Introduction The Siemens 6AG4104-4DA20-0XX0 belongs to the SIMATIC IPC547G industrial rack PC product range, developed for manufacturing facilities, industrial automation systems, and centralized computing applications.
Designed around a 19-inch, 4U rack-mounted enclosure, the IPC547G provides a flexible hardware platform for industrial installations. Its architecture accommodates different Intel processor configurations, memory capacities, and storage arrangements, allowing system integrators to select suitable hardware for individual application requirements.
One of its notable characteristics is its extensive expansion capability. Five PCI Express slots and two conventional PCI slots provide integration options for industrial communication adapters, data acquisition devices, and specialized control hardware. Dual Intel Gigabit Ethernet interfaces further support connections to PLCs, industrial networks, and supervisory systems.
The platform also incorporates temperature and fan monitoring, watchdog functionality, and industrial power supply options. These features help maintenance personnel monitor system conditions and support routine equipment management.
For manufacturing operators, automation engineers, and industrial system integrators, the SIMATIC IPC547G offers a practical computing foundation for SCADA, HMI, production monitoring, and industrial data processing.
The precise processor, memory, storage, and operating system configuration of 6AG4104-4DA20-0XX0 should be confirmed before ordering. Specifications belonging to other IPC547G variants should not automatically be attributed to this particular model.
Technical Specifications Parameter
Specification
Manufacturer
Siemens
Order Number
6AG4104-4DA20-0XX0
Product Family
SIMATIC IPC
Platform Model
IPC547G
Product Type
Industrial Rack PC
Chassis Format
19-inch rack-mounted
Rack Height
4U
Processor Family
Intel Pentium / Core i5 / Core i7 / Xeon E3
Processor Model
Configuration dependent
Chipset
Intel H110 / C236
Memory Type
DDR4 SDRAM
Memory Capacity
Configuration dependent
Graphics
Integrated Intel HD Graphics, configuration dependent
Ethernet Interfaces
2 × Intel Gigabit Ethernet
Front USB
2 × USB 3.0
Rear USB
2 × USB 3.0, 4 × USB 2.0
Display Interfaces
DVI-D / DisplayPort, configuration dependent
Other Interfaces
2 × PS/2, Audio, optional COM
Expansion Slots
5 × PCI Express, 2 × PCI
Storage Options
HDD / SSD
RAID Support
Available on selected configurations
Optical Drive
DVD±RW, configuration dependent
Monitoring Functions
Temperature and Fan Monitoring
System Protection
Watchdog
Power Supply
100–240 V AC
Redundant Power Supply
Available on selected configurations
Installation
Horizontal / Vertical
Dimensions (W × H × D)
481.4 × 176.6 × 446.6 mm
Net Weight
15–23 kg, depending on configuration
Product Lifecycle
Discontinued
Dimensions and weight refer to the standard IPC547G enclosure. A short-enclosure version measures 481.4 × 176.6 × 356.6 mm. Exact installed hardware specifications and net weight for 6AG4104-4DA20-0XX0 require confirmation.
Recommended Companion Models Model Number
Product Name
6AG4104-4DA12-3BX2
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB RAM, 1 TB HDD, Windows 7 Ultimate
6AG4104-4CA12-1DX1
Siemens SIMATIC IPC547G Core i5-6500 Industrial Rack PC, 8 GB RAM, 1 TB HDD, Windows 10 Enterprise 2016 LTSB
6AG4104-4GK13-1BX2
Siemens SIMATIC IPC547G Core i5-6500 Industrial Rack PC, 8 GB RAM, 480 GB SSD, Redundant Power Supply
6AG4104-4HA12-0XX1
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB RAM, 1 TB HDD, Without Operating System
Frequently Selected Alternatives Model Number
Product Name
6AG4104-4CA00-0BX2
Siemens SIMATIC IPC547G Core i5-6500 Industrial Rack PC, 4 GB RAM, 1 TB HDD, Windows 7 Ultimate
6AG4104-4DA22-0HX1
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 16 GB RAM, 1 TB HDD, Windows Server 2016
6AG4104-4DB12-0BX1
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, Dual 1 TB HDD Configuration
6AG4104-4DA16-0CX1
Siemens SIMATIC IPC547G Core i7-6700 Industrial Rack PC, 8 GB RAM, 1 TB HDD, Windows 10 Enterprise LTSB 2015
Where It Excels in Industrial Use - Industrial Process Control: Provides a centralized computing platform for process supervision, equipment management, and PC-based automation in manufacturing facilities.
