Introduction The Siemens 6AG4104-4DA15-2BX3 is an ordering designation associated with the SIMATIC IPC547G industrial rack PC family. Designed for industrial computing environments, the platform combines flexible processing capabilities, extensive expansion options, and a rack-mounted enclosure suitable for manufacturing infrastructure.
The IPC547G architecture supports multiple processor configurations, including selected Intel Core i7-based variants. Its seven expansion slots provide flexibility for installing specialized communication adapters, data acquisition cards, and other industrial peripherals.
For network integration, the platform provides two Intel Gigabit Ethernet interfaces, allowing communication with automation controllers, industrial switches, and supervisory systems. Its USB, display, PS/2, and optional serial interfaces further support integration with different industrial devices.
Temperature and fan monitoring, together with watchdog functionality, provide useful diagnostic capabilities for maintenance personnel. These features help support equipment supervision and ongoing system maintenance.
The SIMATIC IPC547G is suitable for production monitoring, SCADA applications, industrial data processing, and machine integration. Its established hardware architecture makes it a practical option for industrial facilities maintaining existing PC-based automation systems.
The precise configuration of 6AG4104-4DA15-2BX3 should be verified before purchase. In particular, processor, memory, storage, operating system, and power supply details should not be assumed from another 4DA15 suffix.
Technical Specifications Parameter
Specification
Manufacturer
Siemens
Order Number
6AG4104-4DA15-2BX3
Product Family
SIMATIC IPC
Platform Model
IPC547G
Product Type
Industrial Rack PC
Chassis Format
19-inch rack-mounted
Rack Height
4U
Processor Family
Intel Core i7 family, configuration dependent
Processor Model
Exact variant requires confirmation
Chipset
Intel H110
Memory Type
DDR4 SDRAM
Memory Capacity
Configuration dependent
Memory Architecture
Single / Dual Channel
Ethernet Interfaces
2 × Intel Gigabit Ethernet
Front USB
2 × USB 3.0
Rear USB
2 × USB 3.0, 4 × USB 2.0
Display Interfaces
DVI-D / DisplayPort
Expansion Slots
5 × PCI Express, 2 × PCI
Storage Options
HDD / SSD
RAID Support
Configuration dependent
Serial Interface
Optional COM2
Parallel Interface
Optional LPT
Monitoring Functions
Temperature and fan monitoring
System Protection
Watchdog
Power Supply
100–240 V AC
Installation
Rack-mounted
Dimensions (W × H × D)
Approximately 430 × 177 × 446 mm
Reference Weight
Approximately 17 kg
Product Lifecycle
Discontinued
Dimensions and weight are reference values for the IPC547G enclosure, not independently confirmed measurements for the exact -2BX3 configuration. The documented 6AG4104-4DA15-3BX2 variant has an Intel Core i7-6700, 8 GB DDR4 RAM, 1 TB HDD, painted enclosure, and Windows 7 Ultimate. These details should not automatically be attributed to -2BX3.
Recommended Companion Models Model Number
Product Name
6AG4104-4DA15-3BX2
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB RAM, 1 TB HDD, Windows 7 Ultimate
6AG4104-4DA16-0CX1
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB RAM, 1 TB HDD, Windows 10 Enterprise LTSB
6AG4104-4DA22-0BX2
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 16 GB RAM, 1 TB HDD, Windows 7 Ultimate
6AG4104-4DA23-2HX1
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 16 GB RAM, Dual HDD, Redundant Power Supply
Frequently Selected Alternatives Model Number
Product Name
6AG4104-4DA12-3BX2
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB RAM, 1 TB HDD
6AG4104-4DB12-0BX1
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB RAM, Dual 1 TB HDD
6AG4104-4DK21-0KX2
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 16 GB RAM, 480 GB SSD
6AG4104-4DA11-1EX0
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB RAM, 1 TB HDD, Windows 10 IoT Enterprise
Where It Excels in Industrial Use - Factory Automation: Provides an industrial computing platform for production supervision, machine monitoring, and PC-based automation applications requiring flexible hardware integration.
- SCADA and HMI Systems: Supports industrial visualization, operator interfaces, process monitoring, and alarm management across manufacturing environments.
- Production Data Processing: Handles manufacturing information, equipment records, and communication between automation devices and supervisory systems.
- Industrial Network Integration: Supports connections to PLCs, industrial switches, and factory information systems through dual Gigabit Ethernet interfaces.
- Machine Control Applications: Accommodates compatible PCI Express and PCI expansion cards for specialized communication, measurement, and control requirements.
- Centralized Control Stations: Its 19-inch rack-mounted architecture makes it suitable for industrial control cabinets, monitoring rooms, and centralized computing installations.
Key Strengths at a Glance - Intel Core i7 Processing Platform: The documented 6AG4104-4DA15 configuration family includes Core i7-6700 variants, providing four cores and eight threads for industrial computing workloads.
- Extensive Expansion Capacity: Five PCI Express slots and two PCI slots support integration of specialized industrial peripherals.
- Dual Gigabit Ethernet: Two Intel Gigabit Ethernet interfaces support communication with automation controllers and industrial networks.
- DDR4 Memory Architecture: Supports dual-channel memory configurations for industrial applications requiring stable multitasking performance.
- Hardware Monitoring: Temperature and fan monitoring help maintenance personnel identify abnormal operating conditions.
- Industrial Rack Construction: The 4U enclosure supports organized installation in standard 19-inch equipment cabinets.
- Flexible Connectivity: USB, display, PS/2, and optional serial and parallel interfaces accommodate different industrial equipment requirements.
Technical FAQs Q1: What is the primary function of the Siemens 6AG4104-4DA15-2BX3?
It belongs to the SIMATIC IPC547G industrial rack PC product family, designed for industrial computing, production monitoring, and PC-based automation applications. The exact hardware configuration of the -2BX3 suffix requires individual confirmation.
Q2: Which processor is associated with the IPC547G 4DA15 configuration family?
A documented 6AG4104-4DA15 variant uses the Intel Core i7-6700 processor, featuring four cores, eight threads, a 3.4 GHz base frequency, and a maximum turbo frequency of 4.0 GHz.
Q3: Does the IPC547G support PCI Express expansion?
Yes. The platform provides five PCI Express slots and two conventional PCI slots for compatible industrial communication, measurement, and data acquisition cards.
Q4: How many Ethernet interfaces are available?
The IPC547G provides two Intel Gigabit Ethernet interfaces, supporting connections to industrial controllers, network switches, and supervisory systems.
Q5: Can the IPC547G communicate with SIMATIC PLCs?
Yes. It can communicate with compatible SIMATIC controllers through supported Ethernet protocols and appropriate Siemens automation software.
Q6: Does the IPC547G support dual-channel memory?
Yes. Compatible configurations support dual-channel DDR4 memory. The actual memory capacity and module arrangement depend on the selected hardware variant.
Q7: What storage devices can be installed?
The platform supports internal HDD and SSD storage options. Selected configurations also provide RAID functionality through compatible storage controllers.
Q8: Does the IPC547G provide hardware diagnostic capabilities?
Yes. Temperature and fan monitoring, together with watchdog functionality, help maintenance teams identify abnormal operating conditions and supervise system activity.
Q9: Can the system support additional serial communication interfaces?
Compatible configurations can provide additional serial interfaces through motherboard connections or expansion hardware, depending on the selected configuration.
Q10: Which factors should be considered when upgrading this industrial computer?
Check processor compatibility, memory capacity, storage interfaces, expansion cards, operating system support, BIOS settings, and power supply requirements before replacing or upgrading the existing system.
