The GE IC200GBI001 Digital Input Module is designed to provide efficient and reliable signal processing in industrial automation systems. As part of the Versamax PLC series, this module allows for seamless integration of digital input signals from external devices, such as sensors, switches, and other control elements. With 16 input channels, the IC200GBI001 enables precise control of your system, ensuring smooth operation and accurate data acquisition. Whether you're working in manufacturing, process control, or building automation, this module is engineered to meet the high demands of modern industrial environments.

Technical Specifications

Model: IC200GBI001
Type: Digital Input Module
Input Type: 24V DC digital inputs
Input Channels: 16 digital inputs
Input Voltage Range: 20.4V DC to 28.8V DC
Power Consumption: 35mA @ 24V DC
Input Response Time: 5ms (typical)
Isolation: 1500V RMS
Mounting: DIN rail or panel mount
Dimensions: 4.75" x 3.85" x 3.5" (121 mm x 98 mm x 89 mm)
Weight: 0.5 lbs (0.23 kg)
Operating Temperature: 0°C to 60°C
Storage Temperature: -40°C to 85°C
Relative Humidity: 5% to 95%, non-condensing

Recommended Related Models

To expand the capabilities of your Versamax PLC system, consider these complementary modules:

IC200CPUE06: A high-performance CPU module for larger systems requiring advanced processing and greater I/O capacity.
IC200MDL640: A versatile digital I/O module offering additional input and output points.
IC200PWR001: Power supply module to ensure consistent and reliable voltage regulation across your system.
IC200CMM002: Communication module for Modbus and Ethernet compatibility to enable robust network connectivity.

Popular GE PLC Models

The Versamax PLC series offers a range of solutions for different industrial needs. Some of the most popular models include:

IC200CPUE05-LT: A cost-effective and versatile CPU ideal for small to medium-scale automation systems.
IC200CPUE06: A more powerful CPU offering advanced communication and higher I/O capacity for larger systems.
IC200MDL740: Digital I/O module designed for handling higher I/O point requirements in demanding applications.

Applications

The GE IC200GBI001 Digital Input Module is perfect for use in various industrial applications, including:

Manufacturing Automation: Collects input data from sensors, switches, and control devices to manage machinery and production lines.
Process Control: Interfaces with sensors and controllers to monitor and manage critical processes in industries such as chemical, water, and oil & gas.
Building Automation: Used for monitoring environmental sensors, security systems, and other control systems in commercial and industrial buildings.
Material Handling: Captures input from proximity sensors, limit switches, and other devices in conveyor systems, ensuring accurate control over material flows.

Advantages

Flexible Integration: Easily integrates with the Versamax PLC, expanding the I/O capacity of your existing control system.
High Input Accuracy: Ensures reliable and fast digital input signal processing, with a typical response time of 5ms.
Robust Isolation: Provides 1500V RMS isolation to protect the system from electrical surges or spikes.
Cost-Effective: A highly affordable solution for expanding digital input capacity in your PLC system.
Compact Design: Its space-efficient design makes it ideal for installations where space is limited.

Technical FAQs

How many digital inputs does the IC200GBI001 support?
The IC200GBI001 module supports 16 digital inputs, ideal for managing multiple sensors or switches.
What is the voltage range for the digital inputs?
The module supports 20.4V DC to 28.8V DC for reliable digital signal processing.
Can the IC200GBI001 be used for 110V AC input signals?
No, the module is specifically designed for 24V DC digital inputs, and cannot process higher voltage signals without additional equipment.
What is the response time of the digital inputs?
The typical response time for digital inputs is 5ms, ensuring fast and accurate signal processing.
What is the maximum isolation voltage?
The module provides 1500V RMS isolation between input channels and the internal circuitry, protecting the system from electrical noise.
What software is required to configure and program this module?
The Proficy Machine Edition software suite from GE is used for configuring and programming the Versamax PLC system, including the IC200GBI001 module.
Can this module be used in outdoor environments?
While the IC200GBI001 is suitable for industrial applications, it should be protected from direct exposure to extreme weather conditions. Proper enclosure is recommended for outdoor use.
Can I add additional I/O modules to expand my system further?
Yes, the Versamax PLC system supports additional I/O modules such as the IC200MDL640, IC200GBI001, and others, to further expand the I/O capacity of your system.
What is the typical power consumption of this module?
The IC200GBI001 module consumes 35mA at 24V DC.
How is the IC200GBI001 mounted?
The module can be mounted on DIN rails or panel-mounted, making installation flexible for various system configurations.
