AMN11-S1 AMN11-S1 2 AMN11-S1 4 AMN11-S1 3

The Yokogawa AMN11 is a high-performance, multi-function analyzer designed to provide accurate, reliable, and continuous monitoring of essential process parameters in industries that demand precision and efficiency. Ideal for sectors such as chemical processing, water and wastewater treatment, pharmaceutical manufacturing, food and beverage, and power generation, the AMN11 supports the monitoring of critical parameters such as pH, ORP (Oxidation-Reduction Potential), dissolved oxygen, conductivity, and temperature. With its easy-to-use interface and robust design, the AMN11 ensures that processes are operating optimally, minimizing downtime and helping companies maintain compliance with regulatory standards. The analyzer also offers advanced diagnostic features, real-time data logging, and trend analysis, providing operators with valuable insights to enhance decision-making.

Technical Specifications

Model: AMN11
Type: Multi-Function Analyzer
Dimensions: 10.8 inches x 8.9 inches x 4.3 inches (274 mm x 226 mm x 110 mm)
Weight: 3.4 lbs (1.55 kg)
Power Supply: 100-240V AC, 50/60Hz
Power Consumption: 30 W
Input Channels:
- 4x Analog Inputs (for pH, ORP, dissolved oxygen, conductivity, temperature, and customizable parameters)
Display: 7.0-inch color LCD touchscreen
Communication Ports:
- 1x Ethernet (10/100 Mbps)
- 2x RS-485 (Modbus RTU)
- 1x USB (for configuration, data export, and diagnostics)
Measurement Parameters: pH, ORP, Dissolved Oxygen, Conductivity, Temperature, and customizable parameters
Accuracy:
- pH: ±0.01 pH
- Conductivity: ±1% FS
- Temperature: ±0.5°C
Operating Temperature: -10°C to 55°C (14°F to 131°F)
Storage Temperature: -20°C to 70°C (-4°F to 158°F)
Relative Humidity: 5% to 95% (non-condensing)
Environmental Rating: IP65 (for front panel)
Mounting: Panel Mount or Wall Mountable
Software: Data logging, trend graphs, alarm management, diagnostic tools, and event reporting
Certifications: CE, UL, Ex (for hazardous environments)

Recommended Related Models

Yokogawa FLXA202: For water treatment applications, the FLXA202 turbidity analyzer complements the AMN11 by providing additional measurement capabilities, enhancing process monitoring.
Yokogawa SC200: Integrating the AMN11 with the SC200 controller allows for centralized control and monitoring of larger systems, simplifying data management.
Yokogawa PRM (Plant Resource Manager): Integrating PRM with the AMN11 enhances predictive maintenance and process optimization by enabling real-time diagnostics, troubleshooting, and system health monitoring.
Yokogawa ADMAG AXF: For accurate flow measurement, the AMN11 pairs well with the ADMAG AXF magnetic flow meter, ensuring precise monitoring in applications such as chemical processing and water treatment.

Popular Yokogawa Models

Yokogawa CENTUM VP: The AMN11 can be easily integrated with the CENTUM VP Distributed Control System (DCS) for more robust process control and centralized monitoring across industrial environments.
Yokogawa SCADA Systems: Integrating the AMN11 with SCADA systems ensures real-time monitoring, data collection, and alarm management, improving operational visibility and responsiveness.
Yokogawa OpreX Analytical Solutions: As part of the OpreX series, the AMN11 supports advanced process optimization and regulatory compliance, enhancing industrial operational efficiency.

Applications

The Yokogawa AMN11 is designed for precise, continuous measurement and monitoring of process parameters across various industries:

Chemical Processing: The AMN11 measures pH, ORP, and conductivity, ensuring chemical reactions are controlled optimally, improving product consistency and reducing process variations.
Water and Wastewater Treatment: The AMN11 is ideal for dissolved oxygen, pH, and conductivity measurements in water and wastewater treatment systems, ensuring compliance with environmental standards and improving system efficiency.
Pharmaceutical Manufacturing: In the pharmaceutical industry, the AMN11 plays a key role in ensuring quality control by monitoring pH, conductivity, and temperature during critical manufacturing processes.
Food and Beverage: The AMN11 is widely used in food and beverage production to monitor pH, conductivity, and temperature, ensuring product consistency, quality, and safety.
Power Generation: The AMN11 provides critical monitoring of conductivity, ORP, and temperature in cooling systems and water treatment processes within power plants, helping to prevent scaling and corrosion and optimizing performance.

Advantages

Multi-Parameter Measurement: The AMN11 supports simultaneous measurement of pH, ORP, dissolved oxygen, conductivity, and temperature, providing a comprehensive solution for process control and monitoring.
High Accuracy: With ±0.01 pH accuracy for pH, ±1% FS for conductivity, and ±0.5°C for temperature, the AMN11 ensures highly precise and reliable data for critical applications.
User-Friendly Interface: The 7.0-inch color LCD touchscreen simplifies data visualization, trend monitoring, and alarm management, making it easier for operators to respond quickly to process deviations.
Flexible Mounting Options: The AMN11 can be installed as a panel mount or wall mount unit, providing flexibility in diverse industrial environments.
IP65 Protection: The AMN11 is equipped with an IP65-rated front panel, ensuring protection against dust and water ingress, making it suitable for rugged environments.
Ex Certification: The AMN11 is Ex certified, ensuring safe operation in hazardous areas with explosive gases or flammable materials.
Advanced Diagnostics and Alarm Management: The AMN11 provides powerful diagnostic tools and customizable alarm management features, enabling proactive maintenance and reducing downtime.

Technical FAQs

What parameters can the AMN11 measure?
The AMN11 can measure pH, ORP, dissolved oxygen, conductivity, temperature, and other customizable parameters for comprehensive process monitoring.
How many input channels does the AMN11 support?
The AMN11 supports 4 analog input channels, allowing for the simultaneous measurement of multiple process parameters.
What is the accuracy of the AMN11 for pH and conductivity?
The AMN11 offers ±0.01 pH accuracy for pH, ±1% FS for conductivity, and ±0.5°C for temperature, ensuring high-precision monitoring.
Can the AMN11 be used in hazardous environments?
Yes, the AMN11 is Ex certified, making it suitable for use in hazardous environments with explosive gases or flammable materials.
What is the power consumption of the AMN11?
The AMN11 consumes 30 W, ensuring energy-efficient operation while maintaining high performance.
What type of display does the AMN11 have?
The AMN11 features a 7.0-inch color LCD touchscreen, which provides an easy-to-navigate interface for real-time monitoring, trend analysis, and alarm management.
Does the AMN11 support remote communication?
Yes, the AMN11 supports Ethernet, RS-485 (Modbus RTU), and USB communication, enabling seamless integration with other systems and remote access for diagnostics and data export.
What is the environmental rating of the AMN11?
The AMN11 has an IP65-rated front panel, providing protection against dust and water ingress, making it suitable for industrial environments.
What is the operating temperature range for the AMN11?
The AMN11 operates within the temperature range of -10°C to 55°C (14°F to 131°F), providing reliable performance across a wide range of industrial conditions.
Which industries benefit most from the AMN11?
The AMN11 is ideal for industries such as chemical processing, water treatment, pharmaceutical manufacturing, food and beverage, and power generation, where continuous, high-precision monitoring is required for optimal process performance.
