The GE IC200ALG265 Analog Input Module is a high-performance solution designed for accurate and reliable analog signal acquisition in industrial automation systems. Part of the VersaMax™ I/O system, this module provides 16 single-ended or 8 differential analog input channels, ensuring compatibility with a wide variety of industrial sensors. Whether used in temperature control, pressure measurement, or flow monitoring, the IC200ALG265 ensures the system receives high-quality, actionable data for seamless control of industrial processes.

The module supports both voltage inputs (0-10V, ±10V) and current inputs (4-20mA), making it highly versatile in handling a broad range of sensor types. Offering 16-bit resolution and ±0.1% accuracy, the IC200ALG265 guarantees that your data acquisition system performs with the high precision necessary for critical applications. It integrates easily with GE PACSystems™ and VersaMax PLCs, enabling quick and simple integration into your existing control infrastructure.

Built to withstand the rigors of industrial environments, the IC200ALG265 operates within a wide temperature range, ensuring reliable performance in both high- and low-temperature conditions. Its compact form factor and DIN rail mounting design allow it to be easily installed in limited space.

Technical Specifications

Specification	Details
Model	GE IC200ALG265
Module Type	Analog Input Module
Input Channels	16 Single-Ended or 8 Differential Inputs
Input Signal Types	Voltage (0-10V, ±10V) or Current (4-20mA)
Accuracy	±0.1% of Full Scale
Resolution	16-bit
Sample Rate	20ms per channel (for 8 differential channels)
Isolation	1500V isolation between inputs and system
Dimensions (HxWxD)	4.1" x 2.8" x 3.5" (104 mm x 71 mm x 89 mm)
Weight	0.3 kg (0.66 lbs)
Power Supply	5V DC (from system power supply)
Mounting	DIN Rail Mounted
Operating Temperature Range	-40°C to 70°C (-40°F to 158°F)
Environmental Protection	IP20 (protected from dust and water droplets)
Diagnostic Features	Built-in LEDs for status monitoring

Recommended Related Models

For enhanced functionality or different I/O configurations, consider the following GE models:

GE IC200ALG230A – A single-ended analog input module with fewer channels, perfect for systems with simpler signal acquisition requirements.
GE IC200ALG330A – A 16-channel analog input module that allows for greater channel density, providing flexibility in more complex applications.
GE IC200MDL740 – A digital input module ideal for systems that require both analog and digital signal processing.

Popular GE Models

The GE IC200ALG265 is often used alongside the following GE models for robust industrial automation systems:

GE VersaMax I/O System – A modular I/O solution that integrates seamlessly with the IC200ALG265, providing a scalable solution for automation and control applications.
GE PACSystems RX3i – A high-performance industrial controller that supports the IC200ALG265, making it ideal for large, complex automation systems requiring high levels of precision.
GE VersaMax PLC – A flexible and cost-effective controller for applications needing integration with analog I/O such as the IC200ALG265.

Applications

The GE IC200ALG265 Analog Input Module is suitable for a wide variety of industrial applications:

Manufacturing: Collects data from pressure sensors, temperature transducers, and flow meters, helping to maintain efficient operation of automated production lines and systems.
Chemical Processing: Monitors key process variables such as temperature, pH, and chemical concentrations to optimize chemical reactors and ensure product quality.
Oil & Gas: Provides data from pressure transmitters, level gauges, and flow meters to monitor operations in drilling, refining, and pipeline systems.
Power Generation: Used in turbine monitoring, generator control, and temperature sensing in power plants, ensuring safe and efficient power production.
Water Treatment: Measures flow rates, chemical dosing, and tank levels for optimal control in water treatment and wastewater management systems.

Advantages

High-Resolution Signal Processing: The 16-bit resolution ensures that the IC200ALG265 captures and converts analog signals with excellent accuracy, making it ideal for high-precision applications.

Wide Input Flexibility: Supports voltage (0-10V, ±10V) and current (4-20mA) signals, providing compatibility with a broad range of industrial sensors.

Fast Sampling Rate: With a 20ms sample rate for 8 differential channels, the module ensures quick data acquisition for real-time monitoring and control.

Built-in Diagnostics: LED status indicators provide real-time feedback on the health and performance of the module, facilitating easy troubleshooting and system maintenance.

Compact Design: The module’s small form factor and DIN rail mounting make it ideal for use in space-constrained installations, maximizing available panel space.

Reliable in Harsh Environments: With an operating temperature range of -40°C to 70°C, the IC200ALG265 is built to perform in extreme conditions, providing reliable operation in a wide range of industrial environments.

Technical FAQs

How many input channels does the GE IC200ALG265 support?
The IC200ALG265 supports 16 single-ended or 8 differential input channels, providing flexibility depending on your application’s channel requirements.
What accuracy does the IC200ALG265 provide?
The module offers an accuracy of ±0.1% of full scale, ensuring high-precision data collection for critical processes.
What input signal types can the IC200ALG265 process?
The module supports voltage signals (0-10V, ±10V) and current signals (4-20mA), making it compatible with most industrial sensors.
What is the resolution of the IC200ALG265?
The IC200ALG265 provides 16-bit resolution, offering fine precision in analog-to-digital conversion.
What is the sample rate of the IC200ALG265?
The module provides a 20ms sample rate per channel for 8 differential channels, ensuring fast and responsive data collection.
What isolation rating does the IC200ALG265 offer?
The module has 1500V isolation between input channels and the system, protecting against electrical noise and interference.
What is the operating temperature range of the IC200ALG265?
The IC200ALG265 operates in a temperature range of -40°C to 70°C, ensuring reliable performance in a wide range of industrial environments.
How is the IC200ALG265 mounted?
The module is designed for DIN rail mounting, making installation easy and secure in industrial control panels.
What diagnostic features does the IC200ALG265 include?
The IC200ALG265 includes LED status indicators for real-time monitoring of module performance, simplifying troubleshooting.
Can the IC200ALG265 be used in hazardous environments?
The IC200ALG265 has an IP20 rating, offering basic protection against dust and water ingress. For more challenging environments, additional protective measures may be required.
