The Yokogawa AFS30D is a top-tier Fieldbus Gateway designed to optimize communication and integration between field devices and Yokogawa’s advanced control systems. Perfect for industries such as oil & gas, chemical processing, power generation, and pharmaceuticals, the AFS30D enables reliable real-time data transfer and process automation. It supports a variety of communication protocols including Foundation Fieldbus (FF), HART, Modbus, and PROFIBUS, ensuring that field devices from diverse manufacturers can be seamlessly integrated into the control system. By offering enhanced diagnostics, flexible connectivity, and high-speed communication, the AFS30D helps boost operational efficiency, improve process reliability, and enable better decision-making based on real-time data insights.

Technical Specifications

Model: AFS30D
Type: Fieldbus Gateway
Dimensions: 9.2 inches x 6.3 inches x 4.5 inches (234 mm x 160 mm x 114 mm)
Weight: 2.1 lbs (0.95 kg)
Power Supply: 24V DC ± 10%
Power Consumption: 12 W
Communication Ports:
- 1x Fieldbus Port (Foundation Fieldbus, HART, PROFIBUS)
- 1x Ethernet Port (10/100 Mbps)
- 2x Serial Ports (RS-232/RS-485)
Supported Protocols: Foundation Fieldbus (FF), HART, Modbus TCP/IP, Modbus RTU, PROFIBUS DP
Operating Temperature: -20°C to 60°C (-4°F to 140°F)
Storage Temperature: -40°C to 85°C (-40°F to 185°F)
Relative Humidity: 5% to 95% non-condensing
Environmental Rating: IP20 (for indoor use)
Bus Current: 300 mA at 24V DC
Data Rate: 100 Mbps (Ethernet)

Recommended Related Models

Yokogawa CENTUM VP: A powerful Distributed Control System (DCS) that integrates seamlessly with the AFS30D, providing centralized control and real-time process optimization across industries.
Yokogawa STARDOM FCN: A flexible, scalable Distributed Control System that pairs well with the AFS30D, providing real-time monitoring and control in decentralized environments.
Yokogawa ADMAG AXF: A magnetic flow meter that integrates with the AFS30D for precise flow measurement in industrial processes, delivering high accuracy and real-time data.
Yokogawa PRM (Plant Resource Manager): A comprehensive asset management system that pairs with the AFS30D to enhance device diagnostics, predictive maintenance, and asset optimization.

Popular Yokogawa Models

Yokogawa CENTUM VP DCS: A highly flexible and scalable Distributed Control System (DCS) that integrates with the AFS30D, offering advanced process control and real-time monitoring.
Yokogawa DX1000: A high-performance, compact controller that works effectively with the AFS30D, improving system integration and providing reliable communication between field devices and control systems.
Yokogawa PRM (Plant Resource Manager): An asset management tool that integrates with the AFS30D, providing comprehensive diagnostic capabilities, predictive maintenance, and process optimization.

Applications

The Yokogawa AFS30D is perfect for a variety of industrial applications that require seamless integration, real-time communication, and advanced process control:

Field Device Integration: The AFS30D enables the integration of Foundation Fieldbus (FF), HART, Modbus, and PROFIBUS devices, allowing users to achieve real-time data exchange and streamlined device management within Yokogawa’s control systems.
Process Control and Automation: In industries like oil & gas, chemical, and power generation, the AFS30D improves communication between field devices and central control systems, optimizing process performance, minimizing downtime, and enhancing productivity.
Predictive Maintenance: The AFS30D’s continuous diagnostics and monitoring allow for early detection of device faults, enabling predictive maintenance to reduce unplanned downtime and improve asset lifespan.
Energy Management: The AFS30D integrates with energy management systems, providing real-time data on energy consumption, optimizing usage, and reducing costs across operations.
Data Logging and Reporting: The AFS30D ensures reliable, accurate data logging from field devices, supporting regulatory compliance, reporting needs, and real-time decision-making in critical industrial operations.

Advantages

Multi-Protocol Communication: With support for Foundation Fieldbus (FF), HART, Modbus TCP/IP, Modbus RTU, and PROFIBUS DP, the AFS30D can integrate with a wide range of field devices, offering operational flexibility and future-proofing your system.
High-Speed Data Transfer: The 100 Mbps Ethernet port ensures fast, efficient communication, enabling real-time data exchange for time-sensitive processes and applications.
Flexible Connectivity: The AFS30D includes 1 Ethernet port, 1 Fieldbus port, and 2 serial ports (RS-232/RS-485), providing a variety of connection options for easy integration into different industrial networks.
Compact and Durable Design: The AFS30D is designed for rugged industrial environments, offering a compact, lightweight form factor while maintaining high durability and reliability.
Energy Efficiency: With a low 12 W power consumption, the AFS30D provides a cost-effective, energy-efficient solution that can operate continuously without significant power costs.

Technical FAQs

What communication protocols does the AFS30D support?
The AFS30D supports Foundation Fieldbus (FF), HART, Modbus TCP/IP, Modbus RTU, and PROFIBUS DP, ensuring broad compatibility with field devices across various manufacturers and systems.
How many communication ports does the AFS30D have?
The AFS30D includes 1 Fieldbus port, 1 Ethernet port (10/100 Mbps), and 2 serial ports (RS-232/RS-485), offering versatile connectivity options for different network configurations.
What is the power consumption of the AFS30D?
The AFS30D has a power consumption of 12 W, providing an energy-efficient solution without compromising performance or reliability.
What is the data rate of the AFS30D’s Ethernet port?
The 100 Mbps Ethernet port ensures high-speed data transfer, enabling fast and efficient communication for critical, time-sensitive processes.
Can the AFS30D assist with predictive maintenance?
Yes, the AFS30D provides continuous diagnostics and real-time monitoring, allowing for predictive maintenance that minimizes unplanned downtime and extends the lifespan of equipment.
Is the AFS30D suitable for use in hazardous environments?
The AFS30D is designed for indoor use with an IP20 rating, making it ideal for environments that are free from excessive dust, moisture, and hazardous gases.
What is the operating temperature range for the AFS30D?
The AFS30D operates in temperatures ranging from -20°C to 60°C (-4°F to 140°F), making it suitable for use in most industrial environments.
Can the AFS30D integrate with Yokogawa’s CENTUM VP system?
Yes, the AFS30D integrates seamlessly with the Yokogawa CENTUM VP DCS, allowing for centralized control, process optimization, and real-time communication.
How does the AFS30D improve process control?
The AFS30D enhances communication between field devices and control systems, providing accurate, real-time data that enables optimized decision-making and process control.
What is the weight of the AFS30D?
The AFS30D weighs approximately 2.1 lbs (0.95 kg), offering a compact yet reliable solution for industrial applications.
