The Yokogawa AMM22 S3 is an advanced, high-precision multi-function analyzer designed to provide real-time monitoring of critical process parameters across various industrial sectors. As a next-generation model, the AMM22 S3 builds on the renowned capabilities of the AMM22 with enhanced features for even more robust and reliable process control. With the ability to measure pH, ORP (Oxidation-Reduction Potential), dissolved oxygen, conductivity, and temperature, the AMM22 S3 is perfect for applications in chemical processing, water and wastewater treatment, pharmaceutical manufacturing, food & beverage, and energy generation. Offering exceptional accuracy, a user-friendly interface, and flexible connectivity, the AMM22 S3 ensures that your processes operate at their optimal performance levels, improving both product quality and operational efficiency.

Technical Specifications

Model: AMM22 S3
Type: Multi-Function Analyzer
Dimensions: 10.8 inches x 8.9 inches x 4.4 inches (274 mm x 226 mm x 112 mm)
Weight: 3.3 lbs (1.5 kg)
Power Supply: 100-240V AC, 50/60Hz
Power Consumption: 32 W
Input Channels:
- 4x Analog Inputs (for pH, ORP, dissolved oxygen, conductivity, temperature, and other customizable parameters)
Display: 7.0-inch color LCD touchscreen
Communication Ports:
- 1x Ethernet (10/100 Mbps)
- 2x RS-485 (Modbus RTU)
- 1x USB (for configuration, data export, and diagnostics)
Measurement Parameters: pH, ORP, Dissolved Oxygen, Conductivity, Temperature, and other customizable parameters
Accuracy:
- pH: ±0.01 pH
- Conductivity: ±1% FS
- Temperature: ±0.5°C
Operating Temperature: -10°C to 55°C (14°F to 131°F)
Storage Temperature: -20°C to 70°C (-4°F to 158°F)
Relative Humidity: 5% to 95% (non-condensing)
Environmental Rating: IP65 (for front panel)
Mounting: Panel Mount or Wall Mountable
Software: Data logging, trend graphs, alarm management, diagnostic tools, and event reporting
Certifications: CE, UL, Ex (for hazardous environments)

Recommended Related Models

Yokogawa FLXA202: The FLXA202 is a versatile multi-parameter analyzer that complements the AMM22 S3 with additional measurement capabilities, such as turbidity and other parameters, making it ideal for water treatment and environmental monitoring.
Yokogawa SC200: Integrating the SC200 system controller with the AMM22 S3 allows for centralized monitoring, real-time data analysis, and process optimization in larger industrial systems.
Yokogawa PRM (Plant Resource Manager): Using PRM with the AMM22 S3 enables advanced diagnostics, predictive maintenance, and real-time performance monitoring, ensuring optimal process reliability and reduced downtime.
Yokogawa ADMAG AXF: Pairing the AMM22 S3 with the ADMAG AXF magnetic flow meter provides accurate and reliable flow measurements, especially in applications such as chemical processing and water treatment.

Popular Yokogawa Models

Yokogawa CENTUM VP: The AMM22 S3 integrates seamlessly with the CENTUM VP Distributed Control System (DCS), allowing for centralized data collection, monitoring, and control of complex industrial processes.
Yokogawa SCADA Systems: The AMM22 S3 can be used with Yokogawa SCADA systems to provide comprehensive data visualization, real-time monitoring, and control across large industrial operations.
Yokogawa OpreX Analytical Solutions: The AMM22 S3 is part of Yokogawa’s OpreX Analytical Solutions, providing high-accuracy, reliable measurements for industries where precision and performance are critical.

