The Yokogawa AMM22-S3 is an advanced multi-function analyzer designed to provide high-accuracy measurements and real-time monitoring of essential process parameters. Suitable for industries such as chemical processing, water and wastewater treatment, pharmaceutical manufacturing, food & beverage, and power generation, the AMM22-S3 offers robust capabilities for monitoring key parameters like pH, ORP (Oxidation-Reduction Potential), dissolved oxygen, conductivity, and temperature. With an intuitive user interface, multiple communication options, and a compact yet durable design, this analyzer enables efficient, reliable, and precise control over complex processes, ensuring optimal performance and regulatory compliance.

Technical Specifications

Model: AMM22-S3
Type: Multi-Function Analyzer
Dimensions: 10.8 inches x 8.9 inches x 4.3 inches (274 mm x 226 mm x 110 mm)
Weight: 3.4 lbs (1.55 kg)
Power Supply: 100-240V AC, 50/60Hz
Power Consumption: 30 W
Input Channels:
- 4x Analog Inputs (for pH, ORP, dissolved oxygen, conductivity, temperature, and customizable parameters)
Display: 7.0-inch color LCD touchscreen
Communication Ports:
- 1x Ethernet (10/100 Mbps)
- 2x RS-485 (Modbus RTU)
- 1x USB (for configuration, data export, and diagnostics)
Measurement Parameters: pH, ORP, Dissolved Oxygen, Conductivity, Temperature, and other customizable parameters
Accuracy:
- pH: ±0.01 pH
- Conductivity: ±1% FS
- Temperature: ±0.5°C
Operating Temperature: -10°C to 55°C (14°F to 131°F)
Storage Temperature: -20°C to 70°C (-4°F to 158°F)
Relative Humidity: 5% to 95% (non-condensing)
Environmental Rating: IP65 (for front panel)
Mounting: Panel Mount or Wall Mountable
Software: Data logging, trend graphs, alarm management, diagnostic tools, and event reporting
Certifications: CE, UL, Ex (for hazardous environments)

Recommended Related Models

Yokogawa FLXA202: The FLXA202 multi-parameter analyzer expands the capabilities of the AMM22-S3 by offering additional measurements like turbidity, which is essential in water treatment and environmental monitoring applications.
Yokogawa SC200: The SC200 system controller integrates seamlessly with the AMM22-S3, enabling centralized control and real-time data monitoring across large-scale industrial operations.
Yokogawa PRM (Plant Resource Manager): Integrating the AMM22-S3 with PRM enhances diagnostic capabilities, predictive maintenance, and process optimization to reduce downtime and improve operational reliability.
Yokogawa ADMAG AXF: The ADMAG AXF magnetic flow meter, paired with the AMM22-S3, provides highly accurate flow measurement for various industrial applications, such as chemical processing and pharmaceutical production.

Popular Yokogawa Models

Yokogawa CENTUM VP: The AMM22-S3 is compatible with the CENTUM VP Distributed Control System (DCS), providing centralized process monitoring and control for large-scale operations, optimizing overall performance.
Yokogawa SCADA Systems: When integrated with Yokogawa SCADA systems, the AMM22-S3 offers real-time data visualization, alarm management, and trend analysis, empowering operators to make informed decisions in critical processes.
Yokogawa OpreX Analytical Solutions: As part of Yokogawa’s OpreX Analytical Solutions, the AMM22-S3 ensures continuous, high-precision process monitoring across industries that require accurate, real-time data for optimization.

