The Yokogawa ANR10D-420 Communication Module is a robust and high-performance solution designed to facilitate seamless communication in complex industrial environments. Built for integration with Yokogawa’s CENTUM VP and ProSafe-RS control systems, the ANR10D-420 ensures high-speed, reliable data exchange for optimized process control, monitoring, and management.

With support for multiple industrial communication protocols and advanced redundancy features, the ANR10D-420 guarantees operational continuity in critical applications across sectors such as power generation, petrochemical, oil & gas, water treatment, and manufacturing. Its secure, encrypted communication ensures the integrity and safety of industrial data, while its compact design allows for easy integration into existing industrial networks.

Technical Specifications

Feature	Specification
Model	ANR10D-420
Communication Protocol	Modbus TCP/IP, EtherNet/IP, OPC-UA, PROFIBUS
Interface Type	Dual Ethernet Ports (10/100/1000 Mbps)
Power Supply	24V DC
Mounting	Rack Mount
Dimensions (WxHxD)	8.27” x 4.13” x 9.84” (210 mm x 105 mm x 250 mm)
Weight	3.8 lbs (1.7 kg)
Operating Temperature	-20°C to +60°C
Storage Temperature	-40°C to +85°C
Maximum Power Consumption	14W
Status Indicators	LED indicators for communication, power, and status

Recommended Related Models

AMN32-S1 – A high-performance communication module with multiple protocol support and network redundancy, ideal for large-scale and fault-tolerant industrial systems.
AMN33-S2 – A versatile communication module offering fast, secure data transmission with redundancy features, perfect for high-availability applications.
CS3000 – A comprehensive Distributed Control System (DCS) that integrates seamlessly with communication modules like the ANR10D-420 to manage and monitor complex industrial processes.
FLXA21 – A field analyzer designed to complement communication modules like the ANR10D-420, providing accurate, real-time diagnostics and process measurements.

Popular Yokogawa Models

CS3000: An integrated Distributed Control System (DCS) that provides centralized control, monitoring, and diagnostics across diverse industrial applications.
AMN32-S1: A communication module designed for high-speed data transfer with redundancy, offering flexibility and compatibility with multiple industrial protocols.
AMN33-S2: A high-reliability communication module that supports secure, fault-tolerant communication in industrial environments.
FLXA21: A versatile field analyzer for real-time process diagnostics and integration with communication systems like the ANR10D-420, ensuring precision in measurement and control.

Applications

The Yokogawa ANR10D-420 Communication Module is ideal for industries where high-speed, secure, and reliable data transmission is critical for operational success. Key applications include:

Power Generation: Ensures fast, reliable communication between turbines, generators, and control systems, optimizing efficiency and reducing downtime in power plants.
Oil & Gas: Facilitates secure communication across remote offshore platforms, refineries, and central control systems, ensuring safe and efficient operations in challenging environments.
Petrochemical & Chemical Processing: Provides continuous communication between process control systems and field devices, enhancing safety, efficiency, and compliance with regulatory standards.
Water Treatment: Enables smooth data transfer between monitoring systems and control devices, ensuring efficient operation and compliance with environmental regulations.
Manufacturing & Automation: Connects machines, sensors, and control systems, improving overall efficiency and minimizing downtime through reliable, high-speed communication.

Advantages

Dual Ethernet Ports: Equipped with 10/100/1000 Mbps Ethernet ports, the ANR10D-420 ensures fast data transfer and supports network redundancy, maintaining communication even if one network connection fails.
Multiple Communication Protocols: The ANR10D-420 supports Modbus TCP/IP, EtherNet/IP, OPC-UA, and PROFIBUS, offering seamless integration with a wide range of industrial systems.
Enhanced Redundancy: With dual Ethernet ports, the ANR10D-420 provides network redundancy, ensuring continuous communication even in the event of network failures, which is crucial for mission-critical systems.
Secure Communication: Utilizing OPC-UA, the ANR10D-420 provides encrypted communication, ensuring the safety and integrity of industrial data during transmission.
Scalable and Flexible: The ANR10D-420 is designed to scale with your industrial network, allowing for future expansion as your needs evolve.
Compact, Rack-Mountable Design: The rack-mountable design of the ANR10D-420 allows for easy integration into control panels and industrial enclosures, optimizing space in your system.
Energy Efficient: With a 14W maximum power consumption, the ANR10D-420 is an energy-efficient solution, helping reduce operational costs while maintaining high performance.
Wide Operating Temperature Range: The ANR10D-420 operates in a wide temperature range of -20°C to +60°C, ensuring reliable performance in both standard and harsh industrial environments.

Technical FAQs

What communication protocols are supported by the ANR10D-420?
The ANR10D-420 supports Modbus TCP/IP, EtherNet/IP, OPC-UA, and PROFIBUS, providing flexibility for integration with various industrial automation systems.
Is the ANR10D-420 suitable for large-scale industrial applications?
Yes, the ANR10D-420 is designed for large-scale industrial networks, offering high-speed communication, redundancy, and scalability to support the growing demands of complex systems.
What is the maximum power consumption of the ANR10D-420?
The maximum power consumption of the ANR10D-420 is 14W, making it an energy-efficient solution for industrial networks without compromising on performance.
What is the operating temperature range for the ANR10D-420?
The ANR10D-420 operates within an extended temperature range of -20°C to +60°C, ensuring reliable performance in diverse industrial environments.
Does the ANR10D-420 support redundancy?
Yes, the dual Ethernet ports provide network redundancy, ensuring continuous communication even if one of the connections fails, making it ideal for high-availability applications.
Can the ANR10D-420 integrate with other Yokogawa systems?
Yes, the ANR10D-420 integrates seamlessly with Yokogawa’s CENTUM VP and ProSafe-RS systems, ensuring smooth communication and data transfer between devices.
How does the ANR10D-420 ensure secure communication?
The OPC-UA protocol ensures encrypted communication, protecting sensitive data and ensuring the integrity of industrial information during transmission.
What mounting options are available for the ANR10D-420?
The ANR10D-420 is rack-mountable, making it easy to install in control rooms or industrial enclosures, saving space and optimizing system organization.
Which industries benefit from the ANR10D-420?
The ANR10D-420 is ideal for industries such as power generation, oil & gas, petrochemical, water treatment, and manufacturing, where secure, high-speed communication is vital.
What are the physical dimensions of the ANR10D-420?
The ANR10D-420 has dimensions of 210 mm (W) x 105 mm (H) x 250 mm (D), providing a compact and efficient form factor for industrial installations.
