Name: Siemens 6AG4104-4DA18-0XX3 SIMATIC IPC547G Industrial Rack PC
Brand: Siemens
SKU: 23175
Availability: InStock
Rating: 5.0 (1 reviews)

Introduction

The Siemens 6AG4104-4DA18-0XX3 is an ordering designation requested within the SIMATIC IPC547G industrial rack PC product range. This platform is designed for manufacturing facilities and automation environments that require expandable computing hardware, reliable network connectivity, and convenient rack-mounted installation.

The SIMATIC IPC547G features a 19-inch industrial chassis with a 4U form factor. Its seven expansion slots provide substantial flexibility for integrating specialized communication interfaces, data acquisition equipment, and other industrial peripherals.

For network connectivity, the platform incorporates two Intel Gigabit Ethernet interfaces, supporting communication between industrial computers, PLCs, network switches, and supervisory systems. Additional USB, display, PS/2, and optional serial interfaces accommodate different equipment integration requirements.

System monitoring is another important feature. Temperature and fan monitoring, watchdog functionality, and status indicators help maintenance personnel identify potential hardware problems and manage preventive maintenance activities.

The IPC547G is suitable for industrial visualization, manufacturing data processing, machine integration, and centralized production monitoring. Its expandable architecture makes it a practical computing foundation for facilities maintaining established PC-based automation systems.

For procurement purposes, the exact hardware configuration associated with 6AG4104-4DA18-0XX3 should be checked against the original Siemens rating plate or product documentation. Processor, memory, storage, operating system, and power supply specifications should not be inferred from other IPC547G ordering variants.

Technical Specifications

Parameter	Specification
Manufacturer	Siemens
Order Number	6AG4104-4DA18-0XX3
Product Family	SIMATIC IPC
Platform Model	IPC547G
Product Type	Industrial Rack PC
Chassis Format	19-inch rack-mounted
Rack Height	4U
Processor Family	Intel Pentium / Core i5 / Core i7 / Xeon E3
Installed Processor	Requires configuration confirmation
Chipset	Intel H110 / C236
Memory Type	DDR4 SDRAM
Maximum Memory	Up to 64 GB
Memory Configuration	Single / Dual Channel
Ethernet Interfaces	2 × Intel Gigabit Ethernet
Front USB	2 × USB 3.0
Rear USB	Configuration dependent
Display Interfaces	DisplayPort 1.2 / DVI-D
Keyboard and Mouse	2 × PS/2
Serial Interface	COM1 / Optional COM2, configuration dependent
Expansion Slots	5 × PCI Express, 2 × PCI
Storage Options	HDD / SSD
Maximum Storage Configuration	Configuration dependent
RAID Support	Available on selected configurations
Optical Drive	DVD±RW, configuration dependent
Monitoring Functions	Temperature and Fan Monitoring
System Protection	Watchdog
Power Supply	100–240 V AC
Redundant Power Supply	Available on selected configurations
Installation	Horizontal / Vertical
Standard Enclosure Dimensions (W × H × D)	481.4 × 176.6 × 446.6 mm
Short Enclosure Dimensions (W × H × D)	481.4 × 176.6 × 356.6 mm
Net Weight	15–23 kg, depending on configuration
Product Lifecycle	Discontinued

The dimensions and weight are IPC547G platform specifications. Processor, memory, storage, and other configurable parameters above describe the product family rather than confirmed factory-installed components of order number 6AG4104-4DA18-0XX3.

Recommended Companion Models

Model Number	Product Name
6AG4104-4DA12-3BX2	Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB DDR4 RAM, 1 TB HDD, Windows 7 Ultimate
6AG4104-4CA12-1DX1	Siemens SIMATIC IPC547G Core i5-6500 Industrial Rack PC, 8 GB DDR4 RAM, 1 TB HDD, Windows 10 Enterprise 2016 LTSB
6AG4104-4GK13-1BX2	Siemens SIMATIC IPC547G Core i5-6500 Industrial Rack PC, 8 GB DDR4 RAM, 480 GB SSD, Redundant Power Supply
6AG4104-4DA22-0HX1	Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 16 GB DDR4 RAM, 1 TB HDD, Windows Server 2016

