, industrial cabinets, and centralized equipment monitoring installations.
Key Strengths at a Glance - Industrial Computing Platform: Based on Siemens SIMATIC IPC547G architecture for demanding manufacturing and automation environments.
- Flexible Hardware Expansion: Seven expansion slots, including five PCI Express and two PCI slots, provide options for specialized industrial peripherals.
- Dual Ethernet Connectivity: Two Intel Gigabit Ethernet interfaces support communication with PLCs and industrial networks.
- Intelligent Hardware Monitoring: Temperature and fan monitoring help maintenance teams identify abnormal operating conditions.
- Integrated Watchdog: Supports system supervision and configured responses to unexpected operating conditions.
- Flexible Storage Architecture: Supports HDD and SSD configurations, with RAID functionality available on selected hardware variants.
- Industrial Rack Construction: The 4U enclosure provides convenient integration into standard 19-inch equipment cabinets.
Technical FAQs Q1: What is the primary function of the Siemens 6AG4104-4DA13-0XX3?
The requested designation is associated with the SIMATIC IPC547G product family, an industrial rack computer platform designed for automation computing, process visualization, and manufacturing data management. Its exact hardware configuration requires confirmation.
Q2: Which processor architecture does the IPC547G support?
The IPC547G family supports selected Intel Pentium, Core i5, Core i7, and Xeon E3 processor configurations. The actual processor depends on the installed motherboard and ordering variant.
Q3: How many expansion slots are available?
The platform provides seven expansion slots, including five PCI Express slots and two conventional PCI slots for compatible industrial expansion cards.
Q4: Does the IPC547G support dual Ethernet connectivity?
Yes. The platform provides two Intel Gigabit Ethernet interfaces with RJ45 connectors, supporting industrial network communication and compatible teaming configurations.
Q5: Can the IPC547G communicate with Siemens SIMATIC PLCs?
Yes. It can communicate with compatible SIMATIC controllers through supported industrial Ethernet protocols and suitable Siemens automation software.
Q6: Does the platform support SSD storage?
Yes. The IPC547G family supports internal HDD and SSD configurations. Selected variants also provide RAID storage functionality.
Q7: What hardware monitoring functions are integrated?
The system provides temperature and fan monitoring, status indicators, and diagnostic functions that help maintenance personnel identify abnormal hardware conditions.
Q8: What is the purpose of the watchdog function?
The watchdog monitors system activity and can initiate a predefined response when abnormal computer operation is detected, supporting unattended industrial applications.
Q9: Can additional communication interfaces be installed?
Yes. Compatible PCI Express and PCI expansion cards can extend communication capabilities for industrial networks, measurement equipment, and specialized automation devices.
Q10: Which software environments are suitable for the IPC547G?
Depending on the hardware configuration, the platform supports compatible Windows-based industrial computing environments, including selected Windows 7, Windows 10 Enterprise, and Windows Server versions.
