The Yokogawa ANB10D Communication Module is a high-performance, flexible solution designed to ensure seamless communication within industrial control systems. Compatible with Yokogawa’s CENTUM VP and ProSafe-RS platforms, the ANB10D enables reliable, high-speed data transmission across large-scale and complex industrial networks. Whether for power generation, oil & gas, petrochemical, or manufacturing applications, this module is designed to facilitate real-time, secure communication between control systems, field devices, and operator stations, ensuring the efficiency and safety of industrial processes.

With its support for multiple communication protocols, the ANB10D enhances the scalability and reliability of any automation system, offering high levels of integration and ease of use for both small and large-scale installations.

Technical Specifications

Feature	Specification
Model	ANB10D
Communication Protocol	Modbus TCP/IP, EtherNet/IP, OPC-UA, PROFIBUS
Interface Type	Dual Ethernet Ports (10/100/1000 Mbps)
Power Supply	24V DC
Mounting	Rack Mount
Dimensions (WxHxD)	8.27” x 4.13” x 9.84” (210 mm x 105 mm x 250 mm)
Weight	3.8 lbs (1.7 kg)
Operating Temperature	-20°C to +60°C
Storage Temperature	-40°C to +85°C
Maximum Power Consumption	14W
Status Indicators	LED indicators for communication, power, and status

Recommended Related Models

AMN31 – A versatile communication module that supports redundancy and high-speed data transfer, suitable for large-scale industrial applications.
AMN33-S2 – A flexible communication module that provides secure, high-speed communication, ideal for expanding network infrastructures.
CS3000 – A fully integrated DCS solution that optimizes control, monitoring, and diagnostics for large-scale industrial processes.
FLXA21 – A multi-parameter field analyzer that seamlessly integrates with the ANB10D for real-time measurement and process diagnostics.

Popular Yokogawa Models

CS3000: A distributed control system (DCS) that provides comprehensive monitoring and control, suitable for large and complex industrial applications.
AMN31: A robust communication module that supports high-speed data transfer, making it ideal for larger, demanding systems with high availability requirements.
AMN33-S2: A reliable and secure communication module, offering redundancy and multi-protocol support for versatile industrial system integration.
FLXA21: A field analyzer that integrates with communication modules like the ANB10D to provide real-time process monitoring and diagnostics for efficient operations.

Applications

The Yokogawa ANB10D Communication Module is designed for industries and applications where seamless and reliable communication between control systems, field devices, and operators is crucial:

Power Generation: The ANB10D ensures fast, reliable communication between turbine control systems, grid management, and operator stations, optimizing power generation efficiency.
Oil & Gas: Facilitates secure communication between remote offshore platforms, refineries, and central control rooms, improving safety and operational performance.
Petrochemical & Chemical Processing: Ensures smooth, secure data exchange between process control systems and field devices, supporting regulatory compliance and process safety.
Water Treatment: Integrates sensors, monitoring devices, and control systems to provide real-time data transmission, optimizing water quality management and reducing operational costs.
Manufacturing & Automation: Connects machinery, sensors, and control systems to streamline production processes, enhance productivity, and reduce machine downtime.

Advantages

Dual Ethernet Ports: Equipped with 10/100/1000 Mbps Ethernet ports, the ANB10D ensures high-speed communication and supports network redundancy for mission-critical applications.
Multi-Protocol Support: The ANB10D supports multiple industrial protocols, including Modbus TCP/IP, EtherNet/IP, OPC-UA, and PROFIBUS, allowing it to integrate seamlessly with diverse automation systems.
Scalable Integration: Designed to scale with your system, the ANB10D allows for easy network expansion and device integration, making it suitable for both small and large industrial setups.
Secure Data Communication: With OPC-UA support, the ANB10D ensures encrypted, secure data transfer, enhancing the security of sensitive industrial data and protecting against unauthorized access.
Compact, Rack-Mountable Design: The rack-mountable design ensures the ANB10D fits easily into control panels or industrial enclosures, offering space-efficient installation without compromising functionality.
Energy Efficient: With a maximum power consumption of just 14W, the ANB10D operates efficiently, helping reduce energy costs while maintaining optimal communication performance.
Reliability in Harsh Environments: Built to withstand temperatures from -20°C to +60°C, the ANB10D ensures reliable operation in a variety of challenging industrial environments.

Technical FAQs

What communication protocols are supported by the ANB10D?
The ANB10D supports Modbus TCP/IP, EtherNet/IP, OPC-UA, and PROFIBUS, ensuring compatibility with a wide range of industrial automation systems.
Is the ANB10D suitable for large-scale industrial networks?
Yes, the ANB10D is designed for both small and large-scale applications, providing high-speed communication, scalability, and reliability across expansive industrial networks.
What is the maximum power consumption of the ANB10D?
The maximum power consumption of the ANB10D is 14W, making it an energy-efficient solution for industrial networks.
What is the operating temperature range for the ANB10D?
The ANB10D operates in a temperature range of -20°C to +60°C, ensuring reliable performance in a variety of industrial environments.
Does the ANB10D support redundancy?
Yes, the dual Ethernet ports provide network redundancy, ensuring continuous operation even in the event of a network failure.
Can the ANB10D be integrated with other Yokogawa systems?
Yes, the ANB10D is fully compatible with Yokogawa’s CENTUM VP and ProSafe-RS systems, ensuring seamless integration across Yokogawa’s automation solutions.
How does the ANB10D ensure secure communication?
The ANB10D supports OPC-UA, which provides secure, encrypted data transmission, ensuring the integrity of sensitive operational data.
What mounting options are available for the ANB10D?
The ANB10D is rack-mountable, making it ideal for installation in industrial control panels and enclosures.
What industries benefit from using the ANB10D?
Industries such as power generation, oil & gas, petrochemical, water treatment, and manufacturing can benefit from the ANB10D’s scalability, reliability, and secure communication features.
What are the physical dimensions of the ANB10D?
The ANB10D measures 210 mm (W) x 105 mm (H) x 250 mm (D), offering a compact and easy-to-install solution for industrial network infrastructures.
