The GE IC200MDL241E Digital Output Module is designed to provide seamless control of discrete output devices in industrial automation systems. As part of the Versamax PLC series, this module offers 16 high-quality digital output channels for controlling actuators, relays, and other field devices. Whether used in manufacturing, process control, or material handling, the IC200MDL241E module enhances the versatility of your PLC system by offering fast and reliable digital output processing. Built to withstand harsh industrial environments, this module ensures precise and dependable operation, making it an excellent choice for diverse automation applications.

Technical Specifications

Model: IC200MDL241E
Type: Digital Output Module
Output Type: 24V DC sinking (current sourcing is also available in specific configurations)
Output Points: 16 digital outputs
Voltage Range: 20.4V DC to 28.8V DC
Current Rating: 0.5A per output channel (maximum)
Power Consumption: 40mA @ 24V DC
Mounting: DIN rail or panel mount
Dimensions: 4.75" x 3.85" x 3.5" (121 mm x 98 mm x 89 mm)
Weight: 0.5 lbs (0.23 kg)
Operating Temperature: 0°C to 60°C
Storage Temperature: -40°C to 85°C
Relative Humidity: 5% to 95%, non-condensing
Isolation: 1500V RMS

Recommended Related Models

To further expand your Versamax PLC system, consider these complementary models:

IC200CPUE06: A powerful CPU module with higher processing capacity and greater I/O capabilities for complex automation systems.
IC200GBI001: Digital input module for reliable signal processing from sensors, switches, and other field devices.
IC200PWR001: Power supply module that ensures stable voltage delivery for the entire control system.
IC200ERM002A: Ethernet and Modbus communication module for seamless system integration and network connectivity.

Popular GE PLC Models

The Versamax PLC series offers various models that provide flexible solutions for a wide range of industrial applications:

IC200CPUE05-LT: An entry-level CPU for general-purpose automation tasks in smaller systems.
IC200CPUE06: A high-performance CPU designed for larger and more complex applications.
IC200MDL640: A digital I/O module for systems requiring additional input/output capacity.

Applications

The GE IC200MDL241E Digital Output Module is well-suited for a variety of industrial applications, including:

Manufacturing Automation: Controls actuators, valves, and relays in production lines, enabling automated machine operations.
Process Control: Provides output signals to field devices in industries such as chemical, oil and gas, and water treatment.
Material Handling: Used in conveyor systems, robotic arms, and sorting machines to control the movement and handling of materials.
Building Automation: Controls lighting systems, HVAC systems, and security systems in commercial and industrial buildings.

Advantages

High-Quality Outputs: The IC200MDL241E ensures high-performance digital output control, ideal for driving a wide range of field devices.
Flexible Output Configuration: Can handle 24V DC sinking outputs, allowing for easy integration with various types of external devices.
Compact and Robust: Its space-efficient design is built to endure the challenges of industrial environments, ensuring reliability and longevity.
Cost-Effective Expansion: Expands the I/O capacity of your existing Versamax PLC system without the need for costly new systems or major upgrades.
Fast and Reliable Processing: With quick response times, this module ensures real-time control of output devices in dynamic industrial applications.

Technical FAQs

How many digital outputs does the IC200MDL241E module support?
The IC200MDL241E supports 16 digital output channels, ideal for controlling multiple field devices simultaneously.
What is the maximum current rating for each output channel?
The maximum current per output channel is 0.5A, allowing for control of most actuators and relays.
What is the output type of this module?
The module provides 24V DC sinking outputs, which can be used to control external devices that are configured for sinking (current is sourced from the device).
What is the voltage range supported by the IC200MDL241E?
The module operates within a voltage range of 20.4V DC to 28.8V DC for optimal output performance.
What is the power consumption of the IC200MDL241E module?
The module consumes 40mA at 24V DC during operation, making it energy-efficient for integration into your control system.
Can the IC200MDL241E be used in harsh environments?
Yes, the module is designed for industrial environments with an operating temperature range of 0°C to 60°C and provides 1500V RMS isolation to protect against electrical surges.
Is this module compatible with other GE PLC models?
Yes, the IC200MDL241E is compatible with any system within the Versamax PLC family, expanding its I/O capabilities.
Can I use this module for controlling high-power equipment?
The IC200MDL241E is suitable for controlling low to moderate power devices. For controlling high-power equipment, use relays or solid-state relays between the module and the high-power device.
What type of installation is required for this module?
The IC200MDL241E can be mounted on DIN rails or panel-mounted, providing flexibility for installation in various system designs.
Does this module have any built-in diagnostic indicators?
Yes, the IC200MDL241E includes LED indicators for each output point, showing the status of each channel for easy diagnostics and troubleshooting.
