Introduction The Siemens 6AG4104-4DA16-0XX3 is an ordering designation associated with the SIMATIC IPC547G industrial rack PC family. Designed for manufacturing and automation environments, this platform combines industrial hardware construction, flexible expansion capabilities, and network connectivity to support demanding computing applications.
The IPC547G features a standardized 19-inch, 4U rack-mounted architecture, making it suitable for centralized industrial installations. Its expansion design accommodates five PCI Express cards and two conventional PCI cards, providing flexibility for integrating communication adapters, measurement devices, and specialized automation hardware.
Network connectivity is another important advantage. Dual Intel Gigabit Ethernet interfaces support communication with PLCs, industrial switches, and supervisory systems. Additional USB, display, PS/2, and optional serial interfaces help simplify integration with existing industrial equipment.
The platform also incorporates temperature and fan monitoring, watchdog functionality, and configurable power supply arrangements. These capabilities provide useful tools for system supervision, equipment diagnostics, and preventive maintenance.
For industrial operators, equipment manufacturers, and automation system integrators, the SIMATIC IPC547G offers a versatile computing foundation for SCADA applications, production monitoring, machine integration, and industrial data processing.
The exact processor, memory, storage, and operating system configuration of 6AG4104-4DA16-0XX3 should be verified before procurement. Specifications from other 4DA16 ordering variants should not automatically be applied to this particular suffix.
Technical Specifications Parameter
Specification
Manufacturer
Siemens
Order Number
6AG4104-4DA16-0XX3
Product Family
SIMATIC IPC
Platform Model
IPC547G
Product Type
Industrial Rack PC
Chassis Format
19-inch rack-mounted
Rack Height
4U
Processor Family
Intel Pentium / Core i5 / Core i7 / Xeon E3
Processor Model
Configuration dependent
Chipset
Intel H110 / C236
Memory Type
DDR4 SDRAM
Memory Capacity
Configuration dependent
Memory Architecture
Single / Dual Channel
Graphics
Integrated Intel HD Graphics
Ethernet Interfaces
2 × Intel Gigabit Ethernet
Front USB
2 × USB 3.0
Rear USB
USB 3.0 / USB 2.0
Display Interfaces
DVI-D / DisplayPort
Other Interfaces
PS/2, Audio, optional COM
Expansion Slots
5 × PCI Express, 2 × PCI
Storage Options
HDD / SSD
RAID Support
Available on selected configurations
Optical Drive
DVD±RW, configuration dependent
Monitoring Functions
Temperature and fan monitoring
System Protection
Watchdog
Power Supply
100–240 V AC
Redundant Power Supply
Available on selected configurations
Installation
Horizontal or vertical
Dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm
Weight
15–23 kg, depending on equipment
Product Lifecycle
Discontinued
Dimensions and weight refer to the standard IPC547G enclosure. The short-enclosure version measures 481.4 × 176.6 × 356.6 mm. Actual weight depends on processor, storage, expansion cards, and power supply configuration. The exact enclosure and hardware configuration of -0XX3 require confirmation.
Recommended Companion Models Model Number
Product Name
6AG4104-4DA16-0CX1
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB RAM, 1 TB HDD, Windows 10 Enterprise LTSB 2015
6AG4104-4DA12-3EX2
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB RAM, 1 TB HDD, Windows 10 Enterprise 2016 LTSB
6AG4104-4DA22-0BX2
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 16 GB RAM, 1 TB HDD, Windows 7 Ultimate
6AG4104-4DA23-2HX1
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 16 GB RAM, Dual 1 TB HDD, Redundant Power Supply, Windows Server 2016
Frequently Selected Alternatives Model Number
Product Name
6AG4104-4DB12-0BX1
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB RAM, Dual 1 TB HDD, Windows 7 Ultimate
6AG4104-4DD27-0KX1
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 16 GB RAM, 480 GB SSD, Redundant Power Supply, Windows 10 IoT Enterprise 2019 LTSB
6AG4104-4DK21-0KX2
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 16 GB RAM, 480 GB SSD, Windows 10 IoT Enterprise 2019 LTSB
6AG4104-4GK13-1BX2
Siemens SIMATIC IPC547G Core i5-6500 Industrial Rack PC, 8 GB RAM, 480 GB SSD, Redundant Power Supply, Windows 7 Ultimate
Where It Excels in Industrial Use - Industrial Automation: Provides a centralized computing platform for production supervision, machine monitoring, and PC-based automation applications in manufacturing facilities.
