Introduction The Siemens 6AG4104-4DA16-0CX1 is a SIMATIC IPC547G industrial rack PC designed for demanding manufacturing and automation environments. Combining Intel Core i7 processing, dedicated industrial hardware, and a preinstalled Windows operating system, this configuration provides a practical computing solution for production facilities and industrial system integrators.
At its core, the system features an Intel Core i7-6700 processor with four cores and eight threads. Paired with 8 GB of DDR4 SDRAM in dual-channel configuration, it provides computing resources for industrial visualization, production monitoring, data processing, and equipment management.
Storage is provided by an internal 1 TB HDD, while integrated Intel HD Graphics 530 supports standard industrial display requirements. The system also includes Windows 10 Enterprise LTSB 2015, 64-bit, helping simplify deployment in compatible industrial software environments.
Connectivity and expansion are important advantages of this IPC547G configuration. Dual Intel Gigabit Ethernet interfaces support integration with factory networks and automation controllers, while five PCI Express slots and two PCI slots provide room for additional industrial hardware.
The painted industrial enclosure, DVD±RW drive, temperature and fan monitoring, and watchdog functionality further contribute to its suitability for established industrial computing installations.
For manufacturers and automation professionals, the 6AG4104-4DA16-0CX1 offers a well-equipped industrial PC solution that combines processing capability, storage capacity, and extensive connectivity in a standardized rack-mounted format.
Technical Specifications Parameter
Specification
Manufacturer
Siemens
Order Number
6AG4104-4DA16-0CX1
Product Family
SIMATIC IPC
Model
IPC547G
Product Type
Industrial Rack PC
Chassis Design
19-inch rack-mounted
Rack Height
4U
Processor
Intel Core i7-6700
Processor Cores
4
Processor Threads
8
Base Frequency
3.4 GHz
Maximum Turbo Frequency
4.0 GHz
Processor Cache
8 MB
Chipset
Intel H110
Memory Type
DDR4 SDRAM
Installed Memory
8 GB
Memory Configuration
2 × 4 GB, Dual Channel
Graphics Controller
Intel HD Graphics 530
Ethernet Interfaces
2 × Intel Gigabit Ethernet
Front USB
2 × USB 3.0
Rear USB
2 × USB 3.0, 4 × USB 2.0
Display Interfaces
1 × DVI-D, 1 × DisplayPort
Other Interfaces
2 × PS/2, Audio
Expansion Slots
5 × PCI Express, 2 × PCI
Internal Storage
1 × 1 TB HDD
Optical Drive
DVD±RW Slim
Operating System
Windows 10 Enterprise LTSB 2015, 64-bit
Language Support
English, German, French, Italian, Spanish
Power Supply
100–240 V AC Industrial Power Supply
Monitoring Functions
Temperature and Fan Monitoring
System Protection
Watchdog
Enclosure Finish
Painted
Installation
Horizontal or Vertical
Dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm
Weight
15–23 kg, depending on equipment
Product Lifecycle
Discontinued
Dimensions and weight follow the standard IPC547G enclosure specifications. Actual weight depends on installed equipment and accessories.
Recommended Companion Models Model Number
Product Name
6AG4104-4HA12-0XX1
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB RAM, 1 TB HDD, Windows Operating System Not Included
6AG4104-4DA22-0HX1
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 16 GB RAM, 1 TB HDD, Windows Server 2016
6AG4104-4GK13-1BX2
Siemens SIMATIC IPC547G Core i5-6500 Industrial Rack PC, 8 GB RAM, 480 GB SSD, Redundant Power Supply
6AG4104-4CA00-0BX2
Siemens SIMATIC IPC547G Core i5-6500 Industrial Rack PC, 4 GB RAM, 1 TB HDD, Windows 7 Ultimate
Frequently Selected Alternatives Model Number
Product Name
6AG4104-4GN16-4BX0
Siemens SIMATIC IPC547G Core i5-6500 Industrial Rack PC, 8 GB RAM, RAID1, Dual 1 TB HDD, Windows 7 Ultimate
6AG4104-4DA12-3BX2
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB RAM, 1 TB HDD
6AG4104-4DA15-3BX2
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB RAM, 1 TB HDD, Windows 7 Ultimate
6AG4104-4DB12-0BX1
Siemens SIMATIC IPC547G Industrial Rack PC, Dual HDD Configuration
Where It Excels in Industrial Use - Factory Automation: Provides a powerful industrial computing platform for production supervision, machine monitoring, and PC-based automation applications.