- Production Line Monitoring: Supports industrial visualization, production status tracking, and communication between manufacturing equipment and supervisory systems.
- SCADA and HMI Integration: Provides a suitable hardware foundation for operator interfaces, process visualization, alarm management, and industrial monitoring software.
- Manufacturing Data Management: Supports production data processing, equipment information management, and communication with industrial databases.
- Industrial Network Applications: Connects PLCs, network switches, and automation equipment through Gigabit Ethernet interfaces.
- Centralized Automation Systems: Its 19-inch rack-mounted construction makes it suitable for control rooms, industrial cabinets, and centralized computing installations.
Key Strengths at a Glance - Flexible Processor Selection: The IPC547G platform supports Intel Pentium, Core i5, Core i7, and Xeon E3 processor configurations.
- Extensive Expansion Architecture: Five PCI Express slots and two conventional PCI slots provide flexibility for industrial communication and specialized hardware.
- Dual Gigabit Ethernet: Two Intel Gigabit Ethernet interfaces support connections to PLCs, industrial networks, and supervisory computers.
- Industrial Hardware Monitoring: Temperature and fan monitoring help maintenance personnel identify abnormal operating conditions.
- Watchdog Supervision: Supports system monitoring and configured responses to unexpected operating conditions.
- Flexible Power Architecture: Supports standard 100–240 V AC industrial power and optional redundant power supply configurations.
- Rack-Mount Installation: The 4U enclosure supports integration into standard 19-inch industrial equipment cabinets.
Technical FAQs Q1: What is the primary application of the Siemens 6AG4104-4DA20-0XX0?
It is an ordering designation associated with the SIMATIC IPC547G industrial rack PC family. The platform is designed for industrial computing, production monitoring, process visualization, and PC-based automation applications.
Q2: Which processors are supported by the IPC547G platform?
The product family supports Intel Pentium G4400, Core i5-6500, Core i7-6700, and Xeon E3-1275 v5 processor configurations. The installed processor for this specific ordering number requires confirmation.
Q3: How many expansion slots does the IPC547G provide?
The platform provides seven expansion slots, consisting of five PCI Express slots and two conventional PCI slots for compatible industrial expansion cards.
Q4: Does the system support dual Ethernet communication?
Yes. The IPC547G provides two Intel Gigabit Ethernet interfaces for communication with PLCs, industrial switches, and supervisory computers.
Q5: Can the IPC547G be integrated into Siemens automation systems?
Yes. It can communicate with compatible SIMATIC controllers through supported industrial Ethernet protocols and appropriate Siemens automation software.
Q6: What storage technologies are supported?
The platform supports internal HDD and SSD storage configurations. Selected hardware variants also provide RAID functionality for applications requiring improved storage availability.
Q7: Does the IPC547G include system monitoring functions?
Yes. Temperature and fan monitoring functions help maintenance personnel identify abnormal hardware conditions and support preventive maintenance.
Q8: What is the function of the integrated watchdog?
The watchdog monitors system activity and can initiate a predefined response when abnormal computer operation is detected, supporting unattended industrial applications.
Q9: Can additional industrial communication cards be installed?
Yes. Compatible PCI Express and PCI cards can extend communication capabilities for specialized industrial networks, measurement equipment, and data acquisition systems.
Q10: Which operating systems are compatible with this industrial PC?
Compatible operating systems depend on the processor, motherboard, and installed drivers. The IPC547G family supports selected Windows 7, Windows 10 Enterprise, Windows 10 IoT Enterprise, and Windows Server configurations.