Applications

The Yokogawa AMM22 S3 is designed to serve industries where continuous, precise monitoring is essential for efficient operation:

Chemical Processing: In chemical manufacturing, the AMM22 S3 helps maintain product consistency and safety by monitoring pH, ORP, conductivity, and other parameters to optimize reaction conditions.
Water and Wastewater Treatment: The AMM22 S3 is ideal for monitoring dissolved oxygen, pH, and conductivity in water treatment plants, ensuring compliance with environmental regulations and improving water quality management.
Pharmaceutical Manufacturing: In the pharmaceutical industry, the AMM22 S3 ensures precise monitoring of pH, conductivity, and dissolved oxygen, critical for maintaining stringent quality control standards and regulatory compliance.
Food and Beverage: The AMM22 S3 is essential for maintaining consistent product quality in food and beverage production by monitoring pH, conductivity, and temperature to meet safety and regulatory requirements.
Power Generation: The AMM22 S3 helps optimize the performance of power plants by providing real-time monitoring of conductivity, ORP, and temperature, improving efficiency, preventing scaling, and reducing corrosion in systems like cooling circuits and steam boilers.

Advantages

Multi-Parameter Measurement: The AMM22 S3 can measure multiple parameters simultaneously, such as pH, ORP, dissolved oxygen, conductivity, and temperature, offering a comprehensive solution for process optimization.
High Accuracy and Reliability: The AMM22 S3 provides ±0.01 pH accuracy for pH, ±1% FS for conductivity, and ±0.5°C for temperature, ensuring reliable and precise measurements.
Intuitive Touchscreen Interface: The 7.0-inch color LCD touchscreen provides a user-friendly interface for monitoring real-time data, viewing trends, and managing alarms, improving operator efficiency.
Flexible Mounting Options: The AMM22 S3 can be mounted in either panel mount or wall mount configurations, offering flexibility for different installation environments.
IP65 Protection: With an IP65-rated front panel, the AMM22 S3 is resistant to dust and water, making it ideal for use in harsh industrial environments.
Advanced Alarm Management: The AMM22 S3 offers advanced alarm management capabilities, enabling operators to track trends, respond to deviations quickly, and take proactive corrective actions.
Ex Certification for Hazardous Areas: The AMM22 S3 is Ex certified, meaning it is safe for use in hazardous locations where flammable gases or explosive atmospheres may exist.

Technical FAQs

What parameters can the AMM22 S3 measure?
The AMM22 S3 can measure pH, ORP, dissolved oxygen, conductivity, temperature, and other customizable parameters based on your application.
How many input channels does the AMM22 S3 support?
The AMM22 S3 supports 4 analog input channels, allowing simultaneous monitoring of multiple parameters for more comprehensive process control.
What is the accuracy of the AMM22 S3 for pH and conductivity measurements?
The AMM22 S3 offers ±0.01 pH accuracy for pH, ±1% FS for conductivity, and ±0.5°C for temperature, ensuring precise and reliable measurements.
Can the AMM22 S3 be used in hazardous environments?
Yes, the AMM22 S3 is Ex certified, making it suitable for use in hazardous environments such as oil & gas, chemical, and pharmaceutical industries.
What is the power consumption of the AMM22 S3?
The AMM22 S3 has a power consumption of 32 W, offering energy-efficient performance while providing accurate and continuous process monitoring.
What type of display does the AMM22 S3 have?
The AMM22 S3 features a 7.0-inch color LCD touchscreen, providing an easy-to-read and intuitive interface for data visualization, trend analysis, and alarm management.
Does the AMM22 S3 support remote communication?
Yes, the AMM22 S3 supports Ethernet, RS-485 (Modbus RTU), and USB communication, allowing for seamless integration with Yokogawa SCADA systems and other industrial control systems.
What is the environmental rating of the AMM22 S3?
The AMM22 S3 has an IP65-rated front panel, offering protection against dust and water ingress, making it ideal for use in demanding industrial environments.
What is the operating temperature range for the AMM22 S3?
The AMM22 S3 operates within a temperature range of -10°C to 55°C (14°F to 131°F), providing flexibility for use in a variety of industrial conditions.
Which industries can benefit from using the AMM22 S3?
The AMM22 S3 is ideal for industries like chemical processing, water treatment, pharmaceutical manufacturing, food & beverage, and energy generation, where precision and real-time monitoring are crucial for process optimization, safety, and compliance.
