The Yokogawa ANB10D-425 Communication Module is designed to provide a robust, secure, and high-speed network interface for industrial automation systems. Built for seamless integration with Yokogawa’s CENTUM VP and ProSafe-RS platforms, the ANB10D-425 ensures that your industrial processes are efficiently managed and optimized through reliable, real-time communication.

Whether in power generation, chemical processing, oil & gas, or manufacturing, the ANB10D-425 supports multiple communication protocols to ensure that critical data is transmitted with minimal latency and maximum security. Enhanced with redundant features and advanced diagnostics, it enables uninterrupted communication, making it the ideal choice for mission-critical applications where uptime is paramount.

Technical Specifications

Feature	Specification
Model	ANB10D-425
Communication Protocol	Modbus TCP/IP, EtherNet/IP, OPC-UA, PROFIBUS
Interface Type	Dual Ethernet Ports (10/100/1000 Mbps)
Power Supply	24V DC
Mounting	Rack Mount
Dimensions (WxHxD)	8.27” x 4.13” x 9.84” (210 mm x 105 mm x 250 mm)
Weight	3.8 lbs (1.7 kg)
Operating Temperature	-20°C to +60°C
Storage Temperature	-40°C to +85°C
Maximum Power Consumption	14W
Status Indicators	LED indicators for communication, power, and status

Recommended Related Models

AMN32-S1 – A high-performance communication module that supports redundancy and multiple protocols, ideal for large-scale industrial systems.
AMN33-S2 – A versatile module designed for secure, fast data transmission with redundancy features, perfect for fault-tolerant applications.
CS3000 – A fully integrated Distributed Control System (DCS) solution for real-time process control, monitoring, and diagnostics.
FLXA21 – A field analyzer that complements communication modules like the ANB10D-425 for real-time process diagnostics and measurements.

Popular Yokogawa Models

CS3000: An advanced DCS solution providing comprehensive control and monitoring for industrial facilities, ideal for large-scale operations.
AMN32-S1: A reliable communication module offering flexible, high-speed data transfer with multi-protocol support and redundancy.
AMN33-S2: A fault-tolerant communication module designed for secure and high-speed data transfer across industrial networks.
FLXA21: A versatile field analyzer that integrates with Yokogawa systems to provide accurate, real-time diagnostics and process measurements.

Applications

The Yokogawa ANB10D-425 Communication Module is designed to ensure seamless communication and efficient network integration in a wide range of industrial applications:

Power Generation: Ensures stable communication between turbines, power generators, and control systems, optimizing operational efficiency and minimizing downtime.
Oil & Gas: Facilitates real-time, secure communication between offshore platforms, refineries, and central control systems, ensuring safe and efficient operations in remote environments.
Petrochemical & Chemical Processing: Provides continuous communication between process control systems and field devices, ensuring compliance with safety regulations and consistent product quality.
Water Treatment: Enhances data transfer between monitoring systems and control devices, optimizing the efficiency of water treatment processes and ensuring regulatory compliance.
Manufacturing & Automation: Connects machines, sensors, and control systems, streamlining production lines and improving operational efficiency by reducing downtime.

Advantages

Dual Ethernet Ports: The 10/100/1000 Mbps Ethernet ports offer fast, reliable data transfer and support network redundancy, ensuring uninterrupted communication even during network failures.
Multiple Communication Protocols: The ANB10D-425 supports Modbus TCP/IP, EtherNet/IP, OPC-UA, and PROFIBUS, offering flexible integration with a variety of industrial systems.
Enhanced Redundancy: Dual Ethernet connections and redundant features ensure high availability, making the ANB10D-425 ideal for mission-critical systems that cannot afford downtime.
Secure Communication: The OPC-UA protocol enables encrypted communication, protecting sensitive industrial data from unauthorized access and ensuring data integrity.
Scalable and Flexible: This communication module is designed to easily scale with your industrial network, allowing for future expansion and the integration of additional devices.
Compact, Rack-Mountable Design: The rack-mountable form factor allows for efficient installation in control rooms or industrial panels, optimizing space and ensuring a clean, organized setup.
Energy Efficient: With a 14W power consumption, the ANB10D-425 provides a cost-effective, energy-efficient solution without compromising performance.
Wide Operating Temperature Range: The module operates in a wide temperature range of -20°C to +60°C, ensuring reliable performance in harsh industrial environments.

Technical FAQs

What communication protocols does the ANB10D-425 support?
The ANB10D-425 supports Modbus TCP/IP, EtherNet/IP, OPC-UA, and PROFIBUS, ensuring compatibility with a wide variety of industrial automation systems.
Is the ANB10D-425 suitable for large-scale industrial systems?
Yes, the ANB10D-425 is designed for both small and large-scale industrial systems, offering reliable communication and scalability for expanding networks.
What is the maximum power consumption of the ANB10D-425?
The maximum power consumption of the ANB10D-425 is 14W, making it an energy-efficient solution that does not sacrifice performance.
What is the operating temperature range for the ANB10D-425?
The ANB10D-425 operates within a temperature range of -20°C to +60°C, ensuring reliable performance across a variety of industrial environments.
Does the ANB10D-425 support redundancy?
Yes, the dual Ethernet ports provide network redundancy, ensuring that communication remains uninterrupted even in the event of network failures.
Can the ANB10D-425 integrate with other Yokogawa systems?
Yes, the ANB10D-425 integrates seamlessly with Yokogawa’s CENTUM VP and ProSafe-RS systems, ensuring smooth and reliable communication across devices.
How does the ANB10D-425 ensure secure communication?
The OPC-UA protocol ensures encrypted communication, protecting sensitive operational data and preventing unauthorized access.
What mounting options are available for the ANB10D-425?
The ANB10D-425 is rack-mountable, offering easy installation in control rooms or industrial panels, optimizing space while providing powerful communication capabilities.
Which industries benefit from the ANB10D-425?
The ANB10D-425 is ideal for industries such as power generation, oil & gas, petrochemical, water treatment, and manufacturing, where secure, high-speed communication is essential.
What are the physical dimensions of the ANB10D-425?
The ANB10D-425 has dimensions of 210 mm (W) x 105 mm (H) x 250 mm (D), providing a compact, space-saving design that fits easily into control systems.