- SCADA and HMI Operations: Supports industrial visualization, operator interfaces, process monitoring, and alarm management across manufacturing facilities.
- Production Data Management: Handles manufacturing information, equipment records, and communication between automation devices and supervisory systems.
- Industrial Network Integration: Connects PLCs, industrial switches, and factory information systems through dual Intel Gigabit Ethernet interfaces.
- Machine Inspection and Control: Supports compatible PCI Express expansion cards for specialized measurement, image processing, and industrial control applications.
- Centralized Computing Stations: Its 19-inch rack-mounted architecture makes it suitable for industrial control rooms, equipment cabinets, and production monitoring environments.
Key Strengths at a Glance - Intel Core i7-6700 Processor: Features a four-core, eight-thread processor with a 3.4 GHz base frequency and up to 4.0 GHz turbo frequency.
- 8 GB DDR4 Memory: Equipped with 2 × 4 GB DDR4 SDRAM in dual-channel configuration for industrial multitasking.
- Integrated Graphics: Uses Intel HD Graphics 530 for standard industrial visualization and display applications.
- Flexible Expansion Architecture: Provides five PCI Express slots and two PCI slots for additional industrial hardware.
- Dual Gigabit Ethernet: Supports communication with automation controllers, industrial networks, and supervisory systems.
- Windows 10 Enterprise LTSB 2015: Supplied with a 64-bit operating system and multilingual support.
- Industrial Storage: Includes a 1 TB internal HDD for operating system installation, application software, and industrial data storage.
- Hardware Monitoring: Temperature and fan monitoring, together with watchdog functionality, support system supervision and maintenance.
Technical FAQs Q1: Which processor is installed in the Siemens 6AG4104-4DA16-0CX1?
It is equipped with an Intel Core i7-6700 processor featuring four cores, eight threads, a 3.4 GHz base frequency, and a maximum turbo frequency of 4.0 GHz.
Q2: Does this industrial computer support multitasking applications?
Yes. Its Core i7 processor and 8 GB dual-channel DDR4 memory support multiple industrial software applications, including process visualization, equipment monitoring, and production management.
Q3: Which operating system is preinstalled?
The unit comes with Windows 10 Enterprise LTSB 2015, 64-bit, with multilingual support for English, German, French, Italian, and Spanish.
Q4: What graphics controller does the system use?
It uses integrated Intel HD Graphics 530, which supports standard industrial visualization, monitoring interfaces, and compatible display applications.
Q5: Does the IPC547G support additional graphics cards?
Yes. The platform provides PCI Express expansion capability, allowing compatible graphics cards to be installed for applications requiring additional display outputs or graphics performance.
Q6: Can the computer communicate with Siemens PLCs?
Yes. Its dual Intel Gigabit Ethernet interfaces support communication with compatible SIMATIC PLCs and other industrial network devices through appropriate protocols and software.
Q7: What storage capacity is included?
This configuration includes one internal 1 TB HDD for the operating system, industrial applications, and production data storage.
Q8: Does the system support additional industrial expansion cards?
Yes. Five PCI Express slots and two conventional PCI slots provide flexibility for installing compatible communication, measurement, and data acquisition cards.
Q9: What system protection and monitoring functions are available?
The IPC547G includes temperature and fan monitoring, watchdog functionality, and a card retainer to support hardware supervision and secure installation of expansion cards.
Q10: Can the Windows 10 Enterprise LTSB environment support existing industrial software?
It can run compatible 64-bit industrial applications. Before deployment, software versions, hardware drivers, communication protocols, and licensing requirements should be checked for compatibility.