Applications

The Yokogawa AMM22-S3 is designed for versatile use in multiple industries, each requiring precise monitoring to ensure process stability and safety:

Chemical Processing: The AMM22-S3 provides accurate monitoring of pH, ORP, and conductivity, ensuring optimal reaction conditions and product quality in chemical manufacturing.
Water and Wastewater Treatment: With its ability to measure dissolved oxygen, pH, and conductivity, the AMM22-S3 plays a critical role in maintaining water quality and regulatory compliance in municipal and industrial water treatment facilities.
Pharmaceutical Manufacturing: The AMM22-S3 ensures strict control over pH, dissolved oxygen, and conductivity, which are essential for maintaining quality assurance and regulatory compliance in pharmaceutical production.
Food and Beverage: The AMM22-S3 helps maintain product safety and consistency in the food and beverage industry by monitoring critical parameters such as pH, conductivity, and temperature.
Power Generation: The AMM22-S3 aids in monitoring boiler and cooling system performance, providing precise measurements of conductivity, ORP, and temperature, improving system efficiency and preventing issues like scaling and corrosion.

Advantages

Multi-Parameter Measurement: The AMM22-S3 supports the simultaneous measurement of pH, ORP, dissolved oxygen, conductivity, and temperature, providing a comprehensive solution for monitoring and controlling multiple critical process parameters.
High Accuracy: With ±0.01 pH accuracy for pH, ±1% FS for conductivity, and ±0.5°C for temperature, the AMM22-S3 delivers precise and reliable measurement data for optimal process control.
Intuitive User Interface: The 7.0-inch color LCD touchscreen offers an easy-to-use, user-friendly interface that simplifies real-time monitoring, trend analysis, and alarm management.
Flexible Installation: The AMM22-S3 can be panel-mounted or wall-mounted, providing flexibility for installation in a variety of industrial environments.
IP65 Protection: With an IP65-rated front panel, the AMM22-S3 is protected from dust and water ingress, making it highly durable and reliable in harsh environments.
Ex Certification for Hazardous Locations: The AMM22-S3 is Ex certified, making it suitable for use in hazardous environments where explosive or flammable gases may be present, such as in oil & gas and chemical industries.
Advanced Alarm Management: The AMM22-S3 comes with powerful alarm management capabilities, enabling operators to stay on top of critical parameters and react swiftly to any process deviations or equipment malfunctions.

Technical FAQs

What parameters can the AMM22-S3 measure?
The AMM22-S3 measures pH, ORP, dissolved oxygen, conductivity, temperature, and other customizable parameters, providing comprehensive process monitoring.
How many input channels does the AMM22-S3 support?
The AMM22-S3 supports 4 analog input channels, enabling simultaneous monitoring of multiple critical parameters to optimize process control.
What is the accuracy of the AMM22-S3 for pH and conductivity measurements?
The AMM22-S3 offers ±0.01 pH accuracy for pH, ±1% FS for conductivity, and ±0.5°C for temperature, ensuring reliable and precise measurements.
Can the AMM22-S3 be used in hazardous environments?
Yes, the AMM22-S3 is Ex certified, meaning it is safe for use in hazardous locations, including environments with explosive gases or flammable substances, such as in the oil & gas or chemical industries.
What is the power consumption of the AMM22-S3?
The AMM22-S3 consumes 30 W, making it an energy-efficient solution for continuous monitoring in industrial applications.
What type of display does the AMM22-S3 have?
The AMM22-S3 features a 7.0-inch color LCD touchscreen, offering clear and easy-to-read data visualization, trend graphs, and alarm management functions.
Does the AMM22-S3 support remote communication?
Yes, the AMM22-S3 supports Ethernet, RS-485 (Modbus RTU), and USB communication, allowing seamless integration with other industrial systems and remote access for diagnostics.
What is the environmental rating of the AMM22-S3?
The AMM22-S3 has an IP65-rated front panel, providing protection against dust and water ingress, making it ideal for demanding industrial environments.
What is the operating temperature range for the AMM22-S3?
The AMM22-S3 operates in the temperature range of -10°C to 55°C (14°F to 131°F), ensuring reliable performance in various environmental conditions.
Which industries benefit from using the AMM22-S3?
The AMM22-S3 is ideal for industries such as chemical processing, water treatment, pharmaceutical manufacturing, food & beverage, and power generation, where precise, real-time process monitoring is critical.
