The Yokogawa AMM11 is a high-performance multi-function analyzer designed for advanced industrial process monitoring and optimization. Whether in the chemical, pharmaceutical, oil & gas, or food & beverage industries, the AMM11 enables precise measurement and control of various process parameters, improving operational efficiency and product quality. With its ability to handle a wide range of parameters such as pH, dissolved oxygen, conductivity, and ORP (oxidation-reduction potential), the AMM11 is a key instrument for applications requiring accurate, real-time analysis of complex processes. Its flexible design, ease of integration, and intuitive user interface make it an ideal choice for companies looking to improve both performance and safety in their operations.

Technical Specifications

Model: AMM11
Type: Multi-Function Analyzer
Dimensions: 9.5 inches x 8.0 inches x 3.2 inches (242 mm x 203 mm x 81 mm)
Weight: 2.3 lbs (1.05 kg)
Power Supply: 100-240V AC, 50/60Hz
Power Consumption: 15 W
Input Channels: 2x Analog Inputs (for pH, ORP, dissolved oxygen, etc.)
Display: 5.7-inch color LCD touchscreen
Communication Ports:
- 1x Ethernet (10/100 Mbps)
- 1x RS-485 (Modbus RTU)
- 1x USB (for configuration and data export)
Measurement Parameters: pH, ORP, Dissolved Oxygen, Conductivity, and others
Accuracy: ±0.01 pH (for pH measurements), ±1% FS (for conductivity)
Operating Temperature: -10°C to 55°C (14°F to 131°F)
Storage Temperature: -20°C to 70°C (-4°F to 158°F)
Environmental Rating: IP65 (for front panel)
Mounting: Panel Mount or Wall Mountable
Software: Embedded data logging, trend graphs, and alarm management features
Certificates: CE, UL

Recommended Related Models

Yokogawa SC200: The SC200 process controller, integrated with the AMM11, enhances the analyzer's capabilities by providing centralized control, data visualization, and alarm management for critical industrial processes.
Yokogawa FLXA202: The FLXA202 multi-parameter analyzer, when paired with the AMM11, offers broader parameter measurement support, including turbidity, for more complex and diverse process environments.
Yokogawa PRM (Plant Resource Manager): The PRM system can be integrated with the AMM11 for real-time diagnostics and predictive maintenance, ensuring continuous monitoring and uptime of critical process instrumentation.
Yokogawa ADMAG AXF: The ADMAG AXF magnetic flow meter, when used in combination with the AMM11, allows for accurate flow measurement in processes requiring precise fluid control, such as in chemical and food industries.

Popular Yokogawa Models

Yokogawa SCADA Systems: The integration of the AMM11 with Yokogawa's SCADA systems ensures real-time data monitoring, process optimization, and alarm management across a variety of industrial processes.
Yokogawa DX1000: When integrated with the AMM11, the DX1000 offers enhanced real-time process monitoring and control, enabling accurate data analysis for optimized decision-making.
Yokogawa OpreX Analytical Solutions: A complete suite of analytical instruments, including the AMM11, that enables highly accurate and reliable process analysis for industries such as water treatment and chemical production.

Applications

The Yokogawa AMM11 is designed for versatile applications that require multi-parameter analysis and high-precision measurements:

Chemical Processing: The AMM11 plays a crucial role in monitoring parameters like pH, conductivity, and ORP, which are essential for maintaining chemical reaction conditions, ensuring product quality, and optimizing reaction rates.
Water Treatment: Whether in municipal water treatment or industrial wastewater management, the AMM11 helps monitor parameters such as dissolved oxygen and pH to ensure the efficiency and safety of water treatment processes.
Pharmaceutical Manufacturing: Accurate process control is essential in pharmaceutical production. The AMM11 ensures critical parameters like pH and conductivity are tightly monitored to meet stringent quality standards.
Food & Beverage: In this sector, maintaining precise control over parameters such as pH and conductivity is key to product consistency, safety, and taste, which the AMM11 can monitor with high precision.
Energy & Power: The AMM11 enables monitoring of critical parameters like conductivity and ORP in power plant cooling and boiler systems to prevent scaling and ensure efficient operation.

Advantages

Multi-Parameter Capability: The AMM11 allows for simultaneous measurement of multiple process parameters (pH, ORP, dissolved oxygen, conductivity, etc.), simplifying process control and reducing the need for multiple separate analyzers.
User-Friendly Interface: The AMM11 features an intuitive 5.7-inch color touchscreen that provides clear, real-time display of measurement data, trend graphs, and alarms, improving operational visibility and ease of use.
Flexible Mounting Options: The AMM11 can be mounted both on panels or walls, offering flexibility for different industrial installations, whether in control rooms or on-site.
Data Logging and Alarm Management: The analyzer comes equipped with built-in data logging, trend graphs, and alarm management features, enabling better process monitoring, troubleshooting, and compliance reporting.
IP65 Rating: The AMM11 is equipped with an IP65-rated front panel, providing resistance to dust and water, making it ideal for use in harsh industrial environments where environmental protection is critical.
Modular Design: With support for Ethernet, RS-485, and USB connections, the AMM11 integrates seamlessly with a range of industrial automation systems, including Yokogawa’s SCADA systems and other third-party devices.

Technical FAQs

What parameters can the AMM11 measure?
The AMM11 can measure pH, ORP (Oxidation-Reduction Potential), Dissolved Oxygen, Conductivity, and other process-related parameters, making it versatile for various industrial applications.
What is the power consumption of the AMM11?
The AMM11 has a power consumption of 15 W, ensuring efficient operation without high energy demands.
What is the accuracy of the AMM11 for pH measurement?
The AMM11 provides an accuracy of ±0.01 pH for pH measurements, ensuring high-precision monitoring and control in processes where pH is critical.
How many input channels does the AMM11 support?
The AMM11 supports 2 analog input channels, allowing simultaneous monitoring of two parameters such as pH and dissolved oxygen or pH and conductivity.
What type of display does the AMM11 have?
The AMM11 features a 5.7-inch color LCD touchscreen that offers clear, easy-to-read measurement data, trend graphs, and alarm notifications.
What mounting options are available for the AMM11?
The AMM11 can be mounted either on a panel or on a wall, providing flexible installation options depending on the application.
What is the environmental rating of the AMM11?
The AMM11 has an IP65-rated front panel, offering protection against dust and water ingress, making it suitable for use in harsh industrial environments.
Can the AMM11 be connected to external systems?
Yes, the AMM11 supports communication through Ethernet (10/100 Mbps), RS-485 (Modbus RTU), and USB ports for easy integration with Yokogawa’s SCADA systems and other automation devices.
What is the temperature range for operating the AMM11?
The AMM11 operates in a temperature range of -10°C to 55°C (14°F to 131°F), making it suitable for a variety of industrial environments.
Does the AMM11 have data logging capabilities?
Yes, the AMM11 comes equipped with embedded data logging, allowing users to track process trends, store historical data, and facilitate compliance reporting.
