The GE IC200CHS006E is a Control/Status Module designed to facilitate seamless communication and real-time status monitoring for industrial automation systems. As part of the VersaMax™ I/O series, this module is engineered to optimize data exchange between GE PLCs and the associated I/O modules, ensuring smooth and efficient operations in demanding industrial environments.

The IC200CHS006E plays a crucial role in providing system diagnostics and status indicators, allowing operators to monitor the health of their systems, identify faults quickly, and make necessary adjustments in real time. With advanced diagnostic capabilities, this module is ideal for applications that require constant status feedback and system health checks to maintain optimal performance.

This module is typically used in conjunction with GE VersaMax PLCs and is suitable for various industries, including manufacturing, chemical processing, oil & gas, and energy management. Its robust features and reliable performance make it a crucial component in ensuring system integrity and communication efficiency.

Technical Specifications

Specification	Details
Model	GE IC200CHS006E
Module Type	Control/Status Module
Function	Provides system status feedback and diagnostics
Status Indicators	8 LEDs for monitoring status and system diagnostics
Mounting	DIN Rail Mounted
Input/Output Type	Digital I/O (Status signals)
Operating Voltage	24V DC
Power Consumption	5W (max)
Dimensions (HxWxD)	4.1" x 2.8" x 3.5" (104 mm x 71 mm x 89 mm)
Weight	0.3 kg (0.66 lbs)
Operating Temperature Range	-40°C to 70°C (-40°F to 158°F)
Environmental Protection	IP20 (protected from dust and water droplets)
Status LED Indicators	Indicates power, communication, and module diagnostics

Recommended Related Models

For enhanced functionality or alternative configurations, consider these GE models:

GE IC200MDL640 – A digital output module for controlling various industrial devices, compatible with the VersaMax I/O system.
GE IC200CBM002 – A base module for the VersaMax system, offering essential support for I/O configuration and management.
GE IC200CHS002 – A previous generation status module, suitable for smaller applications requiring fewer diagnostics and status signals.

Popular GE Models

The GE IC200CHS006E integrates seamlessly with GE PLC systems and is designed for reliable communication and system monitoring:

GE VersaMax I/O System – The IC200CHS006E is part of the VersaMax I/O system, which is designed for modularity, scalability, and flexibility in various industrial automation applications.
GE PACSystems RX3i – A high-performance controller that, when paired with the IC200CHS006E, provides advanced real-time monitoring and data communication capabilities.
GE VersaMax PLC – A versatile and cost-effective PLC that integrates with the IC200CHS006E for system diagnostics and communication monitoring in industrial environments.

Applications

The GE IC200CHS006E is well-suited for industries that require continuous system monitoring and status feedback, including:

Manufacturing Automation: Helps monitor the health of assembly lines, conveyor belts, and automated machines, ensuring smooth operations and minimizing downtime.
Oil & Gas: Provides real-time diagnostics and status updates for pumps, drilling equipment, and pipeline systems, enabling rapid response to operational changes or issues.
Energy Management: Facilitates communication between power generation systems, transformers, and control panels to ensure consistent energy distribution and efficient system operation.
Water Treatment: Monitors water treatment plants, ensuring that all system components, including pumps, filtration systems, and chemical dosing units, are functioning within operational limits.
Chemical Processing: Helps track the operational status of reactors, mixers, and valves to maintain proper flow, pressure, and temperature parameters within safe operating conditions.

Advantages

Advanced Diagnostic Feedback: With 8 built-in LED indicators, the IC200CHS006E provides clear feedback on system status, communication errors, and module diagnostics, ensuring easier troubleshooting and faster response times.
Real-Time Status Monitoring: The module continuously monitors system performance and provides real-time alerts, helping operators act on issues before they impact production.
Flexible Integration: Designed to integrate easily with both GE VersaMax I/O systems and PACSystems RX3i controllers, making it suitable for a wide variety of industrial automation applications.
Space-Saving Design: Its compact DIN rail mounting allows for easy installation in space-constrained control panels, optimizing available space in control rooms and machinery enclosures.
Wide Operating Temperature Range: With an operating temperature range of -40°C to 70°C, the IC200CHS006E is capable of performing reliably in both extremely cold and hot environments, ensuring year-round operational consistency.
Power-Efficient: With a maximum power consumption of only 5W, the module offers an energy-efficient solution for system communication and diagnostics, reducing the overall power footprint of your automation system.
Durability and Protection: The module's IP20 protection ensures it is resistant to dust and water droplets, making it suitable for harsh industrial environments.

Technical FAQs

What is the main function of the GE IC200CHS006E?
The IC200CHS006E provides real-time system diagnostics and status feedback for VersaMax I/O systems, ensuring continuous monitoring of system health.
How many diagnostic LEDs are included?
The module features 8 LED indicators to show the operational status and system diagnostics, helping users quickly identify and address issues.
What type of I/O does the IC200CHS006E support?
The IC200CHS006E is designed for digital I/O used for system status monitoring and diagnostics.
What is the power requirement for the IC200CHS006E?
The module operates with 24V DC and consumes a maximum of 5W, making it energy-efficient.
Can the IC200CHS006E be integrated with other GE PLC models?
Yes, the module works seamlessly with GE VersaMax PLCs and PACSystems RX3i, ensuring reliable communication and system diagnostics.
What is the operating temperature range of the IC200CHS006E?
The IC200CHS006E operates in a temperature range from -40°C to 70°C, allowing it to function in diverse industrial environments.
How is the IC200CHS006E mounted?
The IC200CHS006E can be easily mounted on a DIN rail, making it ideal for installation in control panels or machinery enclosures.
What types of feedback does the IC200CHS006E provide?
The module provides real-time system status updates, including feedback on communication, power, and diagnostic conditions via its built-in LED indicators.
Is the IC200CHS006E suitable for use in hazardous environments?
The IC200CHS006E has an IP20 rating, offering basic protection against dust and water droplets. Additional enclosures may be needed for more hazardous or wet environments.
What industries benefit most from the IC200CHS006E?
The IC200CHS006E is beneficial for industries requiring continuous monitoring and diagnostics, such as manufacturing, oil & gas, energy, and water treatment.
