The GE IC200ALG230A Analog Input Module is designed to provide high-accuracy and reliable signal conversion in industrial automation systems. With its ability to handle 8 differential or 16 single-ended analog input channels, this module is ideal for applications where precise measurement and data acquisition of voltage or current signals are required. Whether you're working with temperature sensors, pressure transmitters, or flow meters, the IC200ALG230A ensures that your control system receives accurate and timely analog data for effective decision-making.
The module is part of the GE VersaMax™ I/O system, which integrates seamlessly with the VersaMax PLC and other GE PACSystems™ controllers. The IC200ALG230A is particularly beneficial for industries that demand high-density input solutions, including manufacturing, chemical processing, oil & gas, power generation, and water treatment. Its flexibility and compact design allow it to be easily integrated into complex systems where space and performance are critical.
Built to withstand the challenges of industrial environments, the IC200ALG230A provides high accuracy and low drift for reliable performance over time.
Technical Specifications
| Specification | Details |
|---|---|
| Model | GE IC200ALG230A |
| Module Type | Analog Input Module |
| Input Channels | 8 Differential or 16 Single-Ended Inputs |
| Input Type | Voltage (0-10V, ±10V) or Current (4-20mA) |
| Input Voltage Range | ±10V (differential), 0-10V (single-ended) |
| Input Current Range | 4-20mA |
| Accuracy | ±0.1% of Full Scale |
| Resolution | 16-bit |
| Sample Rate | 20ms (for 8 channels) |
| Isolation | 1500V isolation between inputs and system |
| Dimensions (HxWxD) | 4.1" x 2.8" x 3.5" (104 mm x 71 mm x 89 mm) |
| Weight | 0.3 kg (0.66 lbs) |
| Power Supply | 5V DC (from system power supply) |
| Mounting | DIN Rail Mounted |
| Operating Temperature Range | -40°C to 70°C (-40°F to 158°F) |
| Environmental Protection | IP20 (protected from dust and water droplets) |
| Diagnostic Features | Built-in LEDs for status monitoring |
Recommended Related Models
For other analog I/O solutions or different configurations, consider the following GE models:
-
GE IC200ALG330A – A 16-channel analog input module offering increased channel density, suitable for applications requiring large numbers of analog inputs.
-
GE IC200MDL640 – A digital input module for systems that require digital signal processing, complementing the analog input capabilities of the IC200ALG230A.
-
GE IC200ALD620 – A current input module offering a high range of current input signals for specialized applications.
Popular GE Models
For reliable signal processing and industrial automation, the GE IC200ALG230A is commonly used alongside these GE models:
-
GE VersaMax I/O – A modular I/O system that includes the IC200ALG230A, providing flexible and scalable input-output solutions.
-
GE PACSystems RX3i – A powerful controller that integrates seamlessly with GE I/O modules, including the IC200ALG230A, offering robust industrial control.
-
GE IC200ALC640 – A 24V DC current output module, useful for applications requiring both current input and current output.
