The Yokogawa ANR10S Communication Module is a highly efficient and versatile industrial communication solution designed to support seamless data transmission in complex automation and control systems. Engineered to integrate with Yokogawa’s CENTUM VP and ProSafe-RS systems, the ANR10S ensures secure and fast communication across a wide range of industrial applications, from power plants to manufacturing facilities.

With its dual Ethernet ports, robust redundancy features, and support for multiple communication protocols, the ANR10S guarantees high uptime, smooth data exchange, and optimal system performance. Ideal for environments where reliable data transfer and network security are critical, the ANR10S provides an excellent solution for achieving operational efficiency and minimizing downtime.

Technical Specifications

Feature	Specification
Model	ANR10S
Communication Protocol	Modbus TCP/IP, EtherNet/IP, OPC-UA, PROFIBUS
Interface Type	Dual Ethernet Ports (10/100/1000 Mbps)
Power Supply	24V DC
Mounting	Rack Mount
Dimensions (WxHxD)	8.27” x 4.13” x 9.84” (210 mm x 105 mm x 250 mm)
Weight	3.8 lbs (1.7 kg)
Operating Temperature	-20°C to +60°C
Storage Temperature	-40°C to +85°C
Maximum Power Consumption	14W
Status Indicators	LED indicators for communication, power, and status

Recommended Related Models

AMN32-S1 – A high-performance communication module designed for large-scale industrial systems, offering multi-protocol support and redundancy.
AMN33-S2 – A reliable communication solution ideal for fault-tolerant, high-availability systems, supporting secure and fast data transmission.
CS3000 – A fully integrated Distributed Control System (DCS) for centralized process control and monitoring, designed to work seamlessly with modules like the ANR10S.
FLXA21 – A real-time process analyzer that complements communication modules like the ANR10S for enhanced process diagnostics and accurate measurements.

Popular Yokogawa Models

CS3000: A comprehensive DCS that enables efficient and centralized control across complex industrial systems, integrating smoothly with communication modules like the ANR10S.
AMN32-S1: A versatile communication module with robust redundancy, ideal for critical, large-scale systems requiring high-speed communication.
AMN33-S2: A communication module designed for maximum reliability, offering fast data transmission and redundancy features, perfect for mission-critical applications.
FLXA21: A field analyzer designed to work with communication modules like the ANR10S, enabling real-time diagnostics and measurement for accurate process control.

Applications

The Yokogawa ANR10S Communication Module is designed for industries where high-speed, secure, and reliable communication is vital for operational success. Key applications include:

Power Generation: The ANR10S provides stable communication between turbines, generators, and control systems, ensuring real-time monitoring and optimization for power plants.
Oil & Gas: Secure, high-speed communication across offshore platforms, refineries, and control centers enables safe and efficient operations in the oil and gas industry.
Petrochemical & Chemical Processing: Facilitates continuous data exchange between process control systems and field devices, improving safety, productivity, and compliance with regulatory standards.
Water Treatment: Ensures smooth communication between monitoring systems and control devices in water treatment facilities, supporting operational efficiency and environmental compliance.
Manufacturing & Automation: The ANR10S connects machines, sensors, and control systems, enhancing productivity and minimizing downtime through efficient data transfer.

Advantages

Dual Ethernet Ports: Equipped with 10/100/1000 Mbps Ethernet ports, the ANR10S ensures fast data transfer and supports network redundancy, maintaining continuous communication even in the event of network failure.
Multiple Communication Protocols: Supports Modbus TCP/IP, EtherNet/IP, OPC-UA, and PROFIBUS, making the ANR10S compatible with various industrial devices and systems.
Redundancy for High Availability: The dual Ethernet ports provide network redundancy, ensuring uninterrupted communication, which is essential for high-availability applications.
Secure Communication: The OPC-UA protocol ensures encrypted communication, providing enhanced security for industrial data during transmission.
Flexible and Scalable: The ANR10S is designed for scalability, allowing easy expansion of your network and integration of new devices as your system grows.
Compact Design: The rack-mountable form factor optimizes space in industrial control panels or enclosures, facilitating easy installation in tight spaces.
Energy Efficient: With a low power consumption of only 14W, the ANR10S offers energy efficiency while maintaining high performance.
Wide Temperature Range: Operating between -20°C and +60°C, the ANR10S can withstand diverse environmental conditions, ensuring reliable operation in harsh industrial environments.

Technical FAQs

What communication protocols does the ANR10S support?
The ANR10S supports Modbus TCP/IP, EtherNet/IP, OPC-UA, and PROFIBUS, ensuring compatibility with various industrial automation systems.
Is the ANR10S suitable for large-scale industrial systems?
Yes, the ANR10S is designed for both small and large-scale systems, offering scalability, high-speed communication, and redundancy features for critical applications.
What is the maximum power consumption of the ANR10S?
The maximum power consumption of the ANR10S is 14W, making it an energy-efficient communication module for industrial networks.
What is the operating temperature range for the ANR10S?
The ANR10S operates within a temperature range of -20°C to +60°C, ensuring reliable performance in a variety of industrial environments.
Does the ANR10S support redundancy?
Yes, the ANR10S supports network redundancy through dual Ethernet ports, ensuring continuous communication even if one network connection fails.
Can the ANR10S be integrated with other Yokogawa systems?
Yes, the ANR10S integrates seamlessly with Yokogawa’s CENTUM VP and ProSafe-RS systems, ensuring smooth communication across devices and systems.
How does the ANR10S ensure secure communication?
The OPC-UA protocol provides encrypted communication, ensuring the safety and integrity of industrial data during transmission.
What mounting options are available for the ANR10S?
The ANR10S is rack-mountable, making it easy to install in control panels or industrial enclosures, saving space and organizing the system efficiently.
Which industries benefit from the ANR10S?
The ANR10S is ideal for industries such as power generation, oil & gas, petrochemical, water treatment, and manufacturing, where secure and reliable communication is crucial.
What are the physical dimensions of the ANR10S?
The ANR10S has dimensions of 210 mm (W) x 105 mm (H) x 250 mm (D), offering a compact solution for industrial installations.
