The Yokogawa ANB10D-S1 Communication Module is a high-performance, versatile networking solution designed for seamless integration within Yokogawa’s CENTUM VP and ProSafe-RS systems. Engineered for industrial environments where reliability, scalability, and security are crucial, the ANB10D-S1 ensures high-speed communication across a wide range of industrial control systems.

This module supports a variety of communication protocols, making it an ideal choice for industries such as power generation, oil & gas, petrochemicals, and manufacturing. The ANB10D-S1 enables real-time, efficient, and secure data transfer between control systems, field devices, and operator stations, ensuring optimal process control and safety.

Technical Specifications

Feature	Specification
Model	ANB10D-S1
Communication Protocol	Modbus TCP/IP, EtherNet/IP, OPC-UA, PROFIBUS
Interface Type	Dual Ethernet Ports (10/100/1000 Mbps)
Power Supply	24V DC
Mounting	Rack Mount
Dimensions (WxHxD)	8.27” x 4.13” x 9.84” (210 mm x 105 mm x 250 mm)
Weight	3.8 lbs (1.7 kg)
Operating Temperature	-20°C to +60°C
Storage Temperature	-40°C to +85°C
Maximum Power Consumption	14W
Status Indicators	LED indicators for communication, power, and status

Recommended Related Models

AMN31 – A versatile communication module designed for large-scale industrial applications, providing robust redundancy and multi-protocol support.
AMN33-S2 – A high-performance module offering flexible network integration with high-speed data transfer, ideal for medium-to-large-scale systems.
CS3000 – A fully integrated Distributed Control System (DCS) designed for comprehensive control, monitoring, and diagnostics in complex industrial operations.
FLXA21 – A field analyzer for real-time process diagnostics and measurement, compatible with the ANB10D-S1 to provide enhanced process control.

Popular Yokogawa Models

CS3000: A powerful DCS solution providing full process control, diagnostics, and integration capabilities for large-scale industrial facilities.
AMN31: A communication module built for high-performance industrial systems, supporting redundancy and multi-protocol integration for demanding applications.
AMN33-S2: A reliable and secure communication module designed for medium-to-large networks, ensuring high-speed and fault-tolerant data transmission.
FLXA21: A field analyzer that integrates with Yokogawa control systems to enhance process monitoring and real-time diagnostics.

Applications

The Yokogawa ANB10D-S1 Communication Module is engineered for industries where reliable, high-speed communication and secure data transfer are essential for operational efficiency:

Power Generation: Ensures seamless communication between power generation systems (turbines, generators, and control systems), optimizing operational efficiency and minimizing downtime.
Oil & Gas: Facilitates secure communication between remote offshore platforms, refineries, and central control rooms, enabling safe, efficient, and real-time operations.
Petrochemical & Chemical Processing: Enables smooth integration of process control systems and field devices, ensuring safety, regulatory compliance, and efficient plant management.
Water Treatment: Provides real-time data transfer between monitoring systems, sensors, and control platforms, ensuring optimal water quality management and regulatory compliance.
Manufacturing & Automation: Streamlines production processes by integrating machinery, sensors, and control systems, improving operational efficiency and minimizing downtime.

Advantages

Dual Ethernet Ports: With 10/100/1000 Mbps Ethernet ports, the ANB10D-S1 ensures high-speed communication and supports network redundancy, offering fault tolerance for mission-critical systems.
Multi-Protocol Support: The ANB10D-S1 supports a variety of communication protocols including Modbus TCP/IP, EtherNet/IP, OPC-UA, and PROFIBUS, making it highly flexible and compatible with diverse industrial systems.
Scalable and Flexible: Designed to scale with your network, the ANB10D-S1 enables easy integration of new devices and systems, ensuring long-term growth for both small and large applications.
Secure Communication: OPC-UA support ensures secure, encrypted communication, protecting critical operational data and ensuring the safety and integrity of your industrial network.
Compact and Rack-Mountable Design: The rack-mountable design makes the ANB10D-S1 ideal for installation in control panels and industrial enclosures, optimizing space while maintaining high functionality.
Energy Efficient: With a maximum power consumption of just 14W, the ANB10D-S1 delivers excellent performance while helping reduce operational energy costs.
Reliable in Harsh Environments: Built to endure tough industrial environments, the ANB10D-S1 operates efficiently within a temperature range of -20°C to +60°C, ensuring reliable communication even in extreme conditions.

Technical FAQs

What communication protocols are supported by the ANB10D-S1?
The ANB10D-S1 supports Modbus TCP/IP, EtherNet/IP, OPC-UA, and PROFIBUS, offering seamless integration with a wide range of industrial systems.
Is the ANB10D-S1 suitable for large-scale industrial systems?
Yes, the ANB10D-S1 is designed for both small and large systems, offering high-speed, secure communication and scalability to accommodate expanding network requirements.
What is the maximum power consumption of the ANB10D-S1?
The maximum power consumption of the ANB10D-S1 is 14W, providing an energy-efficient solution for demanding industrial networks.
What is the operating temperature range for the ANB10D-S1?
The ANB10D-S1 operates within a temperature range of -20°C to +60°C, ensuring reliable performance even in challenging industrial environments.
Does the ANB10D-S1 support redundancy for mission-critical applications?
Yes, the dual Ethernet ports provide network redundancy, ensuring uninterrupted communication even in the event of a failure.
Can the ANB10D-S1 be used with other Yokogawa systems?
Yes, the ANB10D-S1 integrates seamlessly with Yokogawa’s CENTUM VP and ProSafe-RS systems, ensuring full compatibility with Yokogawa’s suite of automation solutions.
How does the ANB10D-S1 secure data transmission?
The ANB10D-S1 uses OPC-UA for secure, encrypted data communication, ensuring the integrity and confidentiality of operational data.
What mounting options are available for the ANB10D-S1?
The ANB10D-S1 is rack-mountable, providing a flexible installation option that is space-efficient and easy to integrate into control panels or industrial enclosures.
Which industries can benefit from the ANB10D-S1?
Industries such as power generation, oil & gas, petrochemical, water treatment, and manufacturing benefit from the ANB10D-S1’s scalability, high-speed communication, and security features.
What are the physical dimensions of the ANB10D-S1?
The ANB10D-S1 has dimensions of 210 mm (W) x 105 mm (H) x 250 mm (D), providing a compact solution for industrial environments.