- SCADA and HMI Integration: Supports industrial visualization, operator interfaces, process monitoring, and alarm management for automated production environments.
- Manufacturing Data Processing: Handles production information, equipment records, and communication between automation devices and supervisory systems.
- Industrial Network Communication: Connects PLCs, industrial switches, and factory information systems through dual Intel Gigabit Ethernet interfaces.
- Machine Control and Inspection: Supports compatible PCI Express expansion cards for specialized measurement, image processing, and industrial control applications.
- Centralized Monitoring Stations: Its 19-inch rack-mounted architecture makes it suitable for industrial control rooms, equipment cabinets, and centralized computing installations.
Key Strengths at a Glance - Intel-Based Computing Architecture: The IPC547G platform supports Intel Core i7, Core i5, and Xeon processor configurations for different industrial computing workloads.
- Extensive Expansion Capability: Five PCI Express slots and two conventional PCI slots provide flexibility for integrating specialized industrial peripherals.
- Dual Gigabit Ethernet Connectivity: Two Intel Gigabit Ethernet interfaces support communication with PLCs, industrial switches, and supervisory systems.
- Intelligent Hardware Monitoring: Temperature and fan monitoring functions help maintenance personnel identify abnormal operating conditions.
- Integrated Watchdog Function: Provides system supervision and configured responses to unexpected operating conditions.
- Flexible Storage Architecture: Supports internal HDD and SSD configurations, including selected RAID arrangements.
- Industrial Rack Construction: The 4U enclosure facilitates installation in standard 19-inch industrial equipment cabinets.
Technical FAQs Q1: What is the primary function of the Siemens 6AG4104-4DA16-0XX3?
It belongs to the SIMATIC IPC547G industrial rack PC family, designed for industrial computing, production monitoring, process visualization, and PC-based automation applications. The exact hardware configuration associated with the -0XX3 suffix requires confirmation.
Q2: Which processor architecture does the IPC547G support?
The IPC547G family supports selected Intel Core i5, Core i7, Pentium, and Xeon E3 processors. The installed processor depends on the specific ordering configuration.
Q3: Does the IPC547G support PCI Express expansion cards?
Yes. The platform provides five PCI Express slots and two conventional PCI slots, allowing the installation of compatible communication, measurement, and industrial data acquisition cards.
Q4: How many Ethernet interfaces are available?
The IPC547G provides two Intel Gigabit Ethernet interfaces for connecting automation controllers, industrial switches, and supervisory computers.
Q5: Can this computer communicate with Siemens SIMATIC PLCs?
Yes. It can communicate with compatible SIMATIC controllers through supported industrial Ethernet protocols and appropriate Siemens automation software.
Q6: Does the IPC547G support RAID storage configurations?
Selected configurations support RAID functionality through compatible motherboard chipsets and storage controllers. Available RAID levels depend on the installed hardware and drive arrangement.
Q7: What diagnostic functions are integrated into the system?
The platform provides temperature and fan monitoring, status indicators, and watchdog functionality to help maintenance personnel supervise hardware conditions.
Q8: Can additional industrial communication interfaces be installed?
Yes. Compatible PCI Express and PCI expansion cards can provide additional interfaces for specialized industrial networks, measurement equipment, and automation peripherals.
Q9: Which operating systems are compatible with the IPC547G?
Depending on the hardware configuration, the IPC547G supports compatible Windows-based industrial operating systems, including selected Windows 7, Windows 10 Enterprise, and Windows 10 IoT Enterprise versions.
Q10: Can the IPC547G operate continuously in industrial environments?
The platform is designed for industrial computing applications. Continuous operation depends on appropriate environmental conditions, cooling, power supply stability, maintenance, and application configuration.