Frequently Selected Alternatives

Model Number	Product Name
6AG4104-4HA12-0XX1	Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB DDR4 RAM, 1 TB HDD, Without Operating System
6AG4104-4DC12-0XX3	Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB DDR4 RAM, 240 GB SSD
6AG4104-4GQ18-0DX0	Siemens SIMATIC IPC547G Core i5-6500 Industrial Rack PC, C236 Chipset Configuration
6AG4104-4DB10-0XX1	Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, Dual 1 TB HDD Configuration

Where It Excels in Industrial Use

- Factory Automation: Provides an industrial computing platform for production supervision, machine monitoring, and PC-based automation applications in manufacturing facilities.

- SCADA and HMI Applications: Supports industrial visualization, operator interfaces, process monitoring, and alarm management for automated production systems.

- Manufacturing Data Processing: Handles production information, equipment records, and communication between automation devices and supervisory systems.

- Industrial Network Integration: Connects PLCs, industrial switches, and factory information systems through Gigabit Ethernet interfaces.

- Machine Control and Inspection: Supports compatible PCI Express and PCI expansion cards for specialized measurement, industrial communication, and machine inspection applications.

- Centralized Control Stations: Its 19-inch rack-mounted architecture makes it suitable for industrial control rooms, equipment cabinets, and centralized monitoring installations.

Key Strengths at a Glance

- Industrial Computing Architecture: Based on the Siemens SIMATIC IPC547G platform for manufacturing and automation applications.

- Extensive Expansion Capability: Seven expansion slots, including five PCI Express and two PCI slots, accommodate compatible industrial peripherals.

- Dual Gigabit Ethernet: Supports communication with PLCs, industrial switches, and supervisory systems.

- Hardware Condition Monitoring: Integrated temperature and fan monitoring help maintenance teams identify abnormal operating conditions.

- Watchdog Functionality: Provides system supervision and configured responses to unexpected operating conditions.

- Flexible Storage Options: Supports HDD and SSD configurations, with RAID functionality available on selected variants.

- Industrial Rack Design: The 4U enclosure supports installation in standard 19-inch industrial equipment cabinets.

Technical FAQs

Q1: What is the main application of the Siemens 6AG4104-4DA18-0XX3?

It is identified by its ordering number as a requested SIMATIC IPC547G configuration. The IPC547G family is designed for industrial computing, production supervision, process visualization, and PC-based automation. The exact hardware specification of the -4DA18-0XX3 variant requires confirmation.

Q2: Which processor options are supported by the IPC547G family?

The platform supports selected Intel Pentium, Core i5, Core i7, and Xeon E3 processors. Processor selection depends on the motherboard and specific product configuration.

Q3: How many expansion slots does the IPC547G provide?

The IPC547G offers seven expansion slots, consisting of five PCI Express slots and two conventional PCI slots. These accommodate compatible industrial communication and data acquisition cards.

Q4: Does the system support dual Gigabit Ethernet?

Yes. The platform provides two Intel Gigabit Ethernet interfaces with RJ45 connectors, supporting industrial network communication and compatible teaming configurations.

Q5: Can the IPC547G be integrated with Siemens PLC systems?

Yes. It can communicate with compatible SIMATIC PLCs through supported Ethernet protocols and appropriate industrial automation software.

Q6: Does the IPC547G support RAID functionality?

Selected configurations support RAID storage arrangements. Available RAID functions depend on the motherboard chipset, storage controller, and installed drives.

Q7: What system monitoring functions are available?

The platform provides temperature monitoring, fan monitoring, status indicators, and watchdog functionality to help maintenance personnel supervise hardware operation.

Q8: Can additional industrial communication cards be installed?

Yes. Compatible PCI Express and PCI cards can extend the system's communication capabilities for specialized industrial networks, measurement equipment, and automation peripherals.

Q9: Which operating systems can run on the IPC547G?

Depending on the hardware configuration, compatible operating systems include selected Windows 7, Windows 10 Enterprise, Windows 10 IoT Enterprise, and Windows Server editions.

Q10: What should be checked before replacing this industrial PC?

Verify the processor, chipset, memory, storage arrangement, expansion cards, operating system, BIOS configuration, and power supply requirements to ensure compatibility with the existing industrial installation.
